PLC-30-48

60W LED Schaltnetzteile 60W  Single Output LED Power Supply

Technical Information & Details for the MEAN WELL OWA-60E-48 Power Supply Rated Power: 60 W Output Voltage: 48 V DC Rated Current: 1.25 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: 89 % Ripple & Noise: ≤ 350 mVp-p Inrush Current: max. 65 A at 230 V AC No Load Power Consumption: < 0.15 W Working Temperature: −35 °C to +70 °C Cooling: Fanless free air convection Protections: Short circuit, Overload, Over voltage, Over temperature Withstand Voltage: I/O-P: 3.75 kV AC Dimensions (L x W x H): 130 mm x 53 mm x 35 mm Weight: Approx. 0.41 kg Safety & EMC Standards: EN 61558-1, EN 61558-2-16, EAC, CE Special Feature: Fully potted plastic enclosure Manufacturer Warranty: 5 years Information about the MEAN WELL OWA-60E-48 Engineered precisely for high-humidity and dusty operational environments, this external power unit provides a robust solution for sensitive electronic and telecommunication setups. Delivering a steady rated power of 60 W paired with an efficient 48 V DC output, the hardware meets stringent commercial demands with ease. Complete silicone potting encased inside a sturdy plastic housing enhances thermal dissipation significantly while offering total physical sealing against environmental elements. Furthermore, minimal no-load power consumption complies effortlessly with modern ecological guidelines. Achieving a high ingress protection rating of IP67 for the power body, the device ensures absolute resistance against water jets, rain, and heavy dust accumulation. Such rugged design characteristics make it an optimal choice for outdoor industrial installations and exposed electronic equipment. In addition, a wide working temperature span from −35 °C to +70 °C guarantees reliable performance under freezing winter conditions or scorching summer heat. Built-in electronic protection features automatically guard against short circuits, overloads, and overvoltages. Compliance with major international safety regulations streamlines the integration process for device manufacturers and system integrators alike. Built as a Class II unit without a functional ground connection, it simplifies electrical wiring while maintaining excellent isolation standards. High vibration resistance up to 5G and exceptional MTBF reliability ratings secure long-term mechanical stability in challenging locations. Optional quick-adapter DC plugs offer broad flexibility for diverse terminal connections. Operating completely silently through natural free air convection without moving parts, the hardware assures an entirely maintenance-free operational cycle. Advanced internal circuitry minimizes power losses and maintains high conversion efficiency over prolonged use. Combining moistureproofing, high voltage stability, and rugged construction, this model represents an ideal power conversion choice.

Attention! Price & Delivery time avaliable on request! Minimum order quantity: 200 or more Technical Information & Details for MEAN WELL HLG-240H-48C Power Supply Output Power: 240 W Output Voltage: 48 V DC Voltage Adj. Range: 44 V – 53 V (via internal potentiometer) Rated Current: 5 A Current Adj. Range: 2.5 A – 5 A (via internal potentiometer) Connection Type: Terminal block for I/O connection Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: 94 % Ripple & Noise: max. 250 mVp-p Operating Temperature: −40 °C to +90 °C (case temperature) Cooling: Fanless design by free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Dimensions (L x W x H): 251 mm x 68 mm x 38.8 mm Safety Certificates: UL8750, EN61347-1, EN55015, Type HL Manufacturer Warranty: 7 years Information about the MEAN WELL HLG-240H-48C The MEAN WELL HLG-240H-48C is a premium 240W LED driver optimized for 48V power architectures requiring modular and direct wiring. This C-type variant features a practical terminal block interface, making it the perfect choice for installation within industrial control cabinets or professional luminaire housings where fixed cable lengths are impractical. The driver utilizes a sophisticated dual-mode constant voltage and constant current output strategy, ensuring high electrical stability and protection for sensitive 48V LED modules. With built-in potentiometers, installers can manually fine-tune the output voltage and current levels for precise site-specific adjustments. Its rugged metal housing combined with a fanless thermal design allows for silent and reliable operation even at extreme temperatures up to +90 °C. The Type HL rating qualifies the unit for use in Class I, Division 2 hazardous locations, such as industrial refineries or chemical plants. Backed by an industry-leading 7-year manufacturer warranty, the HLG-240H-48C stands as a robust, maintenance-free solution for large-scale commercial and infrastructure projects.

Technical Information & Details for MEAN WELL HLG-185H-48B Power Supply Output Power: 187.2 W Output Voltage: 48 V DC Output Current: 3.9 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 94% Dimming Function: 3-in-1 dimming (1–10V DC, 10V PWM signal, resistance) Ripple & Noise: ≤ 200 mVp-p Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC Operating Temperature: −40 °C to +90 °C (Case Temperature) Cooling: Fanless natural convection Protections: Short Circuit, Over Current, Over Voltage, Over Temperature IP Rating: IP67 (Fully dust-tight and waterproof) Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm Weight: approx. 1150 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP67, EAC, CE Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-185H-48B The MEAN WELL HLG-185H-48B is a high-performance 185W AC/DC LED driver, meticulously engineered for industrial-grade longevity and intelligent lighting control. The standout feature of this "B-Type" model is its integrated 3-in-1 dimming interface, allowing the constant current output to be precisely adjusted via 1–10VDC, a 10V PWM signal, or external resistance. Built with a rugged metal housing and a full IP67 ingress protection rating, this driver is completely immune to dust and water immersion, making it the premier choice for harsh environment applications such as LED street lighting, high-bay lamps, and professional greenhouse lighting systems. It operates using a dual-mode constant voltage and constant current output, providing maximum flexibility for various LED strip or module configurations. Achieving a peak efficiency of 94%, the unit minimizes energy waste and thermal stress, enabling reliable fanless operation at case temperatures from -40 °C to +90 °C. Backed by an industry-leading 7-year manufacturer warranty and a typical life expectancy of over 62,000 hours, the HLG-185H-48B ensures significant reductions in maintenance costs and exceptional long-term performance for large-scale infrastructure projects.
