SGA40E12-P1J

Technical Information & Details on MEAN WELL HLG-60H-24A Power Supply Output Power: 60 W Output Voltage: 24 V DC (adjustable 22 – 27 V) Output Current: 2.5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 89.5 % Ripple & Noise: ≤ 200 mVp-p Inrush Current: typ. 55 A / 26 µs @ 230 VAC No-Load Power Consumption: < 0.75 W Operating Temperature: −40 °C to +80 °C (case temperature) Cooling: fanless natural convection Protection Functions: Short circuit (Hiccup, auto recovery), Overload, Overvoltage, Overtemperature Overvoltage Category: II Isolation Voltage: 3.75 kV AC between input and output Dimensions (H x W x D): 171 mm x 61.5 mm x 36.8 mm Weight: ca. 730 g Safety & EMC Certifications: UL8750, CB, CE, TÜV, EAC, IP65 Manufacturer Warranty: 7 Years Information on MEAN WELL HLG-60H-24A The MEAN WELL HLG-60H-24A offers adjustable flexibility in a professional 60 W LED driver power supply featuring outstanding efficiency up to 89.5 % and −40 °C to +80 °C operating temperature for demanding applications. It delivers fine-tuned 22–27 V DC / 2.5 A via built-in potentiometer in constant voltage and constant current modes (14.4–24 V CC range) with IP65 protection for dust and moisture-resistant installations. Rugged aluminum housing, Class 2 certification, and active PFC ensure optimal customization and maximum reliability for LED panel lighting and industrial systems.

Technical Information & Details of the MEAN WELL PWM-40-24 LED Driver Output power: 40.08 W DC output voltage: 24 V DC Rated output current: 1.67 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3‑in‑1: 0–10 VDC, 10 V PWM signal, or resistance) PWM output frequency: approx. 1.47 kHz Overvoltage protection threshold: 28 – 34 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold‑up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 89 % AC input current (typ.): 0.6 A @ 115 VAC / 0.3 A @ 230 VAC / 0.25 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output voltage, re‑power on to recover Overtemperature protection: Shut down output voltage, re‑power on to recover Short‑circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non‑condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z axes Withstand voltage: 3.75 kVAC between input and output Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”), UL879 (12 V, 24 V), CSA C22.2 No. 250.13‑12, ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, IS 15885 (12 V, 24 V), EAC TP TC 004, GB19510.1, GB19510.14; IP67 EMC emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,625,400 h (Telcordia SR‑332, 25 °C) / 226,400 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II No‑load power consumption: < 0.5 W Design: constant‑voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-40-24 The MEAN WELL PWM‑40‑24 is a 40 W constant‑voltage LED driver with a PWM‑style output at around 1.47 kHz, designed to keep LED strip color temperature and brightness uniform throughout the entire dimming range. This makes it a strong choice for 24 V LED strips, indoor accent lighting, and architectural or decorative LED projects where visual consistency is essential. With typical efficiency up to 89 %, active power factor correction and a wide 90–305 V AC input range, the driver operates efficiently and can be deployed in worldwide installations. The fully encapsulated IP67 housing, wide −40 to +85 °C case temperature rating and comprehensive protection features (short‑circuit, overload, overvoltage and overtemperature in hiccup/shutdown mode) provide reliable operation in dry, damp and wet locations. The integrated 3‑in‑1 dimming interface (0–10 V, 10 V PWM signal, resistance) with dim‑to‑off capability offers excellent flexibility for modern control systems and building automation. Combined with extensive international safety and EMC certifications (including type “HL” for use in Class I, Division 2 hazardous locations), the PWM‑40‑24 is ideally suited for professional 24 V LED strip lighting in commercial and industrial environments.

100K Potentiometer oder Poti, passend für Mean Well LED-Netzteile die Dimmbar sind bzw. eine 3 in1 Dimmung haben. Netzteil-Typ "B" oder Typ "AB" 100K potentiometer, siutable for Mean Well power supplies which are dimmable respectively are dimmbale with 3 in 1 dimming. Power supply type "B" oder type "AB". Zum Beispiel / for e.g.: HLG-40H-12B oder HLG-240H-24AB, LPF-60D-12 oder ELG-75-24B-3Y Um zwei Netzteile parallel mit DIM+/DIM- einzustellen benötigen Sie einen 47K poti.  To connect two DIM+/Dim- of power supplies in parallel you need a 47K potentiometer.

Drehknopf D=16mm /d=6mm passend für 100K Poti Art-Nr.: 200940, Ohne Poti, nur Drehknopf! Außenmaße, Farbe, Schraubenart können leicht variieren.
