• Output Power: 95.76 W
• Output Voltage: 42 V DC
• Output Current: 2.28 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 93 %
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 60 A @ 230 VAC
• Leakage Current: < 0.75 mA / 277 VAC
• Operating Temperature: −40 °C to +80 °C (Case temperature)
• Cooling: Fanless free air convection
• Protection Functions: Short circuit, Over current, Over voltage, Over temperature
• IP Rating: IP67 (fully dust-tight and waterproof)
• Dimming Technology: 3-in-1 dimming (1–10V DC, 10V PWM signal, or resistance)
• Isolation Voltage: 3750 V AC (Input to Output)
• Dimensions (L x W x H): 220 mm x 68 mm x 38.8 mm
• Weight: approx. 1.12 kg
• Safety & EMC Certificates: UL8750, TUV EN61347-1, EN61347-2-13, PSE, KC, EAC, CB, CE
• Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-100H-42B

The MEAN WELL HLG-100H-42B is a premium 96W LED driver designed for superior reliability and advanced dimming control in professional lighting applications. This "B-Type" model is distinguished by its integrated 3-in-1 dimming technology, providing installers with the flexibility to regulate light output via a 1–10V DC signal, 10V PWM signal, or external resistance. Engineered for extreme durability, the unit features a rugged metal housing with an IP67 rating, ensuring total protection against dust ingress and making it resistant to water immersion, which is critical for high-exposure outdoor installations. A core technical advantage is the dual-mode constant voltage and constant current output, allowing the driver to seamlessly adapt to various LED configuration requirements. With an efficiency of up to 93 % and a built-in active PFC function, it minimizes energy loss and adheres to stringent global power factor standards. The fanless design enables completely silent operation and maintains high reliability even at extreme case temperatures up to +80 °C. Backed by a typical lifetime of over 62,000 hours and an industry-leading 7-year manufacturer warranty, the HLG-100H-42B is a premier choice for high-reliability systems such as industrial high-bay lighting, urban street lamps, and sophisticated greenhouse lighting systems.
