• Output Power: 96.12 W (at 200–305 V AC) / 70 W (at 100–180 V AC)
• Output Voltage: 54 V DC
• Output Current: 1.78 A
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: Up to 91%
• Ripple & Noise: ≤ 350 mVp-p
• Inrush Current: COLD START 60 A @ 230 V AC
• No Load / Standby Power: < 0.5 W
• Operating Temperature: −40 °C to +90 °C (Case temperature Tcase)
• Cooling: Fanless free air convection
• Protections: Short circuit (Hiccup mode), Overload (Constant current limiting), Over voltage, Over temperature
• Isolation Voltage: 3750 V AC between Input and Output
• Dimming Control: 3-in-1 dimming (0–10 V DC, 10 V PWM signal, resistance)
• Ingress Protection / Housing: IP67, Metal housing
• AC Input Cable: 3-core AC input cable with protective earth (-3Y model)
• Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
• Weight: approx. 850 g
• Safety & EMC Standards: UL8750 (Type HL), EN61347-1, EN61347-2-13, EN55015, EAC, CB, CE
• Warranty: 5 Years

Information about MEAN WELL ELG-100-54B-3Y

Enhanced brightness control is provided by the MEAN WELL ELG-100-54B-3Y through its built-in 3-in-1 dimming system (B), supporting 0–10V, PWM, and resistance inputs. Equipping the driver with a 3-core AC cord (-3Y version) featuring an integrated earth conductor drastically simplifies electrical grounding compliance during installation. Complete protection against severe moisture and dust penetration is ensured by the fully encapsulated IP67 metal enclosure. Designed for silent operation via natural convection thermal cooling, it performs reliably across case temperatures from -40 °C to +90 °C. Qualified to UL8750 (Type HL) standards for Class I, Division 2 hazardous zones, the unit includes a 5 years manufacturer warranty.
