PLC-30-12

60W LED Schaltnetzteile 60W  Single Output LED Power Supply

Technical Information & Details for the KVF-24200-TDH Power Supply Output Power: 200 W Output Voltage: 24 V DC Output Current: 8.33 A Input Voltage Range: 200 – 240 V AC, 47 – 63 Hz Efficiency: up to 87 % Inrush Current: typ. 96 A @ 230 V AC Operating Temperature: -40 °C to +60 °C Cooling: fanless free air convection Protections: Short circuit, over load, over temperature Waterproof Rating: IP66 Dimming Function: Triac / Leading & trailing edge phase cut (0-100%) Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 256 mm x 78 mm x 47 mm Weight: approx. 1.45 kg Safety & EMC Certificates: ENEC, TUV, SAA, CB, CCC, CE, SELV, RoHS, REACH Manufacturer Warranty: 5 years Information about the KVF-24200-TDH The KVF-24200-TDH is a highly durable and efficient 200W constant voltage LED driver designed specifically to power professional 24V lighting systems. One of the standout features of this model is its flicker-free PWM dimming output (20 kHz), which provides smooth, precise brightness control from 0 to 100% and is fully compatible with both leading edge and trailing edge TRIAC dimmers. Housed in a rugged, IP66-rated waterproof enclosure and engineered to operate across extreme temperatures from -40 °C to +60 °C, this driver ensures unwavering reliability in both demanding indoor and harsh outdoor environments. Furthermore, the built-in active PFC function optimizes power factor and overall energy efficiency while delivering a highly stable 24V direct current. In addition to its exceptional dimming capabilities, this premium power supply features a fanless free air convection cooling system that guarantees completely silent operation and eliminates mechanical failure risks. It is equipped with comprehensive, auto-recovering protection mechanisms against short circuits, overloads, and over-temperature conditions, safeguarding your valuable LED installations against unexpected faults. Supported by an industry-leading 5-year manufacturer warranty and rigorously tested to meet global safety standards including ENEC, TUV, CE, and SELV, the KVF-24200-TDH is an outstanding, reliable choice for high-end dimmable lighting applications.

Technische Eigenschaften des SC Power KVF-24150-TDH: Leistung: 150W Spannung: 24V Ausgangsstrom: 6,25A Konstantspannungsausgang Eingangsbereich: 200-240VAC Arbeitseffizienz: bis zu 90% TRIAC Dimmer: Phasenan-/abschnittsdimmung/ Phase Cut Einfache Installation IP66 Design; Geeignet für Outdoor-Installationen Kühlung durch freie Luftkonvektion Schutz vor Kurzschluss, Überlast, Überstrom und Überhitzung Eingebaute PFC Funktion Perfekte Kompatibilität; Flimmerfreie Dimmung Geeignet für LED-Beleuchtungssysteme und Displayanzeigen

In: 100-305VAC 47-63Hz 142-431VDC / Eff. 92% / 140x63x32mmOut: 12V 8A, 4-8A strom einstellbar , Arbeitet im CC und CV modus, IP67
