• Output Power: 151.2 W
• Output Voltage: 36 V DC
• Output Current: 4.2 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 94%
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 65 A @ 230 V AC
• No-load Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +90 °C
• Cooling: Fanless, free air convection
• Protection Functions: Short circuit, Overload, Over voltage, Over temperature
• IP Rating: IP67 (fully encapsulated)
• Dimming Function: 3-in-1 dimming (1-10V DC, PWM, resistance)
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: approx. 1150 g
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP67, CE
• Withstand Voltage: 3750 V AC
• Manufacturer Warranty: 7 Years

About the MEAN WELL HLG-150H-36B

The MEAN WELL HLG-150H-36B is a premium-grade 150W LED driver engineered for professional lighting systems that demand advanced control and superior environmental protection. This "B" type model is specifically equipped with a versatile 3-in-1 dimming interface, allowing for precise output current management via 1-10V DC, 10V PWM signals, or external resistance. Its fully encapsulated aluminum housing with an IP67 rating ensures total protection against dust and water ingress, making it a perfect choice for harsh industrial environments, street lighting, and outdoor floodlighting. The driver operates with a 94% peak efficiency, which significantly reduces energy waste and internal heat generation, allowing the unit to function reliably without fans even at high ambient temperatures. Designed for versatility, it features a dual-mode output that handles both constant voltage and constant current requirements. With an impressive typical service life exceeding 62,000 hours and a comprehensive 7-year manufacturer warranty, it represents a long-term, high-reliability power solution for critical lighting infrastructure worldwide.
