Discontinued Product see replacement LCM-25DA2

Discontinued Product see replacement: LCM-40DA2

Technical Information & Details for the MEAN WELL HLG-185H-24A Power Supply Output Power: 187.2 W Output Voltage: 24 V DC Output Current: 7.8 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 94% Ripple & Noise: ≤ 150 mVp-p Voltage Adjustment Range: 22 – 27 V (via internal potentiometer) Current Adjustment Range: 3.9 – 7.8 A (via internal potentiometer) Power Factor (PF): ≥ 0.98 / 115 VAC, ≥ 0.95 / 230 VAC Operating Temperature: −40 °C to +90 °C (Case Temperature) Cooling: Fanless, free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Ingress Protection: IP65 (Dust-tight and protected against water jets) Isolation Voltage: 3750 V AC between Input and Output Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm Weight: approx. 1150 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP65, EAC, CE Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-185H-24A The MEAN WELL HLG-185H-24A is a high-performance 187.2W AC/DC LED driver designed to meet the rigorous demands of industrial lighting systems. A key characteristic of the "A-Type" model is its internal potentiometers, which allow for manual adjustment of the output voltage (22–27V) and output current (3.9–7.8A). This feature provides essential on-site flexibility, enabling users to fine-tune power levels to match the exact requirements of their LED arrays. Utilizing a dual-mode constant voltage and constant current architecture, it ensures stable performance across a wide range of applications. The heavy-duty metal enclosure carries an IP65 rating, providing superior protection against dust and water jets, making it the perfect choice for LED street lighting, parking area illumination, and industrial high-bay fixtures. Boasting a peak efficiency of 94%, the driver operates reliably via free air convection without the need for active cooling fans. With a typical life expectancy of over 62,000 hours and a generous 7-year manufacturer warranty, the HLG-185H-24A stands as a top-tier, maintenance-free solution for professional-grade installations.

Technical Information & Details for MEAN WELL HLG-320H-24A Power Supply Rated Power: 320.16 W Output Voltage: 24 V DC Rated Current: 13.34 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 94% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 70 A @ 230 V AC Voltage Adj. Range: 21 – 26 V (via built-in potentiometer) Current Adj. Range: 6.67 – 13.34 A (via built-in potentiometer) Operating Temperature: −40 °C to +90 °C (case temperature) Cooling: fanless free air convection Protections: Short circuit, Over current, Over voltage, Over temperature IP Rating: IP65 rated Isolation Voltage: 3750 V AC between Input and Output Dimensions (L x W x H): 252 mm x 90 mm x 43.8 mm Weight: approx. 1880 g Safety & EMC Standards: UL8750, EN61347-1, EN61347-2-13, IP65, PSE Manufacturer Warranty: 7 Years Information on the MEAN WELL HLG-320H-24A The MEAN WELL HLG-320H-24A is a flagship industrial LED driver designed for peak performance and long-term reliability in demanding environments. This A-Type model is distinguished by its user-accessible internal potentiometers, allowing for the manual adjustment of both voltage and current levels to perfectly match the requirements of the connected load. It operates with a dual-mode output, seamlessly providing Constant Voltage (CV) and Constant Current (CC) characteristics, which is essential for professional LED lighting and battery charging applications. Built with a high-grade metal enclosure and rated at IP65, the unit is highly resistant to dust and moisture ingress. A key strength is its advanced circuit design featuring Active PFC and an impressive 94% efficiency, which minimizes power loss and allows the unit to operate reliably without fans even at extreme temperatures up to +90 °C. With a typical lifetime of over 62,000 hours and an industry-leading 7-year warranty, the HLG-320H-24A provides ultimate peace of mind for high-bay lighting, street lighting, and parking lot installations where maintenance-free operation is a priority.

Technische Eigenschaften des MEAN WELL NPF-90-24 Nennleistung: 90 W Eingangsbereich: 90 bis 305VAC Ausgangsspannung: 24 VDC Konstantsstrom + Konstantspannung (CC + CV) aktive PFC-Funktion Class II Netzgerät Schutzart IP67 Lüfterfreie Konstruktion Hoher Wirkungsgrad von 91% Geringer Standby-Verbrauch < 0,15 W Schutz vor Kurzschluss, Überlast sowie Überspannung Überhitzungsschutz Informationen zum MEAN WELL NPF-90-24 Beim Mean Well NPF-90-24 handelt es sich um einen leistungsstarken LED-Treiber im Kunststoffgehäuse mit der eingebauten aktiven PFC-Funktion für Indoor- sowie Outdoor-Installationen. Es liefert eine geregelte Nennleistung von 90 W bei einem Strom von 3,75 A sowie einer vielfältig einsetzbaren 24 VDC Ausgangsspannung. Eingangsseitig verfügt das LED-Schaltnetzteil von MeanWell über einen weiten AC-Spannungsbereich von 90 bis 305 V mit erforderlichem Derating zwischen 90 und 100 VAC. Die NPF-90-Serie bietet weiterhin die Betriebsmodi Konstantsstrom + Konstantspannung (CC + CV). Falls Sie Fragen dazu haben, können Sie sich gerne jederzeit mit uns in Verbindung setzen. Neben der aktiven PFC-Funktion zeichnen sich die Modelle von Mean Well durch die Schutzart IP67 sowie die Zertifizierung als Class II Schaltnetzteile. Damit lassen sich die LED-Netzgeräte der MeanWell NPF-90-Serie sowohl in trockenen als auch in feuchten Arbeitsumgebungen ausreichend einsetzen. Die Produktreihe von Mean Well ist daher für die Anwendungen wie z. B. LED-Tunnelbeleuchtungen, bewegliche LED-Anzeigenschilder oder dekorative LED-Leuchten gut geeignet. Darüber hinaus sind die MeanWell NPF-90-Netzgeräte nach dem lüfterlosen Design konzipiert und daher durch freie Luftkonvektion gekühlt. Diese gewährleistet einen geräuscharmen Betrieb mit einem hohen Wirkungsgrad von bis zu 91% bei einem geringen Standby-Verbrauch von unter 0,15 W. Nicht zuletzt verfügen die Mean Well NPF-90-Netzteile über einen Schutz gegen Kurzschluss, Überlast sowie Überspannung. Die Produktserie von MeanWell bietet weiterhin einen Überhitzungsschutz und erfüllt zudem alle grundlegenden Sicherheits- sowie Störfestigkeitsnormen gemäß UL8750, EN61347-1, EN61347-2-13 für Netzteile im Bereich der LED-Beleuchtungen.

Technical Information & Details for the MEAN WELL HLG-120H-24A Power Supply Rated Power: 120 W Output Voltage (DC): 24 V Rated Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency (typ.): 93 % Ripple & Noise (max.): 150 mVp-p Voltage Adjustment Range: 22 – 27 V Current Adjustment Range: 2.5 – 5 A Operating Temp. (Case): −40 °C to +80 °C IP Rating: IP65 Dimensions (L x W x H): 220 x 68 x 38.8 mm Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-120H-24A The MEAN WELL HLG-120H-24A is a high-performance 120W LED driver, widely regarded as a staple for 24V professional lighting systems. As an "A-Type" model, it is specifically designed for on-site customization. It features two internal potentiometers located under protective rubber stoppers, allowing installers to manually fine-tune the output voltage from 22V to 27V and calibrate the current limit from 2.5A to 5A to perfectly match the connected load. The unit operates in dual-mode constant voltage and constant current, providing exceptional stability whether it is powering 24V LED strips or direct COB LED arrays. Housed in a rugged IP65-rated aluminum enclosure, the HLG-120H-24A is built to withstand dust and moisture ingress, making it suitable for high-bay lighting, urban street lamps, and outdoor architectural accentuation. The fanless design ensures silent operation and efficient cooling through natural air convection. With a peak efficiency of 93% and built-in active PFC, the driver minimizes energy waste and optimizes power factor. It includes comprehensive safety mechanisms, such as short circuit, overcurrent, and overtemperature protections. Backed by a 7-year manufacturer warranty and carrying the "Type HL" rating for hazardous locations, this driver is a premier choice for mission-critical infrastructure and large-scale industrial projects.
