Technical Information & Details about the MEAN WELL HDR-30-12 Power Supply Output Power: 24 W Output Voltage: 12 V DC Output Current: 2 A Current Range: 0 – 2 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: up to 88 % Ripple & Noise: ≤ 120 mVp-p Output Voltage Adjustment Range: 10.8 – 13.8 V DC Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Setup, Rise Time: 500 ms, 50 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) Inrush Current: 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Cooling: fanless free air convection Protection Functions: short circuit (hiccup mode, auto recovery), overload (constant current limiting 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 35 mm x 90 mm x 54.5 mm Weight: approx. 130 g Housing Material: insulating plastic, Class II Mounting: DIN rail TS35/7.5 or TS35/15 Safety & EMC Certifications: UL 62368-1, UL 508, TUV BS EN/EN 61558-2-16, BS EN/EN 61558-1, IEC 62368-1, EAC TP TC 004, BSMI, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000-6-2, BS EN/EN 61204-3 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 years About the MEAN WELL HDR-30-12 The MEAN WELL HDR-30-12 is a 30 W ultra-slim DIN-rail power supply that delivers a regulated 12 V DC / 2 A output in a narrow 35 mm (2 SU) housing, ideal for compact distribution boards and slim control panels. With a wide 85–264 V AC / 120–370 V DC input range and efficiency up to 88 %, it is well suited for energy-efficient 12 V control circuits in building automation, home automation, and light industrial control systems. The adjustable 10.8–13.8 V output range allows fine tuning of the 12 V bus to compensate for voltage drops and supply relays, sensors, gateways, and I/O modules with stable power. Its Class II plastic enclosure provides double insulation and improves user safety by eliminating the need for a protective earth connection. Fanless free air convection, low no-load consumption below 0.3 W, a wide operating temperature range from −30 °C to +70 °C, and comprehensive protection and certification features make the HDR-30-12 a robust, low-maintenance 12 V power solution for household and industrial automation applications.

Technical Information & Details of the MEAN WELL HDR-15-12 Power Supply Output Power: 15 W Output Voltage: 12 V DC Output Current: 1.25 A Output Current Range: 0 – 1.25 A Output Voltage Adjustment Range: 10.8 – 13.8 V DC Ripple & Noise: ≤ 120 mVp-p Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational) Input Frequency: 47 – 63 Hz Efficiency (typ.): 85 % AC Input Current (typ.): 0.5 A @115 V AC / 0.25 A @230 V AC Inrush Current (typ.): 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Overload Protection: 110 – 145 % of rated power, constant current limiting within 50 – 100 % of rated output voltage, hiccup mode when Vout < 50 %, auto recovery Overvoltage Protection: 14.2 – 16.2 V DC, shut off output, clamping by zener diode Operating Temperature: −30 °C to +70 °C (derating according to curve) Operating Humidity: 20 – 90 % RH, non-condensing Storage Temperature / Humidity: −40 °C to +85 °C, 10 – 95 % RH, non-condensing Temperature Coefficient: ±0.03 % / °C (0 – 50 °C) Vibration Resistance: 10 – 500 Hz, 2 G, 10 min./cycle, 60 min. per axis (X, Y, Z) Operating Altitude: up to 2,000 m (derating above 2,000 m) Isolation Voltage: 4 kVAC (input–output) Isolation Resistance: > 100 MΩ @500 VDC, 25 °C, 70 % RH Dimensions (W x H x D): 17.5 mm x 90 mm x 54.5 mm Weight: approx. 74 g Mounting: DIN rail TS35/7.5 or TS35/15, ultra-slim 1-SU step-shape housing Housing / Isolation Class: plastic housing, isolation Class II, LPS (Limited Power Source) Front Indicators / Controls: LED indicator for power on, adjustable DC output voltage Safety Approvals: UL62368‑1, UL508, TUV BS EN/EN61558‑2‑16, BS EN/EN61558‑1, IEC62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252 (Part1) (except 48 V) EMC Emission: EN55032 (CISPR32), CNS15936 Class B; EN61000‑3‑2, EN61000‑3‑3 EMC Immunity: EN55035, EN61000‑6‑2, EN61204‑3; EN61000‑4‑2/3/4/5/6/8/11 MTBF (typ.): 3,724,300 h (Telcordia SR‑332, 25 °C) / 1,166,100 h (MIL‑HDBK‑217F, 25 °C) Warranty: 3 years Information about the MEAN WELL HDR-15-12 The MEAN WELL HDR‑15‑12 is a slim 15 W DIN rail power supply providing 12 V DC at up to 1.25 A, built in an ultra‑compact 17.5 mm (1 SU) plastic enclosure for space‑saving installations on TS35/7.5 or TS35/15 rails. Its wide 85–264 V AC input (with 277 V AC operational) and adjustable 12 V output range from 10.8 to 13.8 V make it suitable for a variety of 12 V control, sensor and logic applications in household and industrial environments. Thanks to a typical efficiency of 85 % and fanless convection cooling, the HDR‑15‑12 operates from −30 °C to +70 °C when derating is applied, which is ideal for compact distribution boards and building automation panels. With constant‑current overload protection, overvoltage shutdown, low no‑load power consumption and a comprehensive set of safety and EMC certifications, it offers a cost‑effective and standards‑compliant 12 V DIN rail supply for household control systems, building automation and small industrial control systems.

Technical Information & Details of the MEAN WELL HDR-15-15 Power Supply Output Power: 15 W Output Voltage: 15 V DC Output Current: 1 A Output Current Range: 0 – 1 A Output Voltage Adjustment Range: 13.5 – 18 V DC Ripple & Noise: ≤ 120 mVp-p Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational) Input Frequency: 47 – 63 Hz Efficiency (typ.): 85.5 % AC Input Current (typ.): 0.5 A @115 V AC / 0.25 A @230 V AC Inrush Current (typ.): 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Overload Protection: 110 – 145 % of rated power, constant current limiting within 50 – 100 % of rated output voltage, hiccup mode when Vout < 50 %, auto recovery Overvoltage Protection: 18.8 – 22.5 V DC, shut off output, clamping by zener diode Operating Temperature: −30 °C to +70 °C (derating according to curve) Operating Humidity: 20 – 90 % RH, non-condensing Storage Temperature / Humidity: −40 °C to +85 °C, 10 – 95 % RH, non-condensing Temperature Coefficient: ±0.03 % / °C (0 – 50 °C) Vibration Resistance: 10 – 500 Hz, 2 G, 10 min./cycle, 60 min. per axis (X, Y, Z) Operating Altitude: up to 2,000 m (derating above 2,000 m) Isolation Voltage: 4 kVAC (input–output) Isolation Resistance: > 100 MΩ @500 VDC, 25 °C, 70 % RH Dimensions (W x H x D): 17.5 mm x 90 mm x 54.5 mm Weight: approx. 74 g Mounting: DIN rail TS35/7.5 or TS35/15, ultra-slim 1-SU step-shape housing Housing / Isolation Class: plastic housing, isolation Class II, LPS (Limited Power Source) Front Indicators / Controls: LED indicator for power on, adjustable DC output voltage Safety Approvals: UL62368‑1, UL508, TUV BS EN/EN61558‑2‑16, BS EN/EN61558‑1, IEC62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252 (Part1) (except 48 V) EMC Emission: EN55032 (CISPR32), CNS15936 Class B; EN61000‑3‑2, EN61000‑3‑3 EMC Immunity: EN55035, EN61000‑6‑2, EN61204‑3; EN61000‑4‑2/3/4/5/6/8/11 MTBF (typ.): 3,724,300 h (Telcordia SR‑332, 25 °C) / 1,166,100 h (MIL‑HDBK‑217F, 25 °C) Warranty: 3 years Information about the MEAN WELL HDR-15-15 The MEAN WELL HDR‑15‑15 is a 15 W ultra‑slim DIN rail power supply delivering 15 V DC at up to 1 A, built in a 17.5 mm (1 SU) step‑shape plastic housing for highly space‑constrained distribution boards and control panels. With its wide 85–264 V AC input (277 V AC operational) and adjustable 15 V output range from 13.5 to 18 V, it is well suited for 15 V signal, control and small actuator loads in household and industrial automation systems. Thanks to a typical efficiency of 85.5 %, fanless convection cooling and an operating temperature range from −30 °C to +70 °C (with derating), the HDR‑15‑15 offers reliable operation in a broad range of ambient conditions. Its constant‑current overload behaviour, overvoltage shutdown, low no‑load power consumption and comprehensive safety and EMC approvals make it a competitive and standards‑compliant 15 V DIN rail supply for building automation, household control systems, factory automation and electro‑mechanical equipment.
