Technical Information & Details for MEAN WELL HLG-185H-C1050A Power Supply
- Output Power: 200 W
- Output Voltage Range: 95 – 190 V DC
- Output Current: 1050 mA (adjustable via internal potentiometer)
- Current ADJ. Range: 525 mA to 1050 mA
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency: 94 %
- Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC
- Current Ripple: max. 5.0%
- Operating Temperature: −40 °C to +90 °C (T-case)
- Cooling: Fanless natural convection
- Ingress Protection: IP65 rated
- Protection Functions: Short circuit, Over voltage, Over temperature
- Isolation Voltage: 3750 V AC (Input to Output)
- Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
- Weight: 1.15 kg
- Safety Standards: UL8750, EN61347-1, EN61347-2-13, CE, EAC
- Typical Lifetime: > 62,000 hours
- Manufacturer Warranty: 7 years
Information about the MEAN WELL HLG-185H-C1050A
The MEAN WELL HLG-185H-C1050A is a high-performance 200W LED driver engineered for constant current mode operation, providing a reliable power source for high-power LED arrays. The "A" version stands out due to its built-in potentiometer, which allows for manual fine-tuning of the output current level between 525 mA and 1050 mA. This flexibility enables site-specific optimization of light intensity, ensuring that the LED system operates at peak efficiency without the need for complex external control wiring. With an industry-leading efficiency of 94%, this driver significantly reduces thermal stress, promoting a longer lifespan for all connected components.
Encased in a rugged IP65 rated metal housing, the unit is built to withstand dusty and moist conditions typical of industrial warehouses, parking garages, and canopy lighting. The fanless design utilizes natural air convection to maintain safe operating temperatures even in harsh environments up to +90 °C. Coupled with a built-in active PFC function and a massive 7-year manufacturer warranty, the HLG-185H-C1050A ensures a maintenance-free operation for over 62,000 hours. It is the ideal choice for professional lighting installers who require a robust, high-voltage constant current driver with easy manual adjustment capabilities.
