Technical Information & Details for the MEAN WELL MDR-100-24 Power Supply Power Output: 96 W Output Voltage: 24 V DC Output Current: 4 A Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz Efficiency: up to 86% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 30 A @115 VAC / 60 A @230 VAC No-load Power Consumption: < 0.75 W Operating Temperature: −20 °C to +70 °C Cooling: Fanless natural convection Protections: Short circuit, Overload, Over voltage, Over temperature Additional Function: DC OK relay contact for status signaling Isolation Voltage: 3000 V AC Input to Output Dimensions (H x W x D): 100 mm x 55 mm x 90 mm Weight: approx. 420 g Safety & EMC Certificates: UL508, TUV EN62368-1, Class I Div 2 (Hazardous Locations) LED Indicator: Power On indicator Manufacturer Warranty: 3 Years Product Overview for the MEAN WELL MDR-100-24 The MEAN WELL MDR-100-24 is a reliable 96W industrial power supply designed for seamless DIN rail integration. A key technical advantage is its superior efficiency rating of 86%, which minimizes heat dissipation and enhances the overall lifespan of surrounding electronic components. This model is equipped with a specialized DC OK relay contact, allowing for active remote monitoring of the output status, which is vital for maintaining uptime in automated production lines. Its low standby power consumption makes it a "green" solution for modern control cabinets. Furthermore, the MDR-100-24 is built to last in tough environments, featuring Class I, Division 2 approval for use in hazardous locations and a wide operating temperature range. The slim 55mm housing ensures high power density in space-constrained installations, while the 3-year manufacturer warranty provides long-term peace of mind for system integrators and electrical engineers.
