Technical Information & Details for the EAGLERISE VTS-100-24 IP67 L Power Supply
- Output Power: 100 W
- Output Voltage: 24 V DC
- Output Current: 0 – 4.17 A
- Input Voltage Range: 176 – 264 V AC, 47 – 63 Hz
- Efficiency: up to 89%
- Voltage Accuracy: ±5%
- Power Factor: 0.95 (Typical)
- No-Load Power Consumption: < 0.5 W
- Operating Temperature: -40 °C to +75 °C
- Cooling: Free air convection
- Protection Functions: Over Load (OLP), Short Circuit (SCP), Over Temperature (OTP)
- IP Rating: IP67 (Waterproof)
- Inrush Current: 44.6 A (Ipeak)
- Dimensions (L x W x H): 162.5 mm x 42.5 mm x 32 mm
- Total Length (incl. cables): Approx. 190 mm (housing)
- Safety & EMC Certificates: CE, CB, EN 61347-1, EN 61347-2-13, EN 62384, EN 55015
- Special Features: Built-in active PFC function, Flicker-free
- Manufacturer Warranty: 3 Years
Information about the EAGLERISE VTS-100-24 IP67 L
The Eaglerise VTS-100-24 IP67 L is a high-performance 100W constant-voltage LED driver engineered specifically for demanding environments that require superior moisture protection and long-term reliability. Its robust IP67 waterproof rating makes it an ideal solution for outdoor LED strips and signage, ensuring seamless operation even in wet or damp locations. This driver stands out with its integrated active PFC function and a high efficiency rating of up to 89%, which minimizes energy waste and heat generation. Designed with a compact plastic housing, it facilitates installation in narrow spaces while maintaining excellent thermal management through free air convection. The unit provides comprehensive safety through all-around protection including over-load, short-circuit, and over-temperature safeguards with automatic recovery, guaranteeing a maintenance-free lifecycle. Its flicker-free performance and low total harmonic distortion (THD < 10%) ensure stable, high-quality light output, making it a professional-grade choice for modern architectural and decorative lighting systems.
