PLC-60-48

30W LED Schaltnetzteile 30W  Single Output LED Power Supply

60W Einzelausgang Feuchtigkeitsbeständiger Netzteile 60W Single Output Moistureproof Adaptor

Attention! Price & Delivery time avaliable on request! Minimum order quantity: 200 or more Technical Information & Details for MEAN WELL HLG-240H-48C Power Supply Output Power: 240 W Output Voltage: 48 V DC Voltage Adj. Range: 44 V – 53 V (via internal potentiometer) Rated Current: 5 A Current Adj. Range: 2.5 A – 5 A (via internal potentiometer) Connection Type: Terminal block for I/O connection Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: 94 % Ripple & Noise: max. 250 mVp-p Operating Temperature: −40 °C to +90 °C (case temperature) Cooling: Fanless design by free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Dimensions (L x W x H): 251 mm x 68 mm x 38.8 mm Safety Certificates: UL8750, EN61347-1, EN55015, Type HL Manufacturer Warranty: 7 years Information about the MEAN WELL HLG-240H-48C The MEAN WELL HLG-240H-48C is a premium 240W LED driver optimized for 48V power architectures requiring modular and direct wiring. This C-type variant features a practical terminal block interface, making it the perfect choice for installation within industrial control cabinets or professional luminaire housings where fixed cable lengths are impractical. The driver utilizes a sophisticated dual-mode constant voltage and constant current output strategy, ensuring high electrical stability and protection for sensitive 48V LED modules. With built-in potentiometers, installers can manually fine-tune the output voltage and current levels for precise site-specific adjustments. Its rugged metal housing combined with a fanless thermal design allows for silent and reliable operation even at extreme temperatures up to +90 °C. The Type HL rating qualifies the unit for use in Class I, Division 2 hazardous locations, such as industrial refineries or chemical plants. Backed by an industry-leading 7-year manufacturer warranty, the HLG-240H-48C stands as a robust, maintenance-free solution for large-scale commercial and infrastructure projects.

Technical Information & Details for MEAN WELL HLG-185H-48B Power Supply Output Power: 187.2 W Output Voltage: 48 V DC Output Current: 3.9 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 94% Dimming Function: 3-in-1 dimming (1–10V DC, 10V PWM signal, resistance) Ripple & Noise: ≤ 200 mVp-p Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC Operating Temperature: −40 °C to +90 °C (Case Temperature) Cooling: Fanless natural convection Protections: Short Circuit, Over Current, Over Voltage, Over Temperature IP Rating: IP67 (Fully dust-tight and waterproof) Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm Weight: approx. 1150 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP67, EAC, CE Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-185H-48B The MEAN WELL HLG-185H-48B is a high-performance 185W AC/DC LED driver, meticulously engineered for industrial-grade longevity and intelligent lighting control. The standout feature of this "B-Type" model is its integrated 3-in-1 dimming interface, allowing the constant current output to be precisely adjusted via 1–10VDC, a 10V PWM signal, or external resistance. Built with a rugged metal housing and a full IP67 ingress protection rating, this driver is completely immune to dust and water immersion, making it the premier choice for harsh environment applications such as LED street lighting, high-bay lamps, and professional greenhouse lighting systems. It operates using a dual-mode constant voltage and constant current output, providing maximum flexibility for various LED strip or module configurations. Achieving a peak efficiency of 94%, the unit minimizes energy waste and thermal stress, enabling reliable fanless operation at case temperatures from -40 °C to +90 °C. Backed by an industry-leading 7-year manufacturer warranty and a typical life expectancy of over 62,000 hours, the HLG-185H-48B ensures significant reductions in maintenance costs and exceptional long-term performance for large-scale infrastructure projects.

Technical Information & Details for MEAN WELL HLG-185H-48AB Power Supply Output Power: 187.2 W Output Voltage: 48 V DC Output Current: 3.9 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 94% Voltage Adj. Range (Vo ADJ): 43 – 53 V (via internal potentiometer) Current Adj. Range (Io ADJ): 1.95 – 3.9 A (via internal potentiometer) Dimming Function: 3-in-1 dimming (1–10V DC, 10V PWM signal, resistance) Ripple & Noise: ≤ 200 mVp-p Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC Operating Temperature: −40 °C to +90 °C (Case Temperature) Cooling: Fanless natural convection Protections: Short Circuit, Over Current, Over Voltage, Over Temperature IP Rating: IP65 (Dust-tight and protected against water jets) Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm Weight: approx. 1150 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP65, EAC, CE Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-185H-48AB The MEAN WELL HLG-185H-48AB represents the ultimate flexibility in the 185W HLG series by combining internal manual tuning with external intelligent dimming. As an "AB-Type" model, it empowers professional installers to fine-tune the output voltage and current levels via built-in potentiometers while simultaneously supporting a versatile 3-in-1 dimming interface compatible with 1-10VDC, PWM signals, or external resistance. This hybrid design is ideal for sophisticated LED installations that require a precise static setup alongside dynamic brightness adjustment. The durable IP65-rated metal housing ensures high resistance to dust and water, making it perfect for outdoor and industrial environments such as LED street lights, high-bay lighting, and professional greenhouse systems. Featuring dual-mode constant voltage and constant current output, the driver reaches an exceptional efficiency of 94%. Its fanless cooling design allows for reliable operation across a broad temperature range of -40 °C to +90 °C. Backed by a 7-year manufacturer warranty and a typical life expectancy of over 62,000 hours, the HLG-185H-48AB is a top-tier choice for sustainable, long-term architectural and infrastructure projects.
