Technical Information & Details for MEAN WELL HLG-80H-12A Power Supply Output Power: 60 W Output Voltage: 12 V DC Output Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 88 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 70 A @ 230 VAC Operating Temperature: −40 °C to +80 °C (Case) Cooling: fanless free air convection Protection Functions: Short circuit, Over current, Over voltage, Over temperature Isolation Voltage: 3750 V AC (Input to Output) Dimensions (L x W x H): 195.6 mm x 61.5 mm x 38.8 mm Weight: approx. 840 g Safety & EMC Certificates: UL8750, EN61347-1, IP65, CE, EAC, KC Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-80H-12A The MEAN WELL HLG-80H-12A is a high-performance 60W power solution specifically engineered for versatility in demanding industrial and lighting environments. A key characteristic of this A-Type model is the user-adjustable output, featuring internal potentiometers that allow for the precise calibration of voltage and current levels directly on the device. It utilizes an advanced dual-mode output design, enabling operation in both Constant Voltage and Constant Current regions to suit diverse electrical requirements. The heavy-duty metal enclosure carries an IP65 rating, ensuring the unit remains fully protected against dust and water ingress in outdoor or damp settings. Technically, the power supply excels with built-in active Power Factor Correction and an 88% efficiency rating, resulting in minimal heat generation and energy-saving performance. With a typical life expectancy of over 62,000 hours and an industry-leading 7-year manufacturer warranty, it provides exceptional long-term stability. Its Type HL classification further qualifies it for use in hazardous locations, making it a premier choice for high-reliability applications such as LED street lighting, parking facility systems, and greenhouse automation.

Technical Information & Details for the MEAN WELL HLG-120H-12A Power Supply Rated Power: 120 W Output Voltage (DC): 12 V Rated Current: 10 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency (typ.): 92 % Ripple & Noise (max.): 150 mVp-p Voltage Adjustment Range: 10.8 – 13.5 V Current Adjustment Range: 5 – 10 A Operating Temp. (Case): −40 °C to +80 °C IP Rating: IP65 Dimensions (L x W x H): 220 x 68 x 38.8 mm Manufacturer Warranty: 7 Years Details about the MEAN WELL HLG-120H-12A The MEAN WELL HLG-120H-12A is a high-grade 120W LED driver engineered for industrial durability and versatility. As an "A-Type" model, it is specifically designed for on-site customization. It features two internal potentiometers located under protective rubber stoppers, allowing installers to manually fine-tune the output voltage and calibrate the current limiting point to match specific LED array requirements. The unit features a dual-mode constant voltage and constant current output, ensuring exceptional stability across different load configurations. Housed in a rugged IP65-rated aluminum enclosure, the HLG-120H-12A provides effective protection against dust and moisture, making it a premier choice for high-bay lighting, urban street lamps, and outdoor architectural installations. The fanless design enables completely silent operation and efficient cooling through natural air convection. With an efficiency of up to 92% and built-in active PFC, the driver minimizes energy loss while meeting global power factor standards. It includes comprehensive safety mechanisms, including short circuit, overcurrent, overvoltage, and overtemperature protections. Backed by a 7-year manufacturer warranty and a lifespan exceeding 62,000 hours, this "Type HL" rated driver is ideal for mission-critical installations in parking spaces, industrial facilities, and horticultural environments.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-60 series. Technical Information & Details of the MEAN WELL LPV-60-24 Power Supply Output Power: 60 W Output Voltage: 24 V DC Output Current: 2.5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 86 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 60 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 32 mm x 42.5 mm x 162.5 mm Weight: approx. 420 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-60-24 The MEAN WELL LPV-60-24 is a powerful LED power supply with 60 W and stable 24 V DC / 2.5 A output voltage. It excels with excellent efficiency up to 86 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, modules, outdoor lighting, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-60-24 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Technical Information & Details about the MEAN WELL LPV-100-24 Power Supply Rated output power: 100.8 W DC output voltage: 24 V DC Rated output current: 4.2 A Current range: 0 – 4.2 A Input voltage range: 90 – 264 V AC (127 – 370 V DC), 47 – 63 Hz Efficiency (typical): about 88 % Ripple & noise (max.): ≤ 150 mVp-p Output voltage range (O.V.P. region): 27.6 – 32.4 V DC Voltage tolerance: ±5.0 % Line regulation: ±2.0 % Load regulation: ±5.0 % Setup, rise time: 2000 ms, 25 ms at 230 V AC / 115 V AC (first cold start) Hold-up time (typ.): 50 ms at 230 V AC / 14 ms at 115 V AC (full load) AC input current (typ.): 2.2 A at 115 V AC / 1.2 A at 230 V AC Inrush current (typ.): 75 A at 230 V AC (cold start, twidth ≈ 700 μs) Leakage current: < 0.25 mA at 240 V AC Overload protection: 110 – 150 % of rated output power, hiccup mode, auto recovery after fault removal Overvoltage protection: shut down output voltage at 27.6 – 32.4 V, re‑power on to recover Operating temperature: −25 °C to +70 °C (derating required, see curve) Operating humidity: 20 – 90 % RH, non‑condensing Storage conditions: −40 °C to +80 °C, 10 – 95 % RH Cooling method: free air convection (fanless) Withstand voltage: 3000 V AC between input and output Isolation resistance: > 100 MΩ at 500 V DC, 25 °C, 70 % RH Ingress protection rating: IP67, fully encapsulated plastic case Dimensions (L x W x H): 190 mm x 52 mm x 37 mm Weight: approx. 610 g Vibration resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) EMC emission: BS EN/EN 55032 Class B, BS EN/EN 61000‑3‑2 Class A (≤80 % load), BS EN/EN 61000‑3‑3 EMC immunity: BS EN/EN 61000‑4‑2,‑3,‑4,‑5,‑6,‑8,‑11; BS EN/EN 55035 Safety approvals: UL 8750, CSA C22.2 No. 250.13‑12, UL 879, CSA C22.2 No. 207‑M89, BIS IS 15885, IEC/BS EN/EN 62368‑1, EAC Case design: fully isolated, encapsulated plastic case for damp and dusty environments MTBF (typical): 4,497,100 h (Telcordia SR‑332, 25 °C) Manufacturer warranty: 2 years About the MEAN WELL LPV-100-24 The MEAN WELL LPV-100-24 is a 100 W class constant‑voltage switching power supply that provides a regulated 24 V DC output at up to 4.2 A, fully encapsulated in an IP67 plastic housing for reliable use in harsh environments. Its universal AC input range, high efficiency, short‑circuit, overload and overvoltage protection, and fanless free air convection make it suitable for indoor and sheltered outdoor applications. With compact dimensions, strong isolation and broad safety and EMC approvals, LPV-100-24 is a robust 24 V source for LED strips, signage, control systems and other low‑voltage equipment that require a rugged, dust‑ and splash‑proof power supply.

In: 100-305VAC 47-63Hz 142-431VDC / Eff. 92% / 140x63x32mmOut: 12V 8A, 4-8A strom einstellbar , Arbeitet im CC und CV modus, IP67

Technische Eigenschaften des MEAN WELL RSP-320-5 Leistung: 300 W Eingangsbereich: 88 – 264 VAC  Ausgangsspannung: 5 VDC aktive PFC-Funktion hoher Wirkungsgrad von bis zu 83% Kühlung durch built-in DC-Lüfter LED-Lichtanzeige für Power-On Schutz vor Kurzschluss, Überlast, Überspannung und Überhitzung Informationen zum MEAN WELL RSP-320-5 Beim Mean Well RSP-320-5 handelt es sich um ein geschlossenes Schaltnetzteil mit einer Nennleistung von 300 Watt. Es verfügt über einen Weitbereichseingang von 88 bis 264 VAC (Derating bei 88 – 100 VAC) und gibt eine stabilisierte Sekundärspannung von 5 VDC aus. Die Produktreihe von MeanWell ist für die Direktmontage in Maschinen oder Geräten vorgesehen. Mit einer schlanken Bauweise und einer besonders niedrigen Profilhöhe von 30mm können die Schaltnetzteile von Mean Well RSP-320-Serie ohne großen Platzverbrauch problemlos in Endgeräten installiert werden. Darüber hinaus zeichnet sich die Netzteilreihe von MeanWell durch die integrierte aktive PFC-Funktion aus, welche für eine zuverlässige und stabile Stromversorgung sorgt. Die RSP-320-Serie ist des weiteren mit einer LED-Leuchtanzeige für Power-On ausgestattet. Durch die Kühlung mittels eingebautem DC-Lüfter arbeiten die Direktmontage-Schaltnetzteile von Mean Well bei Umgebungstemperaturen von -30°C bis+70°C (Derating ab +50°C) und bei einer relativen Luftfeuchtigkeit zwischen 20 – 90%. Dank der einstellbaren Lüfterleistung gewährleistet die RSP-320-Serie eine effiziente Stromversorgung beim Betrieb. Ein hoher Wirkungsgrad von bis zu 90% wird erzielt. Weiterhin verfügt die Mean Well RSP-320-Serie über einen Schutz gegen Kurzschluss, Überlast, Überspannung sowie Überhitzung. Zudem ist die Netzteilreihe konform mit allen grundlegenden Sicherheitsstandards und weiteren Anforderungen (EN62368-1, EN55032, EN61000-3-2, EN61000-3-3).
