Medical Desktop Adapters

Medical Desktop Adapters need to meet special insulation requirements. User and patient safety is paramount. The implementation of Means of Protection (MOP) specified in IEC/EN 6060601-1 ensures that potential dangers are mitigated. The MOP norm sets minimum standards for the electrical insulation between the primary circuit and the protective conductor (1x MOP), as well as between the primary and secondary circuit (2x MOP). Depending on the application, the MOP requirement is differentiated into the less strict Means of Operator Protection (MOOP) and the more stringent Means of Patient Protection (MOPP). Mean Well's GSM series of Medical Desktop Power Supplies stocked by ProConnecting ensure user and patient safety through isolation according to 2x MOPP. Compact MeanWell Desktop Power Adapters provide medical devices with an output voltage between 5V and 48V via two connector options – a 4-Pin Mini-DIN connector and a coax connector. On the mains side, two choices – C8 (IEC320-C8) and C14 (IEC320-C14) plugs – are available, too. A wide input voltage range from 80V to 264V AC is supported. Mean Well’s GSM series is available on ProConnecting with a rated power of 18W to 200W.

Medical Desktop Adapters need to meet special insulation requirements. User and patient safety is paramount. The implementation of Means of Protection ( MOP ) specified in IEC/EN 6060601-1... read more »
Close window
Medical Desktop Adapters

Medical Desktop Adapters need to meet special insulation requirements. User and patient safety is paramount. The implementation of Means of Protection (MOP) specified in IEC/EN 6060601-1 ensures that potential dangers are mitigated. The MOP norm sets minimum standards for the electrical insulation between the primary circuit and the protective conductor (1x MOP), as well as between the primary and secondary circuit (2x MOP). Depending on the application, the MOP requirement is differentiated into the less strict Means of Operator Protection (MOOP) and the more stringent Means of Patient Protection (MOPP). Mean Well's GSM series of Medical Desktop Power Supplies stocked by ProConnecting ensure user and patient safety through isolation according to 2x MOPP. Compact MeanWell Desktop Power Adapters provide medical devices with an output voltage between 5V and 48V via two connector options – a 4-Pin Mini-DIN connector and a coax connector. On the mains side, two choices – C8 (IEC320-C8) and C14 (IEC320-C14) plugs – are available, too. A wide input voltage range from 80V to 264V AC is supported. Mean Well’s GSM series is available on ProConnecting with a rated power of 18W to 200W.

Top seller
GSM160A20-R7B GSM160A20-R7B
From €49.00 *
GSM40A05-P1J GSM40A05-P1J
From €17.80 *
GSM40A07-P1J GSM40A07-P1J
From €17.80 *
GSM40A09-P1J GSM40A09-P1J
From €17.80 *
GSM40A12-P1J GSM40A12-P1J
From €17.80 *
GSM40A15-P1J GSM40A15-P1J
From €17.80 *
GSM40A18-P1J GSM40A18-P1J
From €17.80 *
GSM40A24-P1J GSM40A24-P1J
From €17.80 *
Filter
Close filters
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
from to
Alle Filter anzeigen
1 From 21
No results were found for the filter!
GSM36B09-P1J
Mehr Infos

1 13,90 *
5 13,30 *
10 12,70 *
20 12,30 *
GSM36B48-P1J
Mehr Infos

1 13,90 *
5 13,30 *
10 12,70 *
20 12,30 *
GSM36B24-P1J
Mehr Infos

1 13,90 *
5 13,30 *
10 12,70 *
20 12,30 *
GSM36B18-P1J
Mehr Infos

1 13,90 *
5 13,30 *
10 12,70 *
20 12,30 *
GSM36B15-P1J
Mehr Infos

1 13,90 *
5 13,30 *
10 12,70 *
20 12,30 *
