ODLV-65-24 Auslaufmodell

Technical Information & Details of the MEAN WELL PWM-60-24 LED Driver Output power: 60 W DC output voltage: 24 V DC Rated output current: 2.5 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3‑in‑1: 0–10 VDC, 10 V PWM signal, or resistance; DA/DA2: DALI/DALI‑2) PWM output frequency: approx. 1.47 kHz (Blank/DA) / 2.5 kHz (DA2) Overvoltage protection threshold: 28 – 34 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold‑up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 89 % AC input current (typ.): 0.8 A @ 115 VAC / 0.4 A @ 230 VAC / 0.32 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output voltage, re‑power on to recover Overtemperature protection: Shut down output voltage, re‑power on to recover (DA2: hiccup mode) Short‑circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non‑condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z axes Withstand voltage: 3.75 kVAC (input–output), 1.5 kVAC (input–DA), 1.5 kVAC (output–DA) Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”, except DA), UL879 (12 V, 24 V Blank only), ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, BIS IS 15885 (Part 2/Sec 13; 12/24/48 Blank & 12/24‑DA2), EAC TP TC 004, GB19510.1, GB19510.14; IP67; suitable for emergency installations per EN 61347‑2‑13 Annex J (EL) DALI standards (DA/DA2): IEC 62386‑101/102/207/251, Device Type 6 (DT6) EMC emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,626,600 h (Telcordia SR‑332, 25 °C) / 227,100 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II/2 No‑load power consumption: < 0.5 W Design: 60 W constant‑voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-60-24 The MEAN WELL PWM‑60‑24 is a 60 W constant‑voltage LED driver with a PWM‑style output, designed to maintain brightness homogeneity when driving 24 V LED strips and other constant‑voltage LED loads. Its PWM operation at approximately 1.47 kHz (Blank/DA) or 2.5 kHz (DA2) delivers smooth, flicker‑free dimming while preserving color consistency even at low dimming levels. With typical efficiency up to around 89 %, active power factor correction and a wide 90–305 V AC input range, the driver is energy‑efficient and suitable for global installations. The fully encapsulated IP67 housing, wide −40 to +85 °C case temperature range and comprehensive protection features (short‑circuit, overload, overvoltage, overtemperature) ensure robust operation in dry, damp and wet locations, including suitability for certain emergency lighting systems under EN 61347‑2‑13. The integrated 3‑in‑1 dimming interface (0–10 V, 10 V PWM signal, resistance) in the Blank version and optional DALI/DALI‑2 control (DA/DA2 types) provide excellent flexibility for modern lighting control and building automation. Combined with long lifetime ratings and extensive international safety and EMC certifications, the PWM‑60‑24 is a strong choice for 24‑V LED strip lighting, indoor and decorative lighting, architectural lighting and industrial LED applications that require reliable constant‑voltage PWM drivers.

Technical Information & Details of the MEAN WELL PWM-40-24 LED Driver Output power: 40.08 W DC output voltage: 24 V DC Rated output current: 1.67 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3‑in‑1: 0–10 VDC, 10 V PWM signal, or resistance) PWM output frequency: approx. 1.47 kHz Overvoltage protection threshold: 28 – 34 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold‑up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 89 % AC input current (typ.): 0.6 A @ 115 VAC / 0.3 A @ 230 VAC / 0.25 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output voltage, re‑power on to recover Overtemperature protection: Shut down output voltage, re‑power on to recover Short‑circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non‑condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z axes Withstand voltage: 3.75 kVAC between input and output Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”), UL879 (12 V, 24 V), CSA C22.2 No. 250.13‑12, ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, IS 15885 (12 V, 24 V), EAC TP TC 004, GB19510.1, GB19510.14; IP67 EMC emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,625,400 h (Telcordia SR‑332, 25 °C) / 226,400 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II No‑load power consumption: < 0.5 W Design: constant‑voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-40-24 The MEAN WELL PWM‑40‑24 is a 40 W constant‑voltage LED driver with a PWM‑style output at around 1.47 kHz, designed to keep LED strip color temperature and brightness uniform throughout the entire dimming range. This makes it a strong choice for 24 V LED strips, indoor accent lighting, and architectural or decorative LED projects where visual consistency is essential. With typical efficiency up to 89 %, active power factor correction and a wide 90–305 V AC input range, the driver operates efficiently and can be deployed in worldwide installations. The fully encapsulated IP67 housing, wide −40 to +85 °C case temperature rating and comprehensive protection features (short‑circuit, overload, overvoltage and overtemperature in hiccup/shutdown mode) provide reliable operation in dry, damp and wet locations. The integrated 3‑in‑1 dimming interface (0–10 V, 10 V PWM signal, resistance) with dim‑to‑off capability offers excellent flexibility for modern control systems and building automation. Combined with extensive international safety and EMC certifications (including type “HL” for use in Class I, Division 2 hazardous locations), the PWM‑40‑24 is ideally suited for professional 24 V LED strip lighting in commercial and industrial environments.

Technical Information & Details for the MEAN WELL SLD-50-24 Power Supply Output Power: 50.4 W Output Voltage: 24 V DC Output Current: 2.1 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC Efficiency: 88 % Ripple & Noise: ≤ 240 mVp-p Inrush Current: 50 A at 230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: -20 °C to +90 °C (Tcase) Cooling: Fanless free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Isolation Class: Class 2 / II power unit Isolation Voltage: 3.75 KV AC Dimensions (L x W x H): 280 mm x 30 mm x 16.8 mm Weight: 0.175 Kg Safety & EMC Certificates: UL8750, ENEC EN61347-1, BS EN/EN62384, EAC, IS15885 Design Type: Ultra-slim linear housing Manufacturer Warranty: 3 years Information about the MEAN WELL SLD-50-24 The MEAN WELL SLD-50-24 is a high-performance 50W LED driver characterized by its ultra-slim and linear housing design, which stands at a mere 16.8mm in height. This low-profile architecture is specifically engineered for seamless integration into signage, troffer lighting, and modern linear luminaires where vertical clearance is extremely limited. The driver features a unique dual-mode output, allowing it to function effectively in both Constant Voltage and Constant Current regions, providing the versatility to drive LED strips or power modules directly. With an efficiency of 88% and a fanless design, the unit operates reliably via free air convection, maintaining stable performance even at case temperatures reaching up to 90°C. Beyond its physical aesthetics, the SLD-50-24 offers industrial-grade reliability with a wide input range of 110 to 305VAC and a built-in active PFC function to ensure high power factor quality across various loads. Safety is integrated at every level, as the unit is a Class 2 power unit and includes comprehensive protections against short circuits, over-voltage, and over-temperature. The hiccup mode protection ensures the device recovers automatically once fault conditions are removed, making it an ideal "install-and-forget" solution for commercial decoration and cove lighting. By adhering to global standards such as UL8750 and ENEC, this driver represents a secure, high-quality power solution for professional lighting designers requiring a balance of minimalist form and maximum durability.

Technical Information & Details for the MEAN WELL SLD-80-24 Power Supply Output Power: 79.2 W Output Voltage: 24 V DC Output Current: 3.3 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC, 47 – 63 Hz Efficiency: 90.5 % Ripple & Noise: ≤ 240 mVp-p Inrush Current: 50 A @ 230 VAC (Cold Start) No-load Power Consumption: < 0.5 W Operating Temperature: −20 °C to +90 °C (Case Temperature) Cooling: Fanless free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Safety Class: Class II (no FG), Class 2 power unit Isolation Voltage: 3.75 kV AC (I/P to O/P) Dimensions (L x W x H): 320 mm x 30 mm x 16.8 mm Weight: 0.206 kg Safety & EMC Certificates: UL8750, EN61347, EN62384, EAC, CB, CE Special Feature: Dual mode Constant Voltage + Constant Current output Manufacturer Warranty: 3 Years Information about the MEAN WELL SLD-80-24 The MEAN WELL SLD-80-24 is a specialized 80W AC/DC LED driver that stands out for its extraordinarily slim and linear housing. With a profile height of only 16.8 mm, it is perfectly suited for space-constrained installations such as signage, troffer lighting, and cove lighting. Its unique dual-mode output allows it to operate in either Constant Voltage or Constant Current regions, providing designers with the versatility to drive LED strips or direct LED modules within a constant current range of 16.8V to 24V without requiring additional components. Engineered for high-performance environments, the SLD-80-24 achieves a superior efficiency of 90.5% and features a built-in active PFC function for optimal power management. The unit is designed to be highly reliable, operating silently via free air convection at case temperatures up to 90°C. It supports a wide input voltage range of 110 to 305V AC, making it compatible with global industrial and commercial electrical systems. Backed by a 3-year warranty and a full array of safety protections, this power supply is a top-tier choice for professional decoration and commercial signage projects that demand a low physical footprint.

In: 180-264VAC 47-63Hz  255-373VDCOut: 24VDC / 30W / 1,25A / Eff. 86% / 76x32x48mm

In: 180-264VAC 47-63Hz  255-373VDCOut: 24VDC / 60W / 2,5A / Eff. 86% / 76x32x48mm
