• Output Power: 95.76 W (at 200–305 V AC) / 70 W (at 100–180 V AC)
• Output Voltage: 42 V DC
• Output Current: 2.28 A
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: Up to 88%
• Ripple & Noise: ≤ 300 mVp-p
• Inrush Current: COLD START 60 A @ 230 V AC
• No Load / Standby Power: < 0.5 W
• Operating Temperature: −40 °C to +90 °C (Case temperature Tcase)
• Cooling: Fanless free air convection
• Protections: Short circuit (Hiccup mode), Overload (Constant current limiting), Over voltage, Over temperature
• Isolation Voltage: 3750 V AC between Input and Output
• Dimming Interface: DALI-2 control technology per IEC62386 (D2-Type)
• Ingress Protection / Housing: IP67, Metal housing
• Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
• Weight: approx. 850 g
• Safety & EMC Standards: UL8750 (Type HL), EN61347-1, EN61347-2-13, EN55015, EAC, CB, CE
• AC Input Connection: 2-wire AC input cable (Standard model)
• Warranty: 5 Years

Information about MEAN WELL ELG-100-42D2

Architected for next-generation smart lighting infrastructure, the MEAN WELL ELG-100-42D2 provides standardized digital dimming functionality compliant with the DALI-2 protocol. Encapsulated in a heavy-duty aluminum chassis, its IP67 enclosure rating guarantees full protection against moisture, water jets, and airborne particulate ingress. The power supply maintains continuous high performance under severe environment conditions, surviving an extreme case temperature range of -40 °C to +90 °C. Specifiers in hazardous industrial fields benefit from its official UL8750 (Type HL) rating for Class I, Division 2 environments. Engineered for exceptional longevity, the unit includes a comprehensive 5 years factory warranty for operational reliability.
