LS-80-24DALI-2 LI

Technical Information & Details for the MEAN WELL SLD-50-24 Power Supply Output Power: 50.4 W Output Voltage: 24 V DC Output Current: 2.1 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC Efficiency: 88 % Ripple & Noise: ≤ 240 mVp-p Inrush Current: 50 A at 230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: -20 °C to +90 °C (Tcase) Cooling: Fanless free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Isolation Class: Class 2 / II power unit Isolation Voltage: 3.75 KV AC Dimensions (L x W x H): 280 mm x 30 mm x 16.8 mm Weight: 0.175 Kg Safety & EMC Certificates: UL8750, ENEC EN61347-1, BS EN/EN62384, EAC, IS15885 Design Type: Ultra-slim linear housing Manufacturer Warranty: 3 years Information about the MEAN WELL SLD-50-24 The MEAN WELL SLD-50-24 is a high-performance 50W LED driver characterized by its ultra-slim and linear housing design, which stands at a mere 16.8mm in height. This low-profile architecture is specifically engineered for seamless integration into signage, troffer lighting, and modern linear luminaires where vertical clearance is extremely limited. The driver features a unique dual-mode output, allowing it to function effectively in both Constant Voltage and Constant Current regions, providing the versatility to drive LED strips or power modules directly. With an efficiency of 88% and a fanless design, the unit operates reliably via free air convection, maintaining stable performance even at case temperatures reaching up to 90°C. Beyond its physical aesthetics, the SLD-50-24 offers industrial-grade reliability with a wide input range of 110 to 305VAC and a built-in active PFC function to ensure high power factor quality across various loads. Safety is integrated at every level, as the unit is a Class 2 power unit and includes comprehensive protections against short circuits, over-voltage, and over-temperature. The hiccup mode protection ensures the device recovers automatically once fault conditions are removed, making it an ideal "install-and-forget" solution for commercial decoration and cove lighting. By adhering to global standards such as UL8750 and ENEC, this driver represents a secure, high-quality power solution for professional lighting designers requiring a balance of minimalist form and maximum durability.

Technical Information & Details for the SNAPPY SS100-24VL LED Power Supply Output Power: 100 W Output Voltage: 24 V DC Output Current: 0 – 4.17 A Input Voltage Range: 200 – 240 V AC, 50/60 Hz Efficiency: 91 % Ripple & Noise: ± 2 % (PK-PK) Inrush Current: max. 60 A @ 230 VAC Standby Power Consumption: < 0.5 W Operating Temperature: −20 °C to +45 °C Cooling: Fanless natural cooling Protection Functions: Short circuit, Over load, Over voltage, Over temperature Power Factor: 0.98 (Typ.) Insulation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 170 mm x 44.5 mm x 28.2 mm Safety & EMC Certificates: CE, TUV, EN61347-1, EN61347-2-13 IP Rating: IP20 Manufacturer Warranty: 5 years The SNAPPY SS100-24VL is a high-efficiency indoor constant voltage LED power supply designed to meet the rigorous demands of modern architectural and commercial lighting. This driver is distinguished by its built-in active PFC function and ultra-low total harmonic distortion (THD), which ensures a superior power factor of 0.98 and minimizes electrical interference within the power grid. Its fanless design utilizes natural air convection to maintain an impressive 91% typical efficiency, providing a silent and energy-saving solution for installations where space and noise levels are critical considerations. Engineered for maximum reliability, the SS100-24VL features a plastic case with internal glue potting to enhance thermal stability and protect sensitive components. The unit includes comprehensive protection circuitry that covers short circuits, overloading, and over-temperature scenarios with automatic recovery modes, significantly increasing the lifecycle of the product. Furthermore, it is equipped with a built-in lightning protection device capable of handling surges up to 4kV, ensuring that your LED luminaire system remains safe and operational even during electrical transients. Backed by a 5-year warranty and a 30,000-hour lifetime at a case temperature of 75°C, this driver represents a dependable choice for high-end indoor lighting projects.

Technical Information & Details for the MEAN WELL SLD-150-24 Power Supply Output Power: 150 W Output Voltage: 24 V DC Output Current: 6.25 A Input Voltage Range: 110 – 305 V AC / 155 – 431 V DC, 47 – 63 Hz Efficiency: up to 92.5 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 50 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −25 °C to +85 °C (Case Temperature) Cooling: Fanless natural convection Protection Functions: Short circuit, Overload, Overvoltage, Over temperature Overvoltage Category: OVC II Isolation Voltage: 3750 V AC between Input and Output Dimensions (H x B x T): 222 mm x 68 mm x 16.8 mm Weight: ca. 710 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, EN62384, GB19510.1 LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL SLD-150-24 The MEAN WELL SLD-150-24 is a highly specialized 150W AC/DC LED driver designed with a focus on an ultra-slim and linear profile. Featuring a remarkably low height of just 16.8 mm, this power supply is the ideal choice for integration into narrow signage, cove lighting, and decorative furniture where traditional, bulkier power units cannot fit. Its unique dual-mode constant voltage and constant current output allows it to serve as a versatile solution for a wide range of LED strip configurations and luminaires, ensuring consistent performance across various lighting design requirements. Beyond its physical compact nature, the SLD-150-24 offers superior electrical performance with a peak efficiency of 92.5% and built-in active Power Factor Correction (PFC). It is housed in a Class II plastic case, which eliminates the need for a functional earth ground while maintaining high safety standards through double insulation. With a wide input range of 110-305 VAC and full protection against short circuits, overloads, and extreme temperatures, this unit provides a 3-year manufacturer warranty and total reliability for professional architectural and commercial lighting projects.
