• Output Power: 81 W
• Output Voltage: 30 V DC
• Output Current: 2.7 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 91 %
• Ripple & Noise: max. 200 mVp-p
• Inrush Current: 70 A at 230 V AC
• Operating Temperature: −40 °C to +80 °C (Case)
• Cooling: fanless free air convection
• Protection Functions: Short circuit, Over current, Over voltage, Over temperature
• Isolation Voltage: 3750 V AC (Input to Output)
• Dimensions (L x W x H): 195.6 mm x 61.5 mm x 38.8 mm
• Weight: approx. 840 g
• Safety & EMC Certificates: UL8750, EN61347-1, IP65, CE, EAC, KC
• Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-80H-30A

The MEAN WELL HLG-80H-30A is a high-performance 81W AC/DC driver designed for professional reliability in demanding lighting and industrial applications. A standout feature of this A-Type model is its manual adjustability, allowing users to fine-tune the output voltage and current levels via internal potentiometers located beneath protective rubber stoppers. The unit utilizes an advanced dual-mode output design, providing high efficiency in both Constant Voltage and Constant Current regions. Housed in a ruggedized metal enclosure with an IP65 rating, it is well-suited for environments where protection against dust and water ingress is required. Technically, the HLG-80H-30A excels with built-in active Power Factor Correction and an impressive 91% efficiency rating, ensuring minimal energy loss and silent, fanless operation. With a typical life expectancy exceeding 62,000 hours and an industry-leading 7-year manufacturer warranty, this 30V model is a premier solution for high-reliability projects such as outdoor LED displays, architectural lighting, and industrial automation control.
