LCM-60DA End of Life

Discontinued Product see replacement: LCM-40DA2

Discontinued Product see replacement LCM-25DA2

Technical Information & Details on MEAN WELL PWM-120-24DA Power Supply Output Power: 120 W Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 90 % PWM Frequency: 1.47 kHz Inrush Current: typ. 60 A / 50 µs @ 230 VAC No-Load Power Consumption: < 0.5 W (Standby < 0.5 W) Operating Temperature: −40 °C to +80 °C Cooling: natural convection Protection Functions: Short circuit (Hiccup mode), Overload, Overvoltage, Over temperature Overvoltage Category: II Isolation Voltage: 3.75 kV AC between input and output; IP-DA 1.5 kV AC Dimensions (L x W x H): 191 mm x 63 mm x 37.5 mm Weight: approx. 0.97 kg Safety & EMC Certifications: UL8750, ENEC EN61347-1/-2-13, EAC, CB, IP67, BIS IS 15885, DALI Standards IEC62386-101/102/207/251 (DT6) Dimming: DALI (up to 16 groups / 64 addresses) MTBF: > 2243.7k hours (Telcordia SR-332) Manufacturer Warranty: 5 years Information on MEAN WELL PWM-120-24DA This PWM LED driver excels with its extremely wide operating range (−40 °C to +80 °C), IP67 waterproofing for outdoor use, and high efficiency up to 90 % with low no-load consumption. Unique features include DALI dimming (DT6) with synchronized multi-device control, automatic fault recovery, and superior vibration resistance for enduring performance in smart lighting systems. The MEAN WELL PWM-120-DA series is a high-performance 120 W PWM output LED driver power supply with waterproof IP67 housing and integrated DALI interface, designed for demanding outdoor and industrial applications. The PWM-120-24DA model delivers stable 24 V DC / 5 A output power with an extremely wide input voltage range of 90–305 V AC. It is ideal for DALI-controlled LED lighting, street lamps, industrial LEDs, and weather-exposed installations, backed by comprehensive certifications and a 5-year manufacturer warranty.

Technical Information & Details for MEAN WELL LCM-40 LED Driver Output Power: 42 W Output Current: 350mA, 500mA, 600mA, 700mA (default), 900mA, 1050mA (selectable via DIP switch) Output Voltage Range: 2 – 100 V DC (depending on selected current) Input Voltage Range: 180 – 295 V AC / 254 – 417 V DC, 47 – 63 Hz Efficiency: up to 92% Auxiliary Output: 12 V / 50 mA (for fans or sensors) Inrush Current: Cold start 20A at 230 V AC No-load Power Consumption: < 1.0 W Operating Temperature: −30 °C to +90 °C (case temperature Tcase) Cooling: Fanless natural convection Protections: Short circuit, Over voltage, Over temperature Withstand Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 123.5 mm x 81.5 mm x 23 mm Weight: approx. 240 g Certifications: CE, ENEC, UL8750, CB, BIS, EAC, CCC Dimming Function: 3-in-1 dimming (0-10V DC, 10V PWM, resistance) Manufacturer Warranty: 3 years Information about the MEAN WELL LCM-40 The MEAN WELL LCM-40 is a high-performance 40W LED driver designed for maximum versatility in commercial and industrial lighting applications. Its defining feature is the multiple-stage constant current output, which allows professionals to select output currents from 350mA to 1050mA using integrated DIP switches. This flexibility ensures compatibility with a vast range of LED configurations, making it a "one-size-fits-all" solution that simplifies inventory management and technical design. With an exceptional efficiency of up to 92%, the unit ensures minimal energy loss and low heat generation during operation. Technically advanced, the LCM-40 includes a built-in 12V auxiliary DC output, perfect for powering external fans or smart sensors without the need for additional power sources. The 3-in-1 dimming interface provides seamless control via 0-10V, PWM signal, or resistance, while the synchronization capability allows up to ten drivers to be linked for uniform brightness across large lighting zones. Featuring a slim Class II plastic housing and active PFC function, this driver is the ideal choice for architectural lighting, office panels, and indoor fixtures where high reliability and superior light quality are essential requirements.

Technical Information & Details for MEAN WELL LCM-60 LED Driver Output Power: 60.3 W Output Current: 500mA, 600mA, 700mA (default), 900mA, 1050mA, 1400mA (selectable via DIP switch) Output Voltage Range: 2 – 90 V DC (depending on selected current) Input Voltage Range: 180 – 295 V AC / 254 – 417 V DC, 47 – 63 Hz Efficiency: up to 92% Auxiliary Output: 12 V / 50 mA (for fans or smart sensors) Inrush Current: Cold start 20A at 230 V AC No-load Power Consumption: < 1.0 W Operating Temperature: −30 °C to +90 °C (case temperature Tcase) Cooling: Fanless natural convection Protections: Short circuit, Over voltage, Over temperature Withstand Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 123.5 mm x 81.5 mm x 23 mm Weight: approx. 240 g Certifications: CE, ENEC, UL8750, CB, BIS, EAC, CCC Dimming Function: 3-in-1 dimming (0-10V DC, 10V PWM, resistance) Manufacturer Warranty: 3 years Information about the MEAN WELL LCM-60 The MEAN WELL LCM-60 is a high-capacity and exceptionally efficient 60W LED driver, serving as a versatile cornerstone for professional indoor lighting systems. Its most prominent feature is the multiple-stage constant current output, which can be configured via on-board DIP switches to provide current levels ranging from 500mA up to 1400mA. This extensive range allows system integrators to drive a vast array of different LED modules with a single driver model, significantly enhancing design flexibility and reducing the complexity of inventory management. With an efficiency of up to 92%, the unit ensures energy-saving operation while maintaining low thermal stress. From a technical standpoint, the LCM-60 also features a built-in 12V auxiliary DC output, ideal for powering peripheral devices such as cooling fans or IoT sensors without requiring an additional power supply. The integrated 3-in-1 dimming function enables precise light intensity control via 0-10V, PWM, or resistance, while the synchronization interface supports linking up to ten units for perfectly harmonized parallel operation. The slim Class II plastic housing and active PFC function make this driver the premier choice for panel lighting, architectural lighting designs, and commercial applications where durability and superior light quality are paramount.

Innerhalb der EU nicht als LED-Treiber zugelassen! Not approved as an LED driver within the EU! Eine zugelassene Alternative ist z.B. die LPF-25-Serie Technische Eigenschaften des MEAN WELL APC-35-500 Leistung: 35 W Eingangsbereich: 90 bis 264 VAC  Ausgangsstrom: 0,5 A 300 VAC Spannungsschwankungen widerstehen Kompakte Bauweise Schutzart IP42 im Kunststoffgehäuse Kühlung durch freie Luftkonvektion Schutz vor Kurzschluss und Überspannung EN55032, EN55035, EN61000-3-2,  EN61000-3-3 Informationen zum MEAN WELL APC-35-500 Das Mean Well APC-35-500 ist ein kompaktes und robustes LED-Schaltnetzteil mit einer konstanten Stromausgabe von 0,5 A für vielfältige LED-Beleuchtungsanlagen wie z. B. LED-Dekorationen und LED-Reklameschilder. Am Eingang verfügt dieses Netzteil über einen weiten AC-Spannungsbereich von 90 bis 264 V (Derating bei 90 - 100 VAC) und erzeugt zudem eine geregelte Nennleistung von 35 W. Die Produktreihe von MeanWell ist weiterhin widerstandsfähig gegen 300 VAC Spannungsschwankungen für bis zu fünf Sekunden. Eine stabile Stromversorgung beim Betrieb ist so sichergestellt. Neben der Widerstandsfähigkeit zeichnen sich die Mean Well APC-35-Netzgeräte durch die kompakte und geschlossene Bauform sowie ein Design nach Schutzart IP42 aus. Damit ist die Produktserie für den ausreichenden Einsatz in verschiedensten Indoor-Bereichen gut geeignet. Darüber hinaus kann die konvektionsgekühlte MeanWell APC-35-Serie mit der lüfterlosen Konstruktion einen energieeffizienten und geräuscharmen Betrieb gewährleisten. Dabei können die LED-Netzteile der Reihe einen Wirkungsgrad von bis zu 84% erreichen. Ausgangsseitig bietet die Mean Well APC-35-Serie die Schutzmaßnahmen gegen Kurzschluss sowie Überlast. Die LED-Netzteile sind zudem konform mit den grundlegenden Sicherheitsstandards nach EN55032, EN55035, EN61000-3-2,  EN61000-3-3 sowie weiteren Normen im LED-Beleuchtungssektor. Mit hoher Zuverlässigkeit sowie herausragender Kosteneffizienz ist die Produktreihe von MeanWell die optimale Lösung für LED-Anwendungen mit kleiner Leistung. Nur für den Einbau in Geräten, die einen anderen Primärgebrauch aufweisen als die Beleuchtung, z. B.Kopiergeräte, Overhead- und Diaprojektoren oder für Skalen- und Anzeigebeleuchtung.
