Technical Specifications & Details for MEAN WELL MDR-20-24 Power Supply Output Power: 24 W Output Voltage: 24 V DC Output Current: 1 A Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz Efficiency: 84% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 20 A @115 VAC / 40 A @230 VAC No-load Power Consumption: < 0.75 W Operating Temperature: −20 °C to +70 °C Cooling: Free air convection Protections: Short circuit, Overload (Constant current limiting), Over voltage Isolation Voltage: 3000 V AC I/P to O/P Dimensions (W x H x D): 22.5 mm x 90 mm x 100 mm Weight: approx. 170 g Safety & EMC Certificates: UL 508, TUV BS EN/EN62368-1, EAC, CB, BSMI, IS13252 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 Years  Information on the MEAN WELL MDR-20-24 The MEAN WELL MDR-20-24 is a highly reliable 24W power supply designed for seamless DIN rail integration in space-constrained industrial environments. Its ultra-slim 22.5mm width allows for maximum component density on TS-35/7.5 or 15 rails, making it a preferred choice for modern control panels. A key technical advantage of this model is the built-in DC OK active signal, which provides real-time feedback on the output status to higher-level monitoring systems or PLCs. Engineered for superior energy performance, it achieves an efficiency of 84% and maintains a no-load power consumption of less than 0.75W, significantly lowering the total cost of ownership and thermal dissipation. The unit employs a constant current limiting protection strategy, ensuring it remains robust during startup surges or temporary overloads and recovers automatically once conditions stabilize. With its maintenance-free fanless design and a full suite of global safety approvals, the MDR-20-24 provides a stable 24V DC foundation for automation, telecommunications, and building management systems.

Technical Information & Details for the MEAN WELL MDR-10-5 Power Supply Output Power: 10 W Output Voltage: 5 V DC Output Current: 2 A Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz Efficiency: 77 % Ripple & Noise: ≤ 80 mVp-p Inrush Current: max. 35 A @115 VAC / 70 A @230 VAC No-load Power Consumption: < 0.75 W Operating Temperature: −20 °C to +70 °C Cooling: Free air convection Protections: Short circuit, Overload, Over voltage Isolation Voltage: 3000 V AC I/P to O/P Dimensions (W x H x D): 22.5 mm x 90 mm x 100 mm Weight: approx. 150 g Safety & EMC Certificates: UL508, TUV EN62368-1, EAC, CB, BSMI, CE LED Indicator: Power On indicator Manufacturer Warranty: 3 Years Detailed Information on the MEAN WELL MDR-10-5 The MEAN WELL MDR-10-5 stands out as an ultra-slim 10W DIN rail power supply designed to optimize space in crowded industrial control cabinets. Featuring an exceptionally narrow 22.5mm width, this unit is perfect for miniaturized automation systems and IoT applications. A unique strength of this series is the built-in DC OK active signal, providing real-time feedback for system monitoring and ensuring that downstream components are receiving the correct voltage. Efficiency is a core characteristic, with a no-load power consumption of less than 0.75W, making it an eco-friendly choice for continuous operation. The device is built for high reliability, featuring 100% full load burn-in testing and a wide operating temperature range that thrives in harsh environments. With its universal AC input and comprehensive protection suite against short circuits and overloads, the MDR-10-5 is a versatile and dependable power source for PLCs, sensors, and building automation modules requiring a precise 5V DC output.

Technical Information & Details for the MEAN WELL RSP-150-12 Power Supply Output Power: 150 W Output Voltage: 12 V DC Output Current: 12.5 A Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz Efficiency: up to 88% Ripple & Noise: ≤ 100 mVp-p Inrush Current: max. 45 A @ 230 VAC Operating Temperature: -30 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Overvoltage Category: OVC II / OVC III Isolation Voltage: 4000 V AC between input and output Dimensions (L x W x H): 199 mm x 99 mm x 30 mm Weight: 0.6 Kg Safety & EMC Certificates: UL62368-1, TUV EN62368-1, EN61558-1, EAC, CCC, CB LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL RSP-150-12 The MEAN WELL RSP-150-12 is a highly reliable 150W AC/DC power supply designed for industrial environments where a stable 12V output is essential. A primary strength of this model is its ultra-slim 1U profile, standing at a height of just 30mm, which enables seamless integration into compact enclosures and flat rack systems where space is at a significant premium. Featuring built-in active Power Factor Correction (PFC), the unit optimizes energy usage and meets global harmonic current regulations. The design is completely fanless, utilizing natural free air convection for heat dissipation, which ensures totally silent operation and eliminates the risk of mechanical failure common in fan-cooled units. Engineered for professional-grade versatility, the RSP-150-12 is rated for operation at altitudes up to 5000 meters, making it suitable for specialized high-altitude telecommunications and industrial installations. It boasts a comprehensive protection architecture, including constant current limiting and automatic recovery, ensuring that both the power supply and the connected load remain safe during electrical faults. With added features such as remote ON-OFF control, a wide operating temperature range down to -30°C, and a high dielectric strength of 4KVAC, this unit is an excellent choice for factory automation, RF applications, and measurement instruments. It is backed by a 3-year manufacturer warranty, providing long-term assurance for critical systems.

Technical Information & Details for the MEAN WELL RSP-200-12 Power Supply Output Power: 200.4 W Output Voltage: 12 V DC Output Current: 16.7 A Input Voltage Range: 88 – 264 V AC / 124 – 370 V DC, 47 – 63 Hz Efficiency: 89% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 20 A @115 VAC / 40 A @230 VAC Leakage Current: < 1 mA / 240 VAC Operating Temperature: −30 °C to +70 °C Cooling: Free air convection Protections: Short circuit, Overload, Over voltage, Over temperature Overvoltage Category: OVC II Isolation Voltage: 3000 V AC between Input and Output Dimensions (L x W x H): 215 mm x 115 mm x 30 mm Weight: approx. 720 g Safety & EMC Certificates: UL62368-1, EN61558-1/-2-16, EAC, CCC, TUV LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL RSP-200-12 The MEAN WELL RSP-200-12 is a highly efficient 200W enclosed AC/DC power supply that represents a standard for industrial reliability. Its most prominent physical feature is the ultra-slim 30mm height, which conforms to 1U low-profile requirements, making it the perfect choice for shallow mounting applications and compact electronic cabinets. A major technical advantage of this 12V model is its fanless design; the unit is cooled entirely by natural free air convection. This eliminates the noise and mechanical vulnerabilities associated with cooling fans, providing a silent and maintenance-free power solution for long-term industrial deployments. Performance is further enhanced by the built-in active PFC function, which ensures a high power factor and optimizes energy consumption while adhering to global harmonic current standards. With an efficiency rating of 89%, it minimizes waste heat, allowing it to operate reliably in a wide temperature range from -30 °C to +70 °C. The RSP-200-12 is equipped with industrial-grade protections including hiccup mode for overloads and an over-temperature shutdown with automatic recovery. These characteristics, combined with certifications for factory automation and measurement instruments, make it an exceptionally stable energy source for sensitive 12V DC systems.
