SNP250-12VL-1

Technical Information & Details about the MEAN WELL LPV-100-12 Power Supply Rated output power: 102 W DC output voltage: 12 V DC Rated output current: 8.5 A Current range: 0 – 8.5 A Input voltage range: 90 – 264 V AC (127 – 370 V DC), 47 – 63 Hz Efficiency (typical): about 87 % Ripple & noise (max.): ≤ 120 mVp-p Output voltage range (O.V.P. region): 13.8 – 16.2 V DC Voltage tolerance: ±5.0 % Line regulation: ±2.0 % Load regulation: ±5.0 % Setup, rise time: 2000 ms, 25 ms at 230 V AC / 115 V AC (first cold start) Hold-up time (typ.): 50 ms at 230 V AC / 14 ms at 115 V AC (full load) AC input current (typ.): 2.2 A at 115 V AC / 1.2 A at 230 V AC Inrush current (typ.): 75 A at 230 V AC (cold start, twidth ≈ 700 μs) Leakage current: < 0.25 mA at 240 V AC Overload protection: 110 – 150 % of rated output power, hiccup mode, auto recovery after fault removal Overvoltage protection: shut down output voltage at 13.8 – 16.2 V, re‑power on to recover Operating temperature: −25 °C to +70 °C (derating required, see curve) Operating humidity: 20 – 90 % RH, non‑condensing Storage conditions: −40 °C to +80 °C, 10 – 95 % RH Cooling method: free air convection (fanless) Withstand voltage: 3000 V AC between input and output Isolation resistance: > 100 MΩ at 500 V DC, 25 °C, 70 % RH Ingress protection rating: IP67, fully encapsulated plastic case Dimensions (L x W x H): 190 mm x 52 mm x 37 mm Weight: approx. 610 g Vibration resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) EMC emission: BS EN/EN 55032 Class B, BS EN/EN 61000‑3‑2 Class A (≤80 % load), BS EN/EN 61000‑3‑3 EMC immunity: BS EN/EN 61000‑4‑2,‑3,‑4,‑5,‑6,‑8,‑11; BS EN/EN 55035 Safety approvals: UL 8750, CSA C22.2 No. 250.13‑12, UL 879, CSA C22.2 No. 207‑M89, BIS IS 15885, IEC/BS EN/EN 62368‑1, EAC Case design: fully isolated, encapsulated plastic case for damp and dusty environments MTBF (typical): 4,497,100 h (Telcordia SR‑332, 25 °C) Manufacturer warranty: 2 years About the MEAN WELL LPV-100-12 The MEAN WELL LPV-100-12 is a 100 W class constant‑voltage switching power supply that provides a regulated 12 V DC output at up to 8.5 A, fully encapsulated in an IP67 plastic housing for reliable use in harsh environments. Its universal AC input range, high efficiency, short‑circuit, overload and overvoltage protection, and fanless free air convection make it well suited for indoor and sheltered outdoor installations. With compact dimensions, strong isolation and comprehensive safety and EMC approvals, LPV-100-12 is a robust 12 V supply for LED‑related fixtures, signage, control electronics and other low‑voltage systems that require a rugged, dust‑ and splash‑proof power source.

Technical Information & Details for MEAN WELL LPV-150-12 Power Supply Output power: 120 W Output voltage: 12 V DC Output current: 10 A Output current range: 0 – 10 A Output characteristic: constant voltage Ripple & noise: max. 200 mVp-p Voltage tolerance: ± 1% Input voltage range: 180 – 305 V AC / 254 – 431 V DC, 47 – 63 Hz Efficiency: typ. 87% AC input current: 1.7 A @ 230 V AC / 1.5 A @ 277 V AC Inrush current (cold start): 60 A @ 230 V AC (twidth = 900 µs, 50% Ipeak) Leakage current: max. 0.25 mA @ 240 V AC Setup & rise time: 500 ms, 50 ms @ 230 V AC / 277 V AC Hold-up time: 18 ms @ 230 V AC / 20 ms @ 277 V AC (full load) Overload protection: 110 – 150% of rated output power, hiccup mode, auto recovery Over-voltage protection: 13.5 – 18 V DC, shutdown with automatic recovery after fault removal Over-temperature protection: output shutdown, automatic restart after cooling down Operating temperature: −25 °C to +65 °C (power derating according to derating curve) Operating humidity: 20 – 90% RH, non-condensing Storage conditions: −40 °C to +80 °C, 10 – 95% RH Temperature coefficient: ± 0.03% / °C Cooling: fanless, cooling by free air convection Case material: fully insulated, flame-retardant plastic housing (UL 94V-0) Ingress protection: IP67 Dielectric strength: 3,000 V AC (input to output) Insulation resistance: > 100 MΩ @ 500 V DC, 25 °C, 70% RH Vibration resistance: 10 – 500 Hz, 2 G, 10 min./cycle along X, Y, Z axes MTBF: 3,361,200 h (Telcordia SR-332, 25 °C) Dimensions (L x W x H): 191 mm x 63 mm x 37.5 mm Weight: 0.79 kg Cable connections: primary SJTW 14 AWG, secondary SJTW 18 AWG, pre‑wired leads Recommended mounting: horizontal mounting, according to case LPC-150 drawing Safety standards: UL 8750, CSA C22.2 No. 250.13-12, UL 879, CSA C22.2 No. 207-M89, BIS IS 15885 (for LPV-150-12/-24), IEC/EN 62368-1, EAC EMC standards: EN 55032 (CISPR 32) Class B, EN 55035, EN 61000-3-2 Class A (≤ 80% load), EN 61000-3-3, EN 61000-4-2/3/4/5/6/8/11 Device class: Class II, double-insulated LED power supply, no earth (FG) connection Application environment: indoor use or outdoor use without direct sunlight Manufacturer warranty: 2 years Information about MEAN WELL LPV-150-12 The MEAN WELL LPV-150-12 is a 150 W constant voltage LED power supply with a regulated 12 V DC output and up to 10 A output current, designed specifically for LED strips, architectural lighting, signage and decorative lighting systems. Its key strengths include the fully encapsulated IP67 housing for reliable operation in damp and wet locations, the fanless free‑air convection design for silent and low‑maintenance use, and comprehensive protection features such as short-circuit, overload, over-voltage and over-temperature protection with automatic recovery. With a wide 180–305 V AC input range, high efficiency and long service life, the LPV-150-12 is ideally suited for professional LED installations that require a stable 12 V supply and dependable 24/7 operation in both indoor and protected outdoor environments.
