PCD-60-500B

40W AC Dimmbar LED Netzteile 40W Single Output AC Dimmable LED Power Supply

16W AC Dimmbar LED Netzteile 16W Single Output AC Dimmable LED Power Supply

40W AC Dimmbar LED Netzteile 40W Single Output AC Dimmable LED Power Supply

25W AC Dimmbar LED Netzteile 25W Single Output AC Dimmable LED Power Supply

Discontinued Model Technical Information & Details for the LS-40V24-D1 Power Supply Output Power: 40 W (10 – 40 W) Output Voltage: 24 V DC Output Current: 0.41 – 1.67 A Input Voltage Range: 176 – 264 V AC (Nominal 220 – 240 V AC), 50/60 Hz Efficiency: ≥ 87% Power Factor: ≥ 0.9 @ 220–240 VAC Inrush Current: 20 A No-Load Power Consumption: ≤ 1 W Dimming: TRIAC (Leading-edge & Trailing-edge) & PWM, Dimming range 10 – 100% Operating Temperature: −10 °C to +50 °C (tc max. 85 °C) IP Rating: IP20 Protections: Short circuit, Overload (105–150%), Overvoltage (> 25.2 V DC), Overtemperature Connection Type: Screw terminal (0.75 – 1.5 mm²) Dimensions (L x W x H): 156 mm x 49.5 mm x 33 mm Installation: Independent installation Safety & EMC Certificates: CE, Class II, EN 61347-1, EN 61347-2-13, EN 55015, RoHS Lifetime: > 30,000 hours (@ 50 °C) Information about the LS-40V24-D1 Delivering up to 40 W across a stable 24 V DC output rail, the HuaTec LS-40V24-D1 driver serves as an energy-efficient power solution engineered specifically for modern LED installations. Supporting dual TRIAC (leading & trailing edge) and PWM dimming, it enables smooth control across a 10–100% range while maintaining an outstanding efficiency of ≥ 87% during operation. Its compact housing is built to IP20 protection specifications for standalone installation, incorporating user-friendly screw terminals designed for 0.75–1.5 mm² wiring. Complete with automated protection mechanisms against short circuits, line surges, and excessive temperatures, it ensures safe performance across demanding lighting setups.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-25 series. Technical Information & Details of the MEAN WELL LPV-35-24 Power Supply Output Power: 36 W Output Voltage: 24 V DC Output Current: 1.5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 85 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 55 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +75 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 30 mm x 40 mm x 148 mm Weight: approx. 340 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-35-24 The MEAN WELL LPV-35-24 is a compact LED power supply with 36 W and stable 24 V DC / 1.5 A output voltage. It excels with excellent efficiency up to 85 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, camera systems, decorative applications, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-35-24 offers maximum flexibility, durability, and weatherproof protection in demanding environments.
