• Output Power: 96 W
• Output Voltage: 20 V DC (Adjustable via internal potentiometer 17 – 22 V)
• Output Current: 4.8 A (Adjustable via internal potentiometer 2.88 – 4.8 A)
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
• Efficiency: 93 %
• Ripple & Noise: ≤ 150 mVp-p
• Inrush Current: max. 60 A @ 230 VAC
• Leakage Current: < 0.75 mA / 277 VAC
• Operating Temperature: −40 °C to +80 °C (T-case)
• Cooling: Fanless natural convection
• Protection Functions: Short circuit, Overload, Over voltage, Over temperature
• IP Rating: IP65
• Isolation Voltage: 3750 V AC
• Dimensions (L x W x H): 220 mm x 68 mm x 38.8 mm
• Weight: 1.12 kg
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP65, EAC, CE
• Typical Lifetime: > 62,000 hours
• Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-100H-20A

The MEAN WELL HLG-100H-20A is a professional-grade 100W AC/DC LED driver designed for projects that demand durability and precise control. This specific A-Type model is equipped with internal potentiometers, allowing for the manual adjustment of both the output voltage and current levels to perfectly match the requirements of the connected LED load. Operating in a dual Constant Voltage (CV) and Constant Current (CC) mode, it offers maximum versatility for architectural lighting, high-bay systems, and outdoor signage. The unit is encased in a rugged metal housing with an IP65 rating, ensuring superior protection against dust and moisture in challenging environments. With a high efficiency of 93% and advanced active PFC functionality, the HLG-100H-20A minimizes energy consumption and heat dissipation. Its wide input range of up to 305VAC and extended operating temperature range make it a global standard for reliability. Backed by a 7-year manufacturer warranty and a lifetime exceeding 62,000 hours, it represents a long-term, high-quality solution for mission-critical industrial and commercial lighting applications.
