PLC-100-12

Technical Information & Details about the MEAN WELL LPV-100-24 Power Supply Rated output power: 100.8 W DC output voltage: 24 V DC Rated output current: 4.2 A Current range: 0 – 4.2 A Input voltage range: 90 – 264 V AC (127 – 370 V DC), 47 – 63 Hz Efficiency (typical): about 88 % Ripple & noise (max.): ≤ 150 mVp-p Output voltage range (O.V.P. region): 27.6 – 32.4 V DC Voltage tolerance: ±5.0 % Line regulation: ±2.0 % Load regulation: ±5.0 % Setup, rise time: 2000 ms, 25 ms at 230 V AC / 115 V AC (first cold start) Hold-up time (typ.): 50 ms at 230 V AC / 14 ms at 115 V AC (full load) AC input current (typ.): 2.2 A at 115 V AC / 1.2 A at 230 V AC Inrush current (typ.): 75 A at 230 V AC (cold start, twidth ≈ 700 μs) Leakage current: < 0.25 mA at 240 V AC Overload protection: 110 – 150 % of rated output power, hiccup mode, auto recovery after fault removal Overvoltage protection: shut down output voltage at 27.6 – 32.4 V, re‑power on to recover Operating temperature: −25 °C to +70 °C (derating required, see curve) Operating humidity: 20 – 90 % RH, non‑condensing Storage conditions: −40 °C to +80 °C, 10 – 95 % RH Cooling method: free air convection (fanless) Withstand voltage: 3000 V AC between input and output Isolation resistance: > 100 MΩ at 500 V DC, 25 °C, 70 % RH Ingress protection rating: IP67, fully encapsulated plastic case Dimensions (L x W x H): 190 mm x 52 mm x 37 mm Weight: approx. 610 g Vibration resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) EMC emission: BS EN/EN 55032 Class B, BS EN/EN 61000‑3‑2 Class A (≤80 % load), BS EN/EN 61000‑3‑3 EMC immunity: BS EN/EN 61000‑4‑2,‑3,‑4,‑5,‑6,‑8,‑11; BS EN/EN 55035 Safety approvals: UL 8750, CSA C22.2 No. 250.13‑12, UL 879, CSA C22.2 No. 207‑M89, BIS IS 15885, IEC/BS EN/EN 62368‑1, EAC Case design: fully isolated, encapsulated plastic case for damp and dusty environments MTBF (typical): 4,497,100 h (Telcordia SR‑332, 25 °C) Manufacturer warranty: 2 years About the MEAN WELL LPV-100-24 The MEAN WELL LPV-100-24 is a 100 W class constant‑voltage switching power supply that provides a regulated 24 V DC output at up to 4.2 A, fully encapsulated in an IP67 plastic housing for reliable use in harsh environments. Its universal AC input range, high efficiency, short‑circuit, overload and overvoltage protection, and fanless free air convection make it suitable for indoor and sheltered outdoor applications. With compact dimensions, strong isolation and broad safety and EMC approvals, LPV-100-24 is a robust 24 V source for LED strips, signage, control systems and other low‑voltage equipment that require a rugged, dust‑ and splash‑proof power supply.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-60 series. Technical Information & Details of the MEAN WELL LPV-60-12 Power Supply Output Power: 60 W Output Voltage: 12 V DC Output Current: 5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 83 % Ripple & Noise: ≤ 120 mVp-p Inrush Current: max. 60 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 32 mm x 42.5 mm x 162.5 mm Weight: approx. 420 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-60-12 The MEAN WELL LPV-60-12 is a powerful LED power supply with 60 W and stable 12 V DC / 5 A output voltage. It excels with excellent efficiency up to 83 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, modules, outdoor lighting, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-60-12 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Technical Information & Details about the MEAN WELL HDR-30-24 Power Supply Output Power: 36 W Output Voltage: 24 V DC Output Current: 1.5 A Current Range: 0 – 1.5 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: up to 89 % Ripple & Noise: ≤ 150 mVp-p Output Voltage Adjustment Range: 21.6 – 29 V DC Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Setup, Rise Time: 500 ms, 50 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) Inrush Current: 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Cooling: fanless free air convection Protection Functions: short circuit (hiccup mode, auto recovery), overload (constant current limiting 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 35 mm x 90 mm x 54.5 mm Weight: approx. 130 g Housing Material: insulating plastic, Class II Mounting: DIN rail TS35/7.5 or TS35/15 Safety & EMC Certifications: UL 62368-1, UL 508, TUV BS EN/EN 61558-2-16, BS EN/EN 61558-1, IEC 62368-1, EAC TP TC 004, BSMI, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000-6-2, BS EN/EN 61204-3 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 years About the MEAN WELL HDR-30-24 The MEAN WELL HDR-30-24 is a 30 W ultra-slim DIN-rail power supply that provides a stable 24 V DC / 1.5 A output in a narrow 35 mm (2 SU) housing, ideal for compact distribution boards and space-saving control cabinets. With its wide 85–264 V AC / 120–370 V DC input range and high efficiency up to 89 %, it offers an energy-efficient 24 V control voltage source for building automation, home automation, and light industrial control systems. The adjustable 21.6–29 V output range allows precise tuning of the 24 V bus to compensate for voltage drops across wiring runs and to supply PLCs, sensors, relays, and I/O modules with reliable power. Its Class II plastic enclosure provides double insulation for enhanced user safety and simplifies installation by eliminating the need for a protective earth connection. Fanless free air convection, very low no-load power consumption below 0.3 W, a wide operating temperature range from −30 °C to +70 °C, and comprehensive protection and certification features make the HDR-30-24 a robust, long-life 24 V power solution for household and industrial automation applications.

Technical Information & Details of the MEAN WELL HDR-15-12 Power Supply Output Power: 15 W Output Voltage: 12 V DC Output Current: 1.25 A Output Current Range: 0 – 1.25 A Output Voltage Adjustment Range: 10.8 – 13.8 V DC Ripple & Noise: ≤ 120 mVp-p Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational) Input Frequency: 47 – 63 Hz Efficiency (typ.): 85 % AC Input Current (typ.): 0.5 A @115 V AC / 0.25 A @230 V AC Inrush Current (typ.): 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Overload Protection: 110 – 145 % of rated power, constant current limiting within 50 – 100 % of rated output voltage, hiccup mode when Vout < 50 %, auto recovery Overvoltage Protection: 14.2 – 16.2 V DC, shut off output, clamping by zener diode Operating Temperature: −30 °C to +70 °C (derating according to curve) Operating Humidity: 20 – 90 % RH, non-condensing Storage Temperature / Humidity: −40 °C to +85 °C, 10 – 95 % RH, non-condensing Temperature Coefficient: ±0.03 % / °C (0 – 50 °C) Vibration Resistance: 10 – 500 Hz, 2 G, 10 min./cycle, 60 min. per axis (X, Y, Z) Operating Altitude: up to 2,000 m (derating above 2,000 m) Isolation Voltage: 4 kVAC (input–output) Isolation Resistance: > 100 MΩ @500 VDC, 25 °C, 70 % RH Dimensions (W x H x D): 17.5 mm x 90 mm x 54.5 mm Weight: approx. 74 g Mounting: DIN rail TS35/7.5 or TS35/15, ultra-slim 1-SU step-shape housing Housing / Isolation Class: plastic housing, isolation Class II, LPS (Limited Power Source) Front Indicators / Controls: LED indicator for power on, adjustable DC output voltage Safety Approvals: UL62368‑1, UL508, TUV BS EN/EN61558‑2‑16, BS EN/EN61558‑1, IEC62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252 (Part1) (except 48 V) EMC Emission: EN55032 (CISPR32), CNS15936 Class B; EN61000‑3‑2, EN61000‑3‑3 EMC Immunity: EN55035, EN61000‑6‑2, EN61204‑3; EN61000‑4‑2/3/4/5/6/8/11 MTBF (typ.): 3,724,300 h (Telcordia SR‑332, 25 °C) / 1,166,100 h (MIL‑HDBK‑217F, 25 °C) Warranty: 3 years Information about the MEAN WELL HDR-15-12 The MEAN WELL HDR‑15‑12 is a slim 15 W DIN rail power supply providing 12 V DC at up to 1.25 A, built in an ultra‑compact 17.5 mm (1 SU) plastic enclosure for space‑saving installations on TS35/7.5 or TS35/15 rails. Its wide 85–264 V AC input (with 277 V AC operational) and adjustable 12 V output range from 10.8 to 13.8 V make it suitable for a variety of 12 V control, sensor and logic applications in household and industrial environments. Thanks to a typical efficiency of 85 % and fanless convection cooling, the HDR‑15‑12 operates from −30 °C to +70 °C when derating is applied, which is ideal for compact distribution boards and building automation panels. With constant‑current overload protection, overvoltage shutdown, low no‑load power consumption and a comprehensive set of safety and EMC certifications, it offers a cost‑effective and standards‑compliant 12 V DIN rail supply for household control systems, building automation and small industrial control systems.

60W LED Schaltnetzteile 60W  Single Output LED Power Supply

100W LED Schaltnetzteile 100W  Single Output LED Power Supply
