Technical Information & Details for the MEAN WELL PCD-40-350B Power Supply
- Rated Power: 37.8 W
- Output Voltage: 45 – 80 V DC
- Rated Current: 350 mA
- Input Voltage Range: 180 – 295 V AC, 47 – 63 Hz
- Efficiency: up to 87 %
- Ripple & Noise: ≤ 9.5 Vp-p
- Inrush Current: Cold start 11 A at 230 V AC
- No Load Output Voltage: 118 V max.
- Working Temperature: −30 °C to +50 °C
- Cooling: Free air convection
- Protections: Short circuit, over temperature
- Withstand Voltage: 3.75 kV AC I/P-O/P
- Dimensions (L x W x H): 128 mm x 60 mm x 31.5 mm
- Weight: approx. 0.23 kg
- Safety & EMC Standards: ENEC BS EN/EN61347-1, BS EN/EN61347-2-13, CE, EAC
- Enclosure Rating: IP42
- Warranty: 3 years
Information about the MEAN WELL PCD-40-350B
Built specifically to satisfy the rigorous demands of commercial illumination projects, this unit delivers exceptional electrical stability. Professional lighting engineers rely on its constant-current output to drive LED fixtures safely and efficiently without performance degradation. Every component is optimized to withstand continuous daily operation in challenging environments.
Versatility is greatly enhanced by the advanced AC phase-cut dimming capability, which ensures seamless compatibility with standard leading and trailing-edge TRIAC dimmers. This allows for fluid lighting control across various architectural settings. Furthermore, an active power factor correction circuit keeps energy consumption optimized and grid harmonics under strict control.
Encapsulated in a fully isolated plastic housing featuring an IP42 ingress protection rating, the hardware remains shielded against environmental particles. Thermal management relies entirely on natural convection cooling, removing the need for noisy internal fans and maximizing mechanical longevity. The streamlined footprint fits smoothly into confined mounting spaces.
Backed by extensive full-load burn-in testing and official ENEC safety approvals, this power supply provides long-term reliability supported by a dependable 3 years warranty. It stands out as an optimal core component for display, decorative, and commercial lighting layouts.
