ELG-75-C1050A-3Y

Product information "ELG-75-C1050A-3Y"

Technische Informationen & Details zum MEAN WELL ELG-75-C1050A-3Y Netzteil

  • Ausgangsleistung: 74,9 W
  • Konstantstrom-Bereich: 107 – 214 V
  • Ausgangsstrom: 1050 mA
  • Eingangsspannungsbereich: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
  • Wirkungsgrad: bis 90 %
  • Leistungsfaktor (PF): PF ≥ 0,97 bei 115 V AC / PF ≥ 0,95 bei 230 V AC
  • Einschaltstrom: Kaltstart 50 A bei 230 V AC
  • Standby-Leistungsaufnahme: < 0,5 W
  • Arbeitstemperatur (Gehäuse): Tcase −40 °C bis +85 °C
  • Kühlung: lüfterlos durch freie Luftkonvektion
  • Schutzfunktionen: Kurzschluss, Überlast, Überspannung, Übertemperatur
  • Schutzart: IP65 (integriertes Potentiometer)
  • Isolationsspannung (Prüfspannung): I/P-O/P 3,75 kV AC
  • Maße (L x B x H): 180 mm x 63 mm x 35,5 mm
  • Gewicht: ca. 800 g
  • Sicherheits- & EMV-Normen: UL8750 (Typ HL), CSA C22.2, EN61347-1, EAC, CE
  • Anschlussart: 3-adriger Eingang (3Y) mit Schutzleiter (PE)
  • Herstellergarantie: 5 Jahre

Informationen zum MEAN WELL ELG-75-C1050A-3Y

Engineered for professional lighting installations, the MEAN WELL ELG-75-C1050A-3Y constant current driver delivers exceptional performance in demanding outdoor environments. Featuring a rugged metal enclosure with an IP65 ingress protection rating, this power supply effectively resists dust and water jets while supporting flexible output adjustments via its built-in potentiometer. Thermal management is exceptionally robust, engineered to function smoothly under extreme case temperatures reaching up to +85 °C without requiring mechanical fans. System reliability is further elevated through comprehensive electronic safeguards and compliance with strict international safety standards including UL8750 Type HL certifications. Backed by an industry-leading 5 years manufacturer warranty, this driver ensures long-term operational stability for architectural, street, and industrial LED lighting arrays.


Verfügbare Downloads
Download ELG-75-C Datenblatt
Eigenschaften für "ELG-75-C1050A-3Y"
Approval: CB, CCC, CE, ENEC, MM, SELV, TÜV, UL
Constant current: 1050 mA
Efficiency: 90%
Height: 35,5
Length: 180
Protection Class: Class I
Protection Rating: IP65
Rated current: 1,05
Series: ELG
Warranty: 5 years
Wattage: 75 W
Weight: 0,8kg
Width: 63
