• Output Power: 150 W
• Output Voltage: 30 V DC
• Output Current: 5 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 93.5%
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 65 A @ 230 V AC
• No-load Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +90 °C
• Cooling: Fanless, free air convection
• Protection Functions: Short circuit, Overload, Over voltage, Over temperature
• IP Rating: IP67 (fully encapsulated for outdoor use)
• Dimming Function: 3-in-1 dimming (1-10V DC, 10V PWM signal or resistance)
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: approx. 1150 g
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP67, CE
• Output Mode: Dual mode Constant Voltage + Constant Current
• Manufacturer Warranty: 7 Years

About the MEAN WELL HLG-150H-30B

The MEAN WELL HLG-150H-30B is a high-performance 150W LED driver designed for professional lighting systems requiring advanced dimming capabilities and long-term durability. This "B" type model features a versatile 3-in-1 dimming interface, allowing for precise output current adjustment via 1-10V DC, 10V PWM signals, or external resistance, making it perfect for integration into smart lighting controls. With its IP67 ingress protection level, the fully encapsulated metal housing provides total protection against dust and temporary immersion in water, ensuring reliable performance in harsh environments and outdoor installations. The unit achieves a high efficiency of 93.5%, which significantly reduces power loss and thermal stress, leading to a service life of more than 62,000 hours. Its fanless design enables silent operation even at extreme temperatures, while the dual-mode output ensures compatibility with both direct-drive LEDs and systems requiring constant voltage. Reflecting its superior industrial build quality, MEAN WELL provides a comprehensive 7-year manufacturer warranty, making it a dependable choice for large-scale outdoor, greenhouse, and industrial lighting projects.
