Technical Information & Details for the MEAN WELL HLG-100H-36A Power Supply
- Output Power: 95.4 W
- Output Voltage: 36 V DC
- Output Current: 2.65 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 93 %
- Ripple & Noise: ≤ 200 mVp-p
- Inrush Current: max. 60 A @ 230 VAC
- Leakage Current: < 0.75 mA / 277 VAC
- Operating Temperature: −40 °C to +80 °C (Case temperature)
- Cooling: Fanless free air convection
- Protection Functions: Short circuit, Over current, Over voltage, Over temperature
- IP Rating: IP65
- Adjustability: Voltage (33–40V) and current (1.6–2.65A) adjustable via internal potentiometers
- Isolation Voltage: 3750 V AC (Input to Output)
- Dimensions (L x W x H): 220 mm x 68 mm x 38.8 mm
- Weight: approx. 1.12 kg
- Safety & EMC Certificates: UL8750, TUV EN61347-1, EN61347-2-13, PSE, KC, EAC, CB, CE
- Manufacturer Warranty: 7 Years
Information about the MEAN WELL HLG-100H-36A
The MEAN WELL HLG-100H-36A is a high-performance 96W LED driver engineered for maximum reliability in professional lighting and industrial environments. This "A-Type" model is characterized by its rugged aluminum housing and IP65 rating, ensuring optimal performance in dusty or humid conditions. A standout characteristic is the on-board adjustment capability, where internal potentiometers allow for the manual calibration of both output voltage and current levels. This precision makes it an ideal solution for applications requiring specific power profiles to maximize LED longevity. The unit features dual-mode constant voltage and constant current output, providing exceptional stability across various load architectures. With a peak efficiency of 93 % and a built-in active PFC function, it operates with minimal energy waste and complies with strict global power quality standards. The fanless thermal design facilitates silent operation and long-term durability, even at case temperatures up to +80 °C. Boasting a typical lifetime of more than 62,000 hours and secured by an industry-leading 7-year manufacturer warranty, the HLG-100H-36A is a premier choice for high-bay lighting, urban street lamps, and heavy-duty industrial systems.
