Technical Information & Details for the MEAN WELL HLG-100H-54A Power Supply
- Output Power: 95.58 W
- Output Voltage: 54 V DC
- Output Current: 1.77 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency: 93 %
- Ripple & Noise: ≤ 200 mVp-p
- Leakage Current: < 0.75 mA / 277 VAC
- Operating Temperature: −40 °C to +80 °C (T-case)
- Ingress Protection: IP65
- Adjustability: Voltage (49–58V) and current (1.1–1.77A) adjustable via internal potentiometers
- Safety Standards: UL8750, CSA C22.2, BS EN/EN 61347-1, GB19510.1, EAC
- Manufacturer Warranty: 7 Years
Details about the MEAN WELL HLG-100H-54A
The MEAN WELL HLG-100H-54A is a high-grade 96W LED driver engineered for industrial environments where stability and precise power delivery are paramount. It features a sophisticated dual-mode constant voltage and constant current output, providing maximum flexibility to drive either high-voltage LED arrays or complex lighting systems requiring a steady power source.
A key advantage of the "A-Type" configuration is its on-board adjustability. The unit is equipped with two internal potentiometers located under protective rubber stoppers in the aluminum housing. These allow installers to manually fine-tune the output voltage from 49V to 58V and the current limit from 1.1A to 1.77A. This level of control is essential for compensating for voltage drops over long cable runs or setting a fixed output intensity without external dimmers.
The driver is housed in a rugged IP65-rated metal enclosure, ensuring high resistance to dust and moisture ingress. With a peak efficiency of 93% and a built-in active PFC function, it minimizes energy loss and thermal stress. Its fanless design utilizes natural air convection for cooling, enabling completely silent operation and a typical life expectancy exceeding 62,000 hours even under demanding conditions.
Backed by an extensive 7-year manufacturer warranty, the HLG-100H-54A is a premier choice for mission-critical installations such as urban street lighting, industrial high-bay fixtures, outdoor parking area illumination, and professional greenhouse cultivation environments.
