Technical Information & Details for the MEAN WELL LRS-150-24 Power Supply Output Power: 156 W Output Voltage: 24 V DC Output Current: 6.5 A Input Voltage Range: 85 – 132 VAC / 170 – 264 VAC (selectable by switch), 240 – 370 VDC Efficiency: up to 89 % Ripple & Noise: ≤ 200 mVp-p Inrush Current: 60 A / 230 VAC (Cold Start) No-Load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: Free air convection (fanless) Protection Functions: Short circuit, Overload, Over voltage, Over temperature Over Voltage Category: OVC III Isolation Voltage: 4000 V AC between Input and Output Dimensions (L x W x H): 159 mm x 97 mm x 30 mm Weight: 0.42 Kg Safety & EMC Certificates: UL62368-1, TUV, CB, CE, EAC, BSMI, CCC LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL LRS-150-24 The MEAN WELL LRS-150-24 is a professional-grade 150W single-output power supply that features an innovative 1U low-profile design with a height of only 30mm. This model is specifically engineered to maximize reliability in compact spaces, utilizing a metallic mesh casing that optimizes natural air convection. This fanless cooling design allows the unit to operate silently while maintaining peak performance across a wide temperature range of -30°C to +70°C. Its robust construction is further highlighted by its 5G anti-vibration capability and the ability to withstand a 300VAC surge input for up to five seconds, ensuring long-term stability in harsh industrial environments. In addition to its physical resilience, the LRS-150-24 is highly efficient, boasting a typ. efficiency of 89% and an impressively low no-load power consumption of less than 0.5W. It is designed to meet Over Voltage Category III (OVC III) requirements, providing enhanced safety for fixed installations and direct connection to industrial distribution panels. Equipped with a comprehensive suite of protections—including hiccup mode for overload and automatic recovery—this 24V DC source is a versatile solution for industrial automation, mechanical equipment, and control systems. The package is completed by a 3-year manufacturer warranty, underscoring its high build quality and reliability.

MEAN WELL LRS-75-24

MEAN WELL LRS-50-24

Technical Information & Details for the MEAN WELL NDR‑120‑24 Power Supply Output Power: 120 W Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 88 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 20 A @115 VAC / 40 A @230 VAC No-Load Power Consumption: < 0.75 W Operating Temperature: −20 °C to +70 °C Cooling: fanless natural convection Protection Features: short-circuit, overload, overvoltage, overtemperature Overvoltage Category: OVC II Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 125.2 mm x 40 mm x 113.5 mm Weight: approx. 670 g Safety & EMC Certificates: CE, UL 508, TUV, CB, EAC LED Indicator: Power On Indicator Manufacturer Warranty: 3 years About the MEAN WELL NDR-120-24 The MEAN WELL NDR-120-24 is a powerful DIN-rail industrial power supply delivering 120 W with stable 24 V DC / 5 A output. It excels with superior efficiency up to 88 %, fanless natural convection cooling for silent operation, and a ultra-narrow 40 mm metal housing. Comprehensive protection features (short-circuit, overload, overvoltage, overtemperature) with automatic recovery ensure maximum operational safety. Ideal for PLC controls, industrial automation, sensor networks, and building management systems – the universal 90–264 V AC input range enables global deployment. With international certifications, the NDR-120-24 provides optimal energy efficiency, durability, and space savings in demanding industrial environments.

Technical Information & Details about the MEAN WELL LPV-100-24 Power Supply Rated output power: 100.8 W DC output voltage: 24 V DC Rated output current: 4.2 A Current range: 0 – 4.2 A Input voltage range: 90 – 264 V AC (127 – 370 V DC), 47 – 63 Hz Efficiency (typical): about 88 % Ripple & noise (max.): ≤ 150 mVp-p Output voltage range (O.V.P. region): 27.6 – 32.4 V DC Voltage tolerance: ±5.0 % Line regulation: ±2.0 % Load regulation: ±5.0 % Setup, rise time: 2000 ms, 25 ms at 230 V AC / 115 V AC (first cold start) Hold-up time (typ.): 50 ms at 230 V AC / 14 ms at 115 V AC (full load) AC input current (typ.): 2.2 A at 115 V AC / 1.2 A at 230 V AC Inrush current (typ.): 75 A at 230 V AC (cold start, twidth ≈ 700 μs) Leakage current: < 0.25 mA at 240 V AC Overload protection: 110 – 150 % of rated output power, hiccup mode, auto recovery after fault removal Overvoltage protection: shut down output voltage at 27.6 – 32.4 V, re‑power on to recover Operating temperature: −25 °C to +70 °C (derating required, see curve) Operating humidity: 20 – 90 % RH, non‑condensing Storage conditions: −40 °C to +80 °C, 10 – 95 % RH Cooling method: free air convection (fanless) Withstand voltage: 3000 V AC between input and output Isolation resistance: > 100 MΩ at 500 V DC, 25 °C, 70 % RH Ingress protection rating: IP67, fully encapsulated plastic case Dimensions (L x W x H): 190 mm x 52 mm x 37 mm Weight: approx. 610 g Vibration resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) EMC emission: BS EN/EN 55032 Class B, BS EN/EN 61000‑3‑2 Class A (≤80 % load), BS EN/EN 61000‑3‑3 EMC immunity: BS EN/EN 61000‑4‑2,‑3,‑4,‑5,‑6,‑8,‑11; BS EN/EN 55035 Safety approvals: UL 8750, CSA C22.2 No. 250.13‑12, UL 879, CSA C22.2 No. 207‑M89, BIS IS 15885, IEC/BS EN/EN 62368‑1, EAC Case design: fully isolated, encapsulated plastic case for damp and dusty environments MTBF (typical): 4,497,100 h (Telcordia SR‑332, 25 °C) Manufacturer warranty: 2 years About the MEAN WELL LPV-100-24 The MEAN WELL LPV-100-24 is a 100 W class constant‑voltage switching power supply that provides a regulated 24 V DC output at up to 4.2 A, fully encapsulated in an IP67 plastic housing for reliable use in harsh environments. Its universal AC input range, high efficiency, short‑circuit, overload and overvoltage protection, and fanless free air convection make it suitable for indoor and sheltered outdoor applications. With compact dimensions, strong isolation and broad safety and EMC approvals, LPV-100-24 is a robust 24 V source for LED strips, signage, control systems and other low‑voltage equipment that require a rugged, dust‑ and splash‑proof power supply.

Achtung ! Das Produkt wird nur an OEM/EMS Kunden verkauft. Es wird nicht an Privatkunden in der EU verkauft oder geliefert. Bitte beachten Sie die Herstellerhinweise dazu im Datenblatt auf der Seite 2 Fußnote Note 9. Alternativen zu diesem Netzteil finden weiter unten bei Ähnliche Artikel.
