• Output Power: 151.2 W
• Output Voltage: 42 V DC
• Output Current: 3.6 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 94 %
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 65 A @ 230 VAC
• Power Factor: PF ≥ 0.98 @ 115 VAC / PF ≥ 0.95 @ 230 VAC
• Operating Temperature: −40 °C to +90 °C
• Cooling: Fanless natural convection
• Protections: Short circuit, Over current, Over voltage, Over temperature
• IP Rating: IP67 (fully potted)
• Isolation Voltage: 3750 V AC between input and output
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: approx. 1150 g
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP67, CE
• Dimming Function: 3-in-1 dimming (1-10VDC, 10V PWM, resistance)
• Manufacturer Warranty: 7 Years

Product Information: MEAN WELL HLG-150H-42B

The MEAN WELL HLG-150H-42B stands as a high-performance LED driver engineered for excellence, featuring a versatile dual-mode Constant Voltage and Constant Current output. This model is particularly distinguished by its extraordinary efficiency of up to 94%, which significantly reduces energy loss and allows the unit to maintain optimal performance via fanless natural convection cooling. Encased in a rugged metal housing with an IP67 protection rating, it is fully prepared for harsh environments, including outdoor architectural lighting and high-bay industrial installations. The advanced 3-in-1 dimming functionality provides seamless control over brightness through 1-10VDC, PWM signals, or resistance, catering to smart building requirements. Designed for longevity, the unit boasts a typical lifetime of more than 62,000 hours and is backed by an industry-leading 7-year manufacturer warranty, ensuring maximum reliability for mission-critical infrastructure and large-scale LED deployments.
