PLD-25-350

25W AC Dimmbar LED Netzteile 25W Single Output AC Dimmable LED Power Supply

Abgekündigt! Siehe Nachfolgemodell KVF-12060-TDH Technische Eigenschaften des SC Power KV-12060-TD: Leistung: 60W Spannung: 12V Ausgangsstrom: 5000mA Konstantspannungsausgang Eingangsbereich: 180-240VAC Arbeitseffizienz: bis zu 81% TRIAC Dimmer: Phasenanschnittsdimmung/ Phase Cut Einfache Installation IP66 Design; Geeignet für Outdoor-Installationen Kühlung durch freie Luftkonvektion Schutz vor Kurzschluss, Überlast, Überstrom und Überhitzung Eingebaute PFC Funktion Perfekte Kompatibilität; Flimmerfreie Dimmung Geeignet für LED-Beleuchtungssysteme und Displayanzeigen

40W AC Dimmbar LED Netzteile 40W Single Output AC Dimmable LED Power Supply

End of Life Product!! see LCM - 25/40/60

40W LED Schaltnetzteile 40W  Single Output LED Power Supply

Technical Information & Details for the MEAN WELL ELG-75-12DA Power Supply Output Power: 60 W Output Voltage: 12 V DC Output Current: 5 A Constant Current Region: 6 – 12 V DC Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz Efficiency: up to 86 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 50 A @ 230 VAC No Load Power Consumption: < 0.5 W Operating Temperature: −40 °C to +85 °C (Case Temperature) Cooling: fanless natural convection Protections: Short circuit, Over current, Over voltage, Over temperature (auto recovery) Isolation Voltage: 3750 V AC between Input and Output Ingress Protection: IP65 metal housing Dimensions (L x W x H): 180 mm x 63 mm x 35.5 mm Weight: approx. 800 g Safety & EMC Certificates: UL8750, EN61347, IEC62386, CE, EAC, KC Special Features: DALI-2 interface, IEC62386-101/102/207 compliant, digital addressable Manufacturer Warranty: 5 Years Information about the MEAN WELL ELG-75-12DA The MEAN WELL ELG-75-12DA is a cutting-edge DALI-2 certified LED driver designed for the most advanced smart lighting ecosystems, delivering precise 60W constant voltage/current output at 12V DC / 5A with full digital controllability. As a dedicated "DA-Type" model, it features a robust DALI-2 interface compliant with IEC62386 standards (101, 102, 207), supporting up to 16 groups and 64 unique addresses for seamless integration into centralized lighting management systems. Its rugged IP65-rated metal housing combined with an expansive 100-305V AC input range and extreme thermal resilience from -40°C to +85°C case temperature make it exceptionally suited for commercial buildings, office spaces, hotels, and large-scale architectural installations requiring network-addressable control and high reliability. The standout strength of the ELG-75-12DA power supply lies in its intelligent, future-proof digital protocol support that enables sophisticated functions like group dimming, scene setting, and broadcast commands without complex wiring. With an optimized 86% efficiency, minimal no-load power under 0.5W, and active PFC for superior power quality, it minimizes energy waste while delivering rock-solid performance backed by comprehensive auto-recovery protections against short circuits, overcurrent, overvoltage, and overtemperature. Fully adhering to stringent global safety and EMC norms, this driver offers a typical lifespan exceeding 50,000 hours and is protected by MEAN WELL's comprehensive 5-year manufacturer warranty, positioning it as the premium choice for scalable, IoT-ready LED lighting networks in modern smart environments.
