Technical Information & Details for the MEAN WELL SDR-75-12 Power Supply Output Power: 76.8 W Output Voltage: 12 V DC Output Current: 6.3 A Input Voltage Range: 88 – 264 V AC / 124 – 370 V DC, 47 – 63 Hz Efficiency: 90% Ripple & Noise: ≤ 100 mVp-p Inrush Current: 30 A @ 115 VAC / 50 A @ 230 VAC Peak Load Capability: 150% (112.5 W) for up to 3 seconds Operating Temperature: -30 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Voltage Adustment Range: 12 – 14 V Isolation Voltage: 3000 V AC I/P-O/P Dimensions (H x W x D): 125.2 mm x 32 mm x 102 mm Weight: 510 g Safety & EMC Certificates: UL 508, TUV EN62368-1, CB, EAC, CE LED Display: DC OK indicator Manufacturer Warranty: 3 Years The MEAN WELL SDR-75-12 stands out as a high-performance solution within the slim DIN rail segment, specifically engineered for industrial environments where reliability and space optimization are paramount. One of its most significant strengths is the 150% peak load capability, which allows the unit to deliver up to 112.5 W for 3 seconds. This unique characteristic is essential for powering loads with high startup currents, such as motors or capacitive loads, ensuring the system remains stable without requiring a larger, more expensive power supply. Its ultra-slim 32mm width facilitates high-density installations on TS-35/7.5 or 15 rails, making it an ideal choice for compact control cabinets and advanced automation systems. Beyond its physical dimensions, the SDR-75-12 boasts an impressive efficiency of 90%, which significantly reduces power dissipation and heat generation within the enclosure. This fanless design relies entirely on natural air convection for cooling and is rated for a broad operating temperature range of -30 °C to +70 °C, ensuring consistent performance in harsh thermal environments. The unit is equipped with comprehensive protection circuits, including short circuit, overvoltage, and over-temperature safeguards with an auto-recovery feature. With global certifications like UL 508 for industrial control equipment and heavy industry-level EMC immunity, this power supply provides a robust and future-proof energy source for PLC systems, sensors, and industrial IoT applications.

Technical Information & Details for MEAN WELL HLG-240H-24A Power Supply Output Power: 240 W Output Voltage: 24 V DC Voltage Adj. Range: 22.4 V – 25.6 V (via built-in potentiometer) Rated Current: 10 A Current Adj. Range: 5 A – 10 A (via built-in potentiometer) Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: 93 % (typ.) Ripple & Noise: max. 150 mVp-p Operating Temperature: −40 °C to +90 °C (case temperature) Ingress Protection: IP65 (Dust-tight & Water jet protected) Typical Lifetime: > 62,000 hours Dimensions (L x W x H): 244.2 mm x 68 mm x 38.8 mm Manufacturer Warranty: 7 years Information about the MEAN WELL HLG-240H-24A The MEAN WELL HLG-240H-24A is a high-performance 240W AC/DC LED driver renowned for its dual-mode constant voltage and constant current output strategy. This A-type model is specifically engineered for flexibility, featuring internal potentiometers that allow for the manual fine-tuning of output voltage and current levels to perfectly suit the requirements of connected LED systems. Encased in a ruggedized metal housing with an IP65 rating, it is highly durable for both indoor and outdoor applications such as LED street lighting, parking space illumination, and greenhouse lighting. The unit achieves a superior efficiency of 93 % and utilizes a fanless thermal design, ensuring silent and reliable operation under free air convection at temperatures up to +90 °C. Furthermore, its Type HL certification qualifies it for use in Class I, Division 2 hazardous locations. Backed by an industry-leading 7-year manufacturer warranty and a service life expectancy of more than 62,000 hours, the HLG-240H-24A provides a robust and maintenance-free power solution for large-scale architectural and high-bay industrial projects.

Technical Information & Details for the MEAN WELL SDR-120-24 Power Supply Output Power: 120 W (180 W Peak) Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 88 – 264 V AC / 124 – 370 V DC, 47 – 63 Hz Efficiency: 90.5% Ripple & Noise: ≤ 100 mVp-p Inrush Current: 35 A @115 VAC / 70 A @230 VAC Voltage Adjustment Range: 24 – 28 V Operating Temperature: −25 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Power Factor: PF > 0.93 / 230 VAC Isolation Voltage: 3000 V AC between input and output Dimensions (W x H x D): 40 mm x 125.2 mm x 113.5 mm Weight: 0.67 Kg Safety & EMC Certificates: UL 508, EN62368-1, SEMI F47, GL, EAC, CE Status Monitoring: Built-in DC OK relay contact and LED indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL SDR-120-24 The MEAN WELL SDR-120-24 is a premier industrial-grade DIN rail power supply engineered for superior efficiency and space-saving performance. A standout feature of this model is its 150% peak load capability, allowing the unit to deliver up to 180W for 3 seconds. This power reserve is critical for starting demanding inductive loads, such as DC motors or heavy-duty relays, without causing system-wide voltage drops or premature shutdowns. With a slim 40mm width, it maximizes cabinet space, while its 90.5% high efficiency ensures minimal heat generation, facilitating reliable operation through simple natural air convection. In addition to its physical robustness, the SDR-120-24 includes active Power Factor Correction (PFC), optimizing power quality and meeting strict industrial harmonics standards. For seamless integration into automated systems, it features a built-in DC OK relay contact, providing a hardware-based signal to monitor the health of the output voltage remotely. The power supply is fully fortified with protections against short circuits, overloads, over-voltage, and excessive temperatures, ensuring maximum system uptime. Backed by international safety certifications and a 100% full load burn-in test, this unit provides a dependable and long-lasting energy solution for complex factory automation and process control systems.

Technical Information & Details for the LX-4692-DA Dimmer Output Power: 120 – 384 W Output Voltage: 12 – 48 V DC Output Current: 1 x 10 A (max. 20 A total via parallel connection) Input Voltage Range: 12 – 48 V DC Efficiency: High-performance PWM constant voltage dimming Dimming Range: 0.1% – 100% DALI Consumption: 2 mA Dimming Interfaces: DALI-2 (DT6), AC Push, 0/1-10V, Phase Cut (Triac) Operating Temperature: −20 °C to +50 °C Cooling: Natural air convection Protection Functions: Short circuit, Overload, Moisture resistant (IP20) Wiring Specifications: 0.5 – 2.5 mm² wire cross-section Control Protocol: IEC 62386-101:2014, 102:2014, 207 Ed2 Dimensions (L x W x H): 170 mm x 53.4 mm x 28 mm Waterproof Grade: IP20 Safety & EMC Certificates: CE, RoHS, DALI-2 compliant Address Assignment: 1 DALI address automatically assigned by master Manufacturer Warranty: 5 Years Information regarding the LX-4692-DA Dimmer The LX-4692-DA stands out as a highly versatile 4-in-1 multifunction LED dimmer engineered to bridge the gap between various control protocols and modern LED lighting systems. This sophisticated device supports DALI-2, AC Push-Dim, 0/1-10V, and Phase-Cut (Triac) dimming interfaces, allowing for unprecedented flexibility in installation. By utilizing an integrated DIP switch, users can manually select the desired dimming mode before wiring, ensuring the unit serves as a universal solution for constant voltage applications ranging from 12V to 48V DC. Its ultra-slim profile and robust build quality make it an ideal choice for professional architectural lighting where space is at a premium but high-performance control is non-negotiable. Technically superior, the LX-4692-DA features a precise PWM output capable of achieving a smooth, flicker-free dimming range from 0.1% to 100%. The unit is designed with dual terminal groups in parallel, enabling a total load capacity of up to 20A, which is perfect for driving high-density LED strips or extensive lighting arrays. It is fully compliant with the latest IEC 62386 DALI-2 standards for DT6 devices, ensuring seamless interoperability with all major DALI masters on the market. Additionally, the inclusion of Phase-Cut compatibility means it can be integrated into existing residential circuits using standard universal dimmers, providing a future-proof upgrade path for smart building automation and industrial lighting environments.
