Technical Information & Details of the MEAN WELL PWM-60-24DA2 LED Driver Output Power: 60 W Output Voltage: 24 V DC Output Current: 2.5 A Dimming Range: 0 – 100 % (PWM dimming, DALI‑2 control) PWM Output Frequency: approx. 2.5 kHz (DA2 type, fixed) Dimming Interface: DALI‑2 primary‑side interface (DA+ / DA−, no polarity), 16 groups, 64 addresses, first step fixed at 0.2 % of output Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Input Frequency: 47 – 63 Hz Power Factor (typ.): > 0.97 @115 VAC, > 0.95 @230 VAC, > 0.92 @277 VAC (full load) Efficiency (typ.): approx. 89 % AC Input Current (typ.): 0.8 A @115 VAC / 0.4 A @230 VAC / 0.32 A @277 VAC Inrush Current (typ.): 50 A @230 VAC (cold start, twidth ≈270 μs, per NEMA 410) THD: < 20 % (≥60 % load @115 / 230 VAC; ≥75 % load @277 VAC) No‑load Power Consumption: < 0.5 W Overload Protection: 108 – 130 % of rated power, hiccup mode (DA2 type), auto recovery (see static characteristic) Overvoltage Protection: shut down output, re‑power on to recover (typ. 28 – 34 V DC) Overtemperature Protection: shut down output, re‑power on to recover (DA2 type in hiccup‑like behaviour) Short‑circuit Protection: hiccup mode, auto recovery Operating Temperature (case): −40 °C to +85 °C (derating according to “Output load vs. temperature” curve) Operating Humidity: 20 – 95 % RH, non‑condensing Storage Temperature / Humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature Coefficient: ±0.03 % / °C (0 – 50 °C) Vibration Resistance: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along each X, Y, Z axis Dielectric Strength: 3.75 kVAC (input–output), 1.5 kVAC (input–DA), 1.5 kVAC (output–DA) Isolation Resistance: > 100 MΩ @500 VDC, 25 °C, 70 % RH Safety Standards: UL8750 (type “HL”, except DA type), UL879 (12/24 V Blank), ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, BIS IS 15885 (12/24/48 V Blank & 12/24‑DA2), EAC, GB19510.1 / GB19510.14; design reference EN 60335‑1; suitable for emergency lighting (EL) according to EN 61347‑2‑13 Annex J DALI Standards (DA2): IEC 62386‑101, 102, 207, 251, device type DT6 (for DA/DA2 types only) EMC Emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC Immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, 2 kV Line‑Line surge), EAC TP TC 020 MTBF (typ.): 2,626,600 h (Telcordia SR‑332, 25 °C) / 227,100 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & Protection: fully encapsulated plastic housing, IP67, Class II, Class 2, LPS Cooling Method: fanless, free air convection Information about the MEAN WELL PWM-60-24DA2 The MEAN WELL PWM‑60‑24DA2 is a 60 W constant‑voltage LED driver with 24 V DC output and high‑frequency 2.5 kHz PWM dimming, designed for DALI‑2‑controlled 24 V LED strip and module installations. The constant‑voltage PWM output ensures very uniform brightness and colour across the entire strip, which is especially beneficial for longer runs of 24 V linear lighting in visually demanding projects. Its technical strengths include a typical efficiency of around 89 %, a wide 90–305 V AC input range with active power factor correction and a fully potted IP67 housing suitable for dry, damp and wet locations. The broad case temperature range from −40 °C to +85 °C and the integrated protections against short circuit, overload, overvoltage and overtemperature allow the PWM‑60‑24DA2 to operate reliably in challenging architectural, commercial and industrial environments. A key unique characteristic of the PWM‑60‑24DA2 is the native DALI‑2 interface (DT6) on the primary side, providing addressable, group‑capable dimming and seamless integration into modern building and lighting management systems, while still delivering a pure PWM constant‑voltage output to the LEDs. Combined with its long MTBF and comprehensive safety and EMC approvals, this driver is an excellent choice for 24 V LED coves, linear accent lighting, signage and other DALI‑2‑based projects where stable low‑flicker dimming and central control are required.

Technical Information & Details on MEAN WELL PWM-90-24DA2 LED Driver Output Power: 90 W Output Voltage: 24 V DC Output Current: 3.75 A Input Voltage Range: 100 – 240 V AC, 47 – 63 Hz Efficiency: up to 90.5 % PWM Frequency: 2.5 kHz (DA2) Inrush Current: typ. 60 A @ 230 VAC No-Load Power Consumption: < 0.5 W Operating Temperature: −40 °C to +85 °C (Tcase) Cooling: passive convection Protection Functions: Hiccup mode (auto recovery) IP Rating: IP67 Isolation Voltage: IP-O/P 3.75 kV AC, IP-DA 1.5 kV AC Dimensions (L x W x H): 171 mm x 63 mm x 37.5 mm Weight: ca. 770 g Safety & EMC Certifications: UL8750, ENEC EN61347, IP67, BIS IS 15885, EAC Dimming: DALI-2 (IEC62386-101/102/207/251), Device Type 6 MTBF: > 2,394,000 hours Manufacturer Warranty: 5 Years Information on MEAN WELL PWM-90-24DA2 The MEAN WELL PWM-90-24DA2 is the advanced DALI-2 certified 90W PWM output LED driver with 2.5 kHz PWM frequency in a rugged IP67 waterproof housing for professional lighting applications. It excels with outstanding efficiency up to 90.5%, extreme temperature range -40 °C to +85 °C, over 2,394,000 hours MTBF, and 5-year manufacturer warranty. The DALI-2 compatibility with 16 groups/64 addresses, improved setup time for DALI controllers, and full bidirectional communication make it ideal for modern smart lighting systems in facade lighting, street lamps, and industrial applications with maximum precision and reliability.

Technical Information & Details on MEAN WELL PWM-120-24DA2 Power Supply Output Power: 120 W Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 100 – 240 V AC, 47 – 63 Hz Efficiency: up to 90 % PWM Frequency: 2.5 kHz Inrush Current: typ. 60 A Standby Power Consumption: < 0.5 W Operating Temperature: −40 °C to +80 °C Cooling: IP67 waterproof, natural convection Protection Functions: Short circuit (Hiccup, auto recovery), Overload, Overvoltage, Over temperature Isolation Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 191.6 mm x 63 mm x 37.5 mm Weight: approx. 0.97 kg Safety & EMC Certifications: UL8750, ENEC BS EN 61347-1/-2-13, BIS IS 15885, EAC, IP67 Dimming: DALI-2 (IEC62386-101/102/207/251, Device Type 6) Manufacturer Warranty: 5 years Information on MEAN WELL PWM-120-24DA2 The MEAN WELL PWM-120-24DA2 is a powerful 120W PWM LED driver with cutting-edge DALI-2 certification in an ultra-rugged IP67 waterproof housing, handling a wide temperature range of -40 °C to +80 °C for harsh outdoor and industrial conditions. It excels with outstanding efficiency up to 90%, ultra-low standby consumption under 0.5 W, and precise DALI-2 dimming control (16 groups, 64 addresses, synchronizable). Perfect for commercial lighting, LED projects, and emergency systems with fast fault recovery and extended lifespan over 2,240,000 hours.

Technical Information & Details on MEAN WELL PWM-90-24DA LED Driver Output Power: 90 W Output Voltage: 24 V DC Output Current: 3.75 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 90.5 % PWM Frequency: 1.47 kHz Inrush Current: typ. 60 A @ 230 VAC No-Load Power Consumption: < 0.5 W Operating Temperature: −40 °C to +85 °C (Tcase) Cooling: passive convection Protection Functions: Short circuit (Hiccup), Overload, Overvoltage, Over temperature IP Rating: IP67 Isolation Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 171 mm x 63 mm x 37.5 mm Weight: ca. 770 g Safety & EMC Certifications: UL8750, ENEC EN61347, IP67, EAC, CB Dimming: DALI (IEC62386-101/102/207/251), Device Type 6 MTBF: > 2,394,000 hours Manufacturer Warranty: 5 Years Information on MEAN WELL PWM-90-24DA The MEAN WELL PWM-90-24DA is a high-performance 90W PWM output LED driver with DALI dimming capability in a rugged IP67 waterproof housing, designed for demanding outdoor and industrial applications. It excels with outstanding efficiency up to 90.5%, an extreme temperature range from -40 °C to +85 °C, over 2,394,000 hours MTBF, and 5-year manufacturer warranty, paired with precise PWM dimming at 1.47 kHz for flicker-free lighting. Featuring a universal input voltage range, automatic recovery after faults, and full DALI compatibility including 16 groups and 64 addresses, it is ideal for professional LED lighting systems in street lighting, facades, and humid environments with maximum reliability.

Technical Information & Details on MEAN WELL PWM-120-24DA Power Supply Output Power: 120 W Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 90 % PWM Frequency: 1.47 kHz Inrush Current: typ. 60 A / 50 µs @ 230 VAC No-Load Power Consumption: < 0.5 W (Standby < 0.5 W) Operating Temperature: −40 °C to +80 °C Cooling: natural convection Protection Functions: Short circuit (Hiccup mode), Overload, Overvoltage, Over temperature Overvoltage Category: II Isolation Voltage: 3.75 kV AC between input and output; IP-DA 1.5 kV AC Dimensions (L x W x H): 191 mm x 63 mm x 37.5 mm Weight: approx. 0.97 kg Safety & EMC Certifications: UL8750, ENEC EN61347-1/-2-13, EAC, CB, IP67, BIS IS 15885, DALI Standards IEC62386-101/102/207/251 (DT6) Dimming: DALI (up to 16 groups / 64 addresses) MTBF: > 2243.7k hours (Telcordia SR-332) Manufacturer Warranty: 5 years Information on MEAN WELL PWM-120-24DA This PWM LED driver excels with its extremely wide operating range (−40 °C to +80 °C), IP67 waterproofing for outdoor use, and high efficiency up to 90 % with low no-load consumption. Unique features include DALI dimming (DT6) with synchronized multi-device control, automatic fault recovery, and superior vibration resistance for enduring performance in smart lighting systems. The MEAN WELL PWM-120-DA series is a high-performance 120 W PWM output LED driver power supply with waterproof IP67 housing and integrated DALI interface, designed for demanding outdoor and industrial applications. The PWM-120-24DA model delivers stable 24 V DC / 5 A output power with an extremely wide input voltage range of 90–305 V AC. It is ideal for DALI-controlled LED lighting, street lamps, industrial LEDs, and weather-exposed installations, backed by comprehensive certifications and a 5-year manufacturer warranty.

Innerhalb der EU nicht als LED-Treiber zugelassen! Not approved as an LED driver within the EU! Eine zugelassene Alternative ist z.B. die LPF-25-Serie Technische Eigenschaften des MEAN WELL APV-35-24 Nennleistung: 36 W AC-Spannungsbereich: 90 bis 264 VAC  Sekundärspannung: 24 VDC 300 VAC Spannungsschwankungen widerstehen Kompakte Bauform Schutzart IP42 Kühlung durch freie Luftkonvektion Schutz vor Kurzschluss, Überspannung und Überlast Informationen zum MEAN WELL APV-35-24 Mit dem APV-35-24 stellt Mean Well ein kompaktes und robustes LED-Netzgerät für Niederspannungsanlagen wie z. B. LED-Dekorationen und LED-Leuchtreklamen dar. Es verfügt über einen weltweit anwendbaren Weitbereichseingang von 90 bis 264 VAC mit Derating bei 90 und 100 VAC und erzeugt eine geregelte Nennleistung von 36 W. Ausgegeben wird eine vielfältig einsetzbare 24 VDC Konstantspannung sowie ein Ausgangsstrom von 1,5 A. Die sämtliche Mean Well APV-35-Serie ist des Weiteren widerstandsfähig gegen 300 VAC Spannungsschwankungen für bis zu fünf Sekunden. Damit ist eine stabile Stromversorgung und ein sicherer Betrieb gewährleistet. Mit der kompakten Bauweise sowie der Schutzart IP42 eignen sich die LED-Schaltnetzteile von MeanWell besonders gut für Indoor-Installationen. Die konvektionsgekühlte Produktreihe sorgt weiterhin für einen geräuscharmen Betrieb und kann einen Wirkungsgrad von bis zu 85% erreichen. Nicht zuletzt sind die APV-35-Modelle von Mean Well ausgangsseitig kurzschlussfest und bieten einen Schutz gegen Überlast sowie Überspannung. Die Produktserie erfülle dabei alle grundlegenden Sicherheits- und Störfestigkeitsstandards gemäß UL8750, EN61000-3-2, EN55035 sowie weitere Normen. Mit hoher Zuverlässigkeit sowie herausragender Kosteneffizienz ist die MeanWell APV-35-Serie die optimale Lösung für LED-Beleuchtungen mit Niederspannungen. Nur für den Einbau in Geräten, die einen anderen Primärgebrauch aufweisen als die Beleuchtung, z. B.Kopiergeräte, Overhead- und Diaprojektoren oder für Skalen- und Anzeigebeleuchtung.
