Technical Information & Details for the SNAPPY SS60-24VF Power Supply Output Power: 60 W Output Voltage: 24 V DC Output Current: 0 – 2.5 A Input Voltage Range: 220 – 240 V AC (198 – 264 V AC), 47 – 63 Hz Efficiency: 88 % Ripple & Noise: ± 3 % (PK-PK) Inrush Current: max. 30 A @ 230 VAC (Cold start) Stand-by Power Consumption: < 0.5 W Operating Temperature: −20 °C to +45 °C Cooling: Natural convection (fanless) Protections: Short circuit, Overload, Over voltage, Over temperature IP Rating: IP20 Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 159 mm x 57.8 mm x 18 mm Weight: 250 g Safety & EMC Certificates: TUV, CE, SAA, EN61347-1/-2-13, EN55015 Power Factor: 0.95 (Typical at full load) Manufacturer Warranty: 5 years Information about the SNAPPY SS60-24VF The SNAPPY SS60-24VF is a high-performance constant voltage driver specifically engineered for indoor LED installations requiring a steady 24V supply. Its ultra-slim profile, measuring only 18 mm in height, makes it an ideal choice for space-constrained environments such as retail displays, furniture lighting, and architectural accents. Equipped with a built-in active PFC function, the unit achieves a superior power factor of 0.95 and remarkably low total harmonic distortion, ensuring compliance with modern energy standards while maximizing operational efficiency. The internal glue potting and durable plastic shell provide added reliability, protecting the internal components while maintaining a fanless, silent operation through natural air convection. This power supply is designed for maximum uptime, featuring an intelligent protection system that safeguards against short circuits, voltage spikes, and thermal overloads. The auto-recovery hiccup mode is a key benefit, allowing the device to resume normal operation automatically once a fault condition is removed, which significantly reduces maintenance efforts. Rigorously tested to meet worldwide safety regulations like TUV and SAA, it features reinforced insulation with a 3750V isolation rating between input and output. Backed by a 5-year warranty and a 30,000-hour rated lifetime at full load, the SS60-24VF offers a dependable and energy-efficient solution for professional lighting projects ranging from advertising lights to industrial sensor power.

In: 220-240VAC 50/60Hz / 0,17A / Eff.: 87%Out: 24VDC / 30W / 1,25A / 154x50x14

Technical Information & Details of the MEAN WELL PWM-60-24 LED Driver Output power: 60 W DC output voltage: 24 V DC Rated output current: 2.5 A Output type: Constant voltage PWM style output Dimming range: 0 – 100 % (3‑in‑1: 0–10 VDC, 10 V PWM signal, or resistance; DA/DA2: DALI/DALI‑2) PWM output frequency: approx. 1.47 kHz (Blank/DA) / 2.5 kHz (DA2) Overvoltage protection threshold: 28 – 34 V DC Setup / rise time: ≤ 500 ms, 80 ms @ 115 / 230 VAC (full load) Hold‑up time (typ.): approx. 16 ms @ 115 / 230 VAC (full load) Input voltage range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Power factor (typ.): PF > 0.97 @ 115 VAC, PF > 0.95 @ 230 VAC, PF > 0.92 @ 277 VAC (full load) Efficiency (typ.): approx. 89 % AC input current (typ.): 0.8 A @ 115 VAC / 0.4 A @ 230 VAC / 0.32 A @ 277 VAC Inrush current (typ.): cold start, 50 A @ 230 VAC (≈270 μs at 50 % Ipeak) Leakage current: < 0.25 mA @ 277 VAC Overload protection: 108 – 130 % of rated output power, hiccup mode, auto recovery Overvoltage protection: Shut down output voltage, re‑power on to recover Overtemperature protection: Shut down output voltage, re‑power on to recover (DA2: hiccup mode) Short‑circuit protection: Hiccup mode, auto recovery Operating temperature (case Tcase): −40 °C to +85 °C (see “Output load vs temperature” derating) Operating humidity: 20 – 95 % RH, non‑condensing Storage temperature / humidity: −40 °C to +80 °C, 10 – 95 % RH Temperature coefficient: ± 0.03 % / °C (0 – 50 °C) Vibration: 10 – 500 Hz, 5 G, 12 min./cycle, 72 min. along X, Y, Z axes Withstand voltage: 3.75 kVAC (input–output), 1.5 kVAC (input–DA), 1.5 kVAC (output–DA) Isolation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70 % RH Safety standards: UL8750 (type “HL”, except DA), UL879 (12 V, 24 V Blank only), ENEC EN 61347‑1, EN 61347‑2‑13 (independent), EN 62384, BIS IS 15885 (Part 2/Sec 13; 12/24/48 Blank & 12/24‑DA2), EAC TP TC 004, GB19510.1, GB19510.14; IP67; suitable for emergency installations per EN 61347‑2‑13 Annex J (EL) DALI standards (DA/DA2): IEC 62386‑101/102/207/251, Device Type 6 (DT6) EMC emission: EN 55015, EN 61000‑3‑2 Class C (≥60 % load), EN 61000‑3‑3, GB/T 17743, GB17625.1, EAC TP TC 020 EMC immunity: EN 61000‑4‑2,3,4,5,6,8,11; EN 61547 (light industry level, surge Line–Line 2 kV), EAC TP TC 020 MTBF (typ.): 2,626,600 h (Telcordia SR‑332, 25 °C) / 227,100 h (MIL‑HDBK‑217F, 25 °C) Dimensions (L x W x H): 150 mm x 53 mm x 35 mm Weight: approx. 0.49 kg Case & protection: fully encapsulated plastic case, IP67, Class II/2 No‑load power consumption: < 0.5 W Design: 60 W constant‑voltage PWM LED driver, Class 2, LPS Information about the MEAN WELL PWM-60-24 The MEAN WELL PWM‑60‑24 is a 60 W constant‑voltage LED driver with a PWM‑style output, designed to maintain brightness homogeneity when driving 24 V LED strips and other constant‑voltage LED loads. Its PWM operation at approximately 1.47 kHz (Blank/DA) or 2.5 kHz (DA2) delivers smooth, flicker‑free dimming while preserving color consistency even at low dimming levels. With typical efficiency up to around 89 %, active power factor correction and a wide 90–305 V AC input range, the driver is energy‑efficient and suitable for global installations. The fully encapsulated IP67 housing, wide −40 to +85 °C case temperature range and comprehensive protection features (short‑circuit, overload, overvoltage, overtemperature) ensure robust operation in dry, damp and wet locations, including suitability for certain emergency lighting systems under EN 61347‑2‑13. The integrated 3‑in‑1 dimming interface (0–10 V, 10 V PWM signal, resistance) in the Blank version and optional DALI/DALI‑2 control (DA/DA2 types) provide excellent flexibility for modern lighting control and building automation. Combined with long lifetime ratings and extensive international safety and EMC certifications, the PWM‑60‑24 is a strong choice for 24‑V LED strip lighting, indoor and decorative lighting, architectural lighting and industrial LED applications that require reliable constant‑voltage PWM drivers.

In: 220-240VAC 50/60Hz 176-280VDC / 290x45x30.5mmOut: 80W / 0-3.33A / 24VDC / Eff. 87% / IP20, DALI2, PUSH, SELV, Class II
