ODLV-45A-12 Auslaufmodell

Technical Information & Details of the MEAN WELL PWM-60-12 LED Driver Output power: 60 W DC output voltage: 12 V DC Rated output current: 5 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3‑in‑1: 0–10 VDC, 10 V PWM signal, or resistance; DA/DA2: DALI/DALI‑2) PWM output frequency: approx. 1.47 kHz (Blank/DA) / 2.5 kHz (DA2) Overvoltage protection threshold: 15 – 17 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold‑up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 86 % AC input current (typ.): 0.8 A @ 115 VAC / 0.4 A @ 230 VAC / 0.32 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output voltage, re‑power on to recover Overtemperature protection: Shut down output voltage, re‑power on to recover (DA2: hiccup mode) Short‑circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non‑condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z axes Withstand voltage: 3.75 kVAC (input–output), 1.5 kVAC (input–DA), 1.5 kVAC (output–DA) Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”, except DA), UL879 (12 V, 24 V Blank only), ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, BIS IS 15885 (Part 2/Sec 13; 12/24/48 Blank & 12/24‑DA2), EAC TP TC 004, GB19510.1, GB19510.14; IP67; suitable for emergency lighting per EN 61347‑2‑13 Annex J DALI standards (DA/DA2): IEC 62386‑101/102/207/251, Device Type 6 (DT6) EMC emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,626,600 h (Telcordia SR‑332, 25 °C) / 227,100 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II/2 No‑load power consumption: < 0.5 W Design: 60 W constant‑voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-60-12 The MEAN WELL PWM‑60‑12 is a 60 W constant‑voltage LED driver with a PWM‑style output, engineered to maintain brightness homogeneity when driving 12 V LED strips and other constant‑voltage LED loads. Its PWM operation at around 1.47 kHz (Blank/DA) or 2.5 kHz (DA2) ensures smooth dimming while preserving color consistency and avoiding visible flicker across the entire dimming range. Featuring typical efficiency around 86 %, active PFC and a wide 90–305 V AC input range, the driver is highly energy‑efficient and suitable for global use. The IP67 fully encapsulated housing, broad −40 to +85 °C case temperature rating and extensive protection set (short‑circuit, overload, overvoltage, overtemperature) make the PWM‑60‑12 robust enough for dry, damp and wet locations, including certain emergency lighting applications under IEC 61347‑2‑13. With its 3‑in‑1 dimming interface (0–10 V, 10 V PWM signal, resistance) on the Blank version and optional DALI/DALI‑2 control (DA/DA2 types), the PWM‑60‑12 offers strong integration flexibility for modern lighting control systems and building automation. Combined with long lifetime ratings and comprehensive international safety and EMC approvals, it is well suited to professional LED strip lighting, indoor LED lighting, decorative installations, architectural lighting and industrial projects that require reliable 12 V constant‑voltage PWM drivers.

Technical Information & Details of the MEAN WELL PWM-40-12 LED Driver Output power: 40.08 W DC output voltage: 12 V DC Rated output current: 3.34 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3-in-1: 0–10 VDC, 10 V PWM signal, or resistance) PWM output frequency: approx. 1.47 kHz Overvoltage protection threshold: 15 – 17 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold-up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 86 % AC input current (typ.): 0.6 A @ 115 VAC / 0.3 A @ 230 VAC / 0.25 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output, re-power on to recover Overtemperature protection: Shut down output, re-power on to recover Short-circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non-condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z Withstand voltage: 3.75 kVAC between input and output Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”), UL879 (12 V, 24 V), CSA C22.2 No. 250.13-12, ENEC EN 61347-1, EN 61347-2-13 (independent), EN 62384, IS 15885 (12 V, 24 V), EAC TP TC 004, GB19510.1, GB19510.14; IP67 EMC emission: EN 55015, EN 61000-3-2 Class C (≥60 % load), EN 61000-3-3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000-4-2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,625,400 h (Telcordia SR-332, 25 °C) / 226,400 h (MIL-HDBK-217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II No-load power consumption: < 0.5 W Design: constant-voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-40-12 The MEAN WELL PWM-40-12 is a 40 W constant-voltage LED driver with a PWM-style output at around 1.47 kHz, designed to keep LED color temperature and brightness uniform across the entire dimming range. This makes it particularly well suited for LED strip lighting, indoor accent lighting, and architectural or decorative LED installations where visual consistency is critical. With typical efficiency up to 86 %, active PFC, and a wide 90–305 V AC input range, the driver delivers energy-efficient performance and can be used worldwide. The fully encapsulated IP67 housing, wide −40 to +85 °C case temperature capability, and comprehensive protection functions (short-circuit, overload, overvoltage, overtemperature in hiccup/shutdown mode) ensure reliable operation in dry, damp, or wet locations. The integrated 3-in-1 dimming interface (0–10 V, 10 V PWM, resistance) with dim-to-off support gives excellent flexibility for modern control systems and building automation. Combined with broad international safety and EMC approvals (including type “HL” for use in Class I, Division 2 hazardous locations), the PWM-40-12 is an ideal choice for professional LED strip projects and demanding commercial or industrial lighting applications.

Technical Information & Details for the MEAN WELL SLD-50-12 Power Supply Output Power: 50.4 W Output Voltage: 12 V DC Output Current: 4.2 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC, 47 – 63 Hz Efficiency: 90 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 50 A @ 230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: -20 °C to +90 °C (Tcase) Cooling: Fanless natural convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Isolation Class: Class II (no FG) Isolation Voltage: 3.75 KV AC between input and output Dimensions (L x W x H): 280 mm x 30 mm x 16.8 mm Weight: approx. 175 g Safety & EMC Certificates: UL8750, ENEC EN61347, BS EN/EN55015, CB, EAC, CE Design Type: Ultra-slim linear housing Manufacturer Warranty: 3 years Information about the MEAN WELL SLD-50-12 The MEAN WELL SLD-50-12 stands out as a high-performance 50W LED driver specifically engineered with an ultra-slim and linear housing design. This low-profile architecture makes it the premier choice for integration into space-constrained environments such as signage, cove lighting, and modern linear luminaires. Operating with a dual-mode Constant Voltage and Constant Current output, this power supply provides exceptional flexibility for driving LEDs either directly or through additional DC/DC drivers. Its robust design ensures a high efficiency of 90%, allowing the unit to operate reliably under free air convection without the need for active cooling fans, which significantly extends the system's overall lifespan and silent operation. Safety and versatility are core strengths of the SLD-50 series, featuring a wide input range of 110 to 305VAC and full PFC functionality to ensure compliance with global energy regulations. The unit is classified as a Class 2 power unit and meets stringent BS EN/EN61347 standards, providing a secure foundation for decorative and commercial lighting applications. With built-in hiccup mode protection for short circuits and automatic recovery features, the SLD-50-12 offers a "fit-and-forget" solution for professionals seeking a balance between compact aesthetics and industrial-grade reliability. This driver is particularly optimized for panel lighting and strip lighting where maintaining a sleek profile is just as critical as consistent power delivery.

Technical Information & Details for the MEAN WELL SLD-80-12 Power Supply Output Power: 79.2 W Output Voltage: 12 V DC Output Current: 6.6 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC, 47 – 63 Hz Efficiency: up to 90.5 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 50 A @230 VAC (Cold Start) No-load Power Consumption: < 0.5 W Operating Temperature: −20 °C to +90 °C (Case Temperature) Cooling: Fanless free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Overvoltage Category: Class II (without FG) Isolation Voltage: 3750 V AC between Input and Output Dimensions (L x W x H): 320 mm x 30 mm x 16.8 mm Weight: approx. 206 g Safety & EMC Certificates: UL8750, EN61347, EN62384, EAC, CB, CE Special Feature: Ultra-slim linear housing design Manufacturer Warranty: 3 Years Information about the MEAN WELL SLD-80-12 The MEAN WELL SLD-80-12 is an 80W AC/DC LED driver engineered specifically for applications where space is at a premium. Its ultra-low profile linear design, featuring a height of only 16.8 mm, makes it the ideal choice for signage, troffer lighting, and cove lighting applications. This model is unique due to its dual-mode output, providing both Constant Voltage and Constant Current capabilities, which allows it to drive LED modules directly or work alongside additional DC/DC drivers for maximum versatility in lighting system design. This power supply stands out for its high efficiency of up to 90.5% and its robust fanless design, which ensures silent and reliable operation even at case temperatures as high as 90°C. Equipped with a wide input range of 110 to 305V AC and built-in active PFC function, it complies with global lighting regulations and minimizes harmonic distortion. With a focus on long-term reliability, the SLD-80-12 includes a full suite of protection features and a 3-year warranty, providing a dependable solution for decorative, commercial, and industrial lighting projects that require a slim form factor without compromising on power performance.

In: 180-264VAC 47-63Hz  255-373VDCOut: 12VDC / 30W / 2,5A / Eff. 83% / 76x32x48mm

In: 180-264VAC 47-63Hz  255-373VDCOut: 12VDC / 50W / 4,16A / Eff. 85% / 76x32x48mm
