• Output Power: 95.76 W
• Output Voltage: 42 V DC
• Output Current: 2.28 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 93 %
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 60 A @ 230 VAC
• Leakage Current: < 0.75 mA / 277 VAC
• Operating Temperature: −40 °C to +80 °C (Case temperature)
• Cooling: Fanless free air convection
• Protection Functions: Short circuit, Over current, Over voltage, Over temperature
• IP Rating: IP65
• Adjustability: Voltage (38–46V) and current (1.37–2.28A) adjustable via internal potentiometers
• Isolation Voltage: 3750 V AC (Input to Output)
• Dimensions (L x W x H): 220 mm x 68 mm x 38.8 mm
• Weight: approx. 1.12 kg
• Safety & EMC Certificates: UL8750, TUV EN61347-1, EN61347-2-13, PSE, KC, EAC, CB, CE
• Manufacturer Warranty: 7 Years

Details about the MEAN WELL HLG-100H-42A

The MEAN WELL HLG-100H-42A is a high-grade 96W LED driver engineered for maximum durability and peak performance in professional lighting architectures. This "A-Type" model is characterized by its rugged aluminum housing with an IP65 ingress protection rating, making it highly resistant to dust and water splashes in harsh environments. A standout technical characteristic is its on-board adjustment flexibility: internal potentiometers allow for the manual calibration of both output voltage and current levels, providing installers with the precision needed to optimize power delivery for specific LED array requirements. The unit features dual-mode constant voltage and constant current output, ensuring exceptional stability and compatibility across diverse load profiles. With a peak efficiency of 93 % and a built-in active PFC function, it operates with minimal energy loss and low thermal stress. Its fanless thermal design facilitates completely silent operation and reliable longevity, maintaining stable performance even at case temperatures as high as +80 °C. Backed by a typical lifetime of over 62,000 hours and a comprehensive 7-year manufacturer warranty, the HLG-100H-42A is a premier choice for high-reliability systems such as industrial high-bay lighting, urban street lamps, and sophisticated greenhouse cultivation environments.
