Technical Information & Details about the MEAN WELL HDR-100-24 Power Supply Output Power: 92 W Output Voltage: 24 V DC Output Current: 3.83 A Current Range: 0 – 3.83 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: up to 90 % Ripple & Noise: ≤ 150 mVp-p Output Voltage Adjustment Range (LPS type): 24 – 25.5 V DC Extended Adjustment Range (Non‑LPS “N” type): 21.6 – 29 V DC Voltage Tolerance: ±2.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Setup, Rise Time: 500 ms, 60 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) AC Input Current (typ.): 3 A @115 V AC / 1.6 A @230 V AC Inrush Current: 35 A @115 V AC / 70 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Operating Humidity: 20 – 90 % RH, non‑condensing Storage Conditions: −40 °C to +85 °C, 10 – 95 % RH, non‑condensing Cooling: fanless free air convection Protection Features: short circuit (hiccup mode, auto recovery), overload (constant current limiting within 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Protection Threshold: 30 – 36 V DC Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 70 mm x 90 mm x 54.5 mm Weight: approx. 270 g Housing Material: insulating plastic housing, Class II, ultra‑slim 4‑SU step‑shape Mounting: DIN rail TS35/7.5 or TS35/15 Vibration Resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) Safety & EMC Certificates: UL 62368‑1, UL 508, TUV BS EN/EN 61558‑2‑16, BS EN/EN 61558‑1, IEC 62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000‑6‑2, BS EN/EN 61204‑3 LPS Classification: Pass LPS for “blank” models (up to 92 W, narrower adjustment range), Non‑LPS for “N” models (up to 100.8 W with wider adjustment range) LED Indicator: Power‑On status LED Manufacturer Warranty: 3 years About the MEAN WELL HDR-100-24 The MEAN WELL HDR-100-24 is an ultra‑slim 100 W class DIN‑rail power supply that provides a regulated 24 V DC output at up to 3.83 A in a compact 70 mm (4 SU) housing, ideal for space‑constrained 24 V control panels. With a universal input range, high efficiency up to 90 %, very low no‑load consumption and fanless free air convection, it delivers an energy‑efficient 24 V bus for building automation, household control systems and industrial control cabinets. LPS‑compliant “blank” models with a tighter adjustment window and higher‑power “N” versions with an extended adjustment range up to 29 V give designers flexibility between safety classification and additional voltage headroom. Together with the Class II plastic enclosure, comprehensive protection features and broad international approvals, HDR-100-24 is a robust, low‑maintenance 24 V power solution for PLCs, I/O modules, valves, relays and other 24 V control electronics.

In: 90-264VAC 47-63Hz  120-370VDCOut: 16VDC / 240mA / 3,84W / 145x38x22mmZolltarif 85044030 ChinaDALI Bus Power Supply (Desktop Type)

End of Life Product!! see LCM - 25/40/60
