Technical Information & Details on MEAN WELL PWM-200-36KN Power Supply
- Output Power: 199.8 W
- Output Voltage: 36 V DC
- Output Current: 5.55 A
- Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 94 %
- Inrush Current: 65 A (Peak)
- No-Load Power Consumption: < 0.5 W (Standby)
- Operating Temperature: −40 °C to +80 °C
- Cooling: natural convection
- Protection Functions: Short Circuit (Hiccup), Overload, Overvoltage, Over Temperature
- Isolation Voltage: 3.75 kV AC between Input and Output
- Dimensions (L x W x H): 195 mm x 68 mm x 39.5 mm
- Weight: approx. 1.03 kg
- Safety & EMC Certifications: UL8750, ENEC, EAC, CB
- MTBF: > 1658 K hours
- KNX Interface: certified, PWM Dimming up to 4 kHz
Information on MEAN WELL PWM-200-36KN
The MEAN WELL PWM-200-36KN is a high-performance 200 W PWM LED driver power supply with integrated KNX interface for smart lighting control in buildings. It excels with exceptional efficiency up to 94 %, wide temperature range from -40 °C to +80 °C, and universal input voltage for global applications. Unique KNX-certified integration enables seamless dimming (0-100 %, PWM up to 4 kHz), automatic fault recovery, and outstanding reliability with MTBF over 1.6 million hours – perfect for professional LED lighting in industrial, office, and smart home environments.
