• Output Power: 172.5 W
• Output Voltage: 15 V DC
• Output Current: 11.5 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 92%
• Ripple & Noise: ≤ 150 mVp-p
• Inrush Current: Max. 65 A @ 230 VAC (Cold start)
• Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC
• Operating Temperature: -40 °C to +90 °C (Case temperature)
• Cooling: Fanless natural convection
• Protection Functions: Short circuit, Overload (Constant current limiting), Over voltage, Over temperature
• IP Rating: IP65 (Dust tight and protected against water jets)
• Adjustability: Voltage (13.5–17V) and current (5.75–11.5A) adjustable via built-in potentiometers
• Isolation Voltage: 3750 V AC between input and output
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: Approx. 1150 g
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, EN55015, EAC, CB, CE
• Lifetime: > 62,000 hours (at Tcase ≤ 75 °C)
• Manufacturer Warranty: 7 Years

Information about MEAN WELL HLG-185H-15A

The MEAN WELL HLG-185H-15A is a premier 172.5W LED driver engineered for superior reliability in high-demand industrial environments. This A-Type model is specifically designed for users who require manual control, featuring built-in potentiometers that allow for the fine-tuning of both output voltage (13.5V to 17V) and current levels (5.75A to 11.5A). Encased in a rugged metal housing with an IP65 rating, it provides exceptional protection against dust and moisture, making it ideal for both indoor and outdoor installations. Its fanless design, coupled with a high efficiency of 92%, ensures stable performance across a wide temperature spectrum up to a case temperature of +90 °C. Equipped with active power factor correction (PFC) and supported by an industry-leading 7-year manufacturer warranty, the HLG-185H-15A is a sustainable and maintenance-free choice for mission-critical applications such as LED street lighting, high-bay illumination, and greenhouse systems.
