HLN-80H-24A

Technical Information & Details for MEAN WELL GST90A24-P1M Power Supply Output Power: 90 W Output Voltage: 24 V DC Output Current: 3.75 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 89.5% Ripple & Noise: ≤ 200 mVp-p Inrush Current: max. 35 A @115 VAC / 70 A @230 VAC No-Load Power Consumption: < 0.15 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protections: Short circuit, Overload, Over voltage, Over temperature Overvoltage Category: Class I Power Unit (with FG) Isolation Voltage: 3000 V AC between Input and Output Dimensions (L x W x H): 145 mm x 60 mm x 32 mm Weight: approx. 450 g Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, BSMI, CCC, PSE, CB, CE, EAC, UKCA LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL GST90A24-P1M The MEAN WELL GST90A24-P1M is a highly reliable, energy-saving 90W desktop green AC-DC power adapter designed to deliver continuous and steady power to industrial equipment, automation systems, and commercial electronics. Built with a standard 3-pole IEC320-C14 AC inlet (Class I power unit) and an integrated active Power Factor Correction (PFC) circuit, this unit supplies a clean and stable 24V DC output voltage with a continuous rated current of 3.75 A. Enclosed in a durable 94V-0 flame-retardant plastic casing, it operates reliably across a wide temperature range of -30 °C to +70 °C under natural convection cooling. A key technical highlight of the GST90A series is its high efficiency of up to 89.5% combined with an ultra-low no-load power consumption below 0.15 W. This allows full compliance with strict global efficiency standards such as Energy Efficiency Level VI, EU ErP, and CoC Version 5. For safe operation, the adapter features full electronic protection against short circuits, overloads, overvoltage, and overtemperature conditions. Equipped with a standard P1M tuning fork DC plug (2.5 x 5.5 x 11 mm) and broad international safety approvals, the MEAN WELL GST90A24-P1M provides a long-lasting power solution supported by a 3-year manufacturer warranty.

Technical Information & Details for the MEAN WELL HLG-120H-24A Power Supply Rated Power: 120 W Output Voltage (DC): 24 V Rated Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency (typ.): 93 % Ripple & Noise (max.): 150 mVp-p Voltage Adjustment Range: 22 – 27 V Current Adjustment Range: 2.5 – 5 A Operating Temp. (Case): −40 °C to +80 °C IP Rating: IP65 Dimensions (L x W x H): 220 x 68 x 38.8 mm Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-120H-24A The MEAN WELL HLG-120H-24A is a high-performance 120W LED driver, widely regarded as a staple for 24V professional lighting systems. As an "A-Type" model, it is specifically designed for on-site customization. It features two internal potentiometers located under protective rubber stoppers, allowing installers to manually fine-tune the output voltage from 22V to 27V and calibrate the current limit from 2.5A to 5A to perfectly match the connected load. The unit operates in dual-mode constant voltage and constant current, providing exceptional stability whether it is powering 24V LED strips or direct COB LED arrays. Housed in a rugged IP65-rated aluminum enclosure, the HLG-120H-24A is built to withstand dust and moisture ingress, making it suitable for high-bay lighting, urban street lamps, and outdoor architectural accentuation. The fanless design ensures silent operation and efficient cooling through natural air convection. With a peak efficiency of 93% and built-in active PFC, the driver minimizes energy waste and optimizes power factor. It includes comprehensive safety mechanisms, such as short circuit, overcurrent, and overtemperature protections. Backed by a 7-year manufacturer warranty and carrying the "Type HL" rating for hazardous locations, this driver is a premier choice for mission-critical infrastructure and large-scale industrial projects.
