IRM-30-15

20W AC-DC PCB Grünes Mount Modul 20W AC-DC PCB Mount Green Power Module

Technical Specifications & Details for MEAN WELL LRS-100-24 Power Supply Output Power: 108 W Output Voltage: 24 V DC Output Current: 4.5 A Input Voltage Range: 85 – 264 V AC / 120 – 373 V DC, 47 – 63 Hz Efficiency: up to 90% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 50 A @230 VAC No Load Power Consumption: < 0.3 W Operating Temperature: -30 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage Overvoltage Category: OVC III Isolation Voltage: 3.75 kV AC between input and output Dimensions (H x W x D): 30 mm x 97 mm x 129 mm Weight: approx. 340 g Safety & EMC Certificates: CE, UL 62368-1, TUV, CB, EAC LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Detailed Information on the MEAN WELL LRS-100-24 The MEAN WELL LRS-100-24 is a premier 108W single-output enclosed power supply that has become a staple in industrial automation due to its ultra-compact 30mm low-profile design. This form factor is specifically optimized for 1U installations, providing engineers with the flexibility to design smaller control cabinets without sacrificing power density. Engineered for high-stress environments, this power supply features a vibration resistance of up to 5G and a rugged metallic mesh housing that facilitates efficient heat dissipation through natural air convection, ensuring stable performance even at elevated ambient temperatures up to 70°C. Technically, the LRS-100-24 stands out with an impressive efficiency of up to 90%, which significantly minimizes thermal waste and enhances the overall longevity of the connected system. It is fully compliant with Over Voltage Category III (OVC III) standards, allowing it to be safely integrated into fixed industrial distribution panels with an added layer of surge protection. With its extremely low standby power consumption of less than 0.3W, this unit is a sustainable choice for energy-conscious projects, providing a reliable 24V DC / 4.5A output that is ideal for PLC systems, sensors, and high-performance motor controls.

Technical Information & Details for the MEAN WELL RS-25-15 Power Supply Output Power: 25.5 W Output Voltage: 15 V DC Output Current: 1.7 A Input Voltage Range: 88 – 264 V AC / 125 – 373 V DC, 47 – 63 Hz Efficiency: 83.5 % Ripple & Noise: ≤ 120 mVp-p Inrush Current: 45 A / 230 V AC (Cold Start) No Load Power Consumption: < 0.5 W Operating Temperature: −20 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage Vibration Resistance: 5G vibration test compliance Isolation Voltage: 3000 V AC between Input and Output Dimensions (L x W x H): 78 mm x 51 mm x 28 mm Weight: 200 g Safety & EMC Certificates: UL62368-1, EN62368-1, CCC, CB, CE, EAC, BSMI LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL RS-25-15 The MEAN WELL RS-25-15 is a high-performance 25.5W switching power supply that delivers a precise 15V DC output, making it an ideal choice for powering industrial control systems and communication equipment. One of its most significant technical advantages is its high surge resistance, capable of withstanding 300VAC input for 5 seconds without sustaining damage. This robustness is complemented by its mechanical durability, as the unit is designed to meet 5G vibration standards, ensuring stable operation even when mounted in environments subject to heavy machinery movement. By utilizing 105°C long-life electrolytic capacitors, the RS-25-15 is engineered for maximum reliability and a prolonged service life under professional operating conditions. Beyond its physical resilience, this power supply is optimized for energy efficiency and safe integration into complex systems. It features a low no-load power consumption of under 0.5W, aligning with modern ecological and cost-saving standards. The safety suite includes short circuit, overload, and over-voltage protections, with a Hiccup mode that facilitates automatic recovery once fault conditions are cleared. Its miniature footprint and effective cooling by free air convection allow it to fit easily into confined spaces while maintaining an operating temperature range of -20°C to +70°C. Backed by global safety certifications and a 3-year manufacturer warranty, it stands as a dependable and versatile power solution for international markets.
