Technical Information & Details for the MEAN WELL HLG-100H-54B Power Supply
- Output Power: 95.58 W
- Output Voltage: 54 V DC
- Output Current: 1.77 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency: 93 %
- Ripple & Noise: ≤ 200 mVp-p
- Leakage Current: < 0.75 mA / 277 VAC
- Operating Temperature: −40 °C to +80 °C (T-case)
- Ingress Protection: IP67 (fully dust-tight and waterproof)
- Dimming Technology: 3-in-1 dimming (1–10V DC, 10V PWM signal, or resistance)
- Safety Standards: UL8750, CSA C22.2, BS EN/EN 61347-1, GB19510.1, EAC
- Manufacturer Warranty: 7 Years
Information about the MEAN WELL HLG-100H-54B
The MEAN WELL HLG-100H-54B is a high-performance 96W LED driver specifically engineered for advanced dimming control and long-term reliability in professional lighting environments. As a "B-Type" model, it is distinguished by its versatile 3-in-1 dimming function. This feature provides lighting designers with the flexibility to regulate output current using a 1–10V DC signal, a 10V PWM signal, or an external resistance, making it an ideal choice for smart city initiatives and automated industrial lighting.
Built for extreme environmental resilience, the HLG-100H-54B features a fully potted metal enclosure with an IP67 rating. This design ensures that the unit is completely sealed against dust and remains operational even after temporary immersion in water. Such robust protection makes it suitable for high-exposure outdoor installations, hazardous industrial locations, and architectural lighting in challenging climates.
Technically, the unit features a dual-mode constant voltage and constant current output, allowing it to adapt effortlessly to various LED load configurations. With a peak efficiency of 93% and built-in active PFC, the driver minimizes energy waste and optimizes power quality. The fanless thermal design utilizes natural air convection for cooling, facilitating silent operation and a typical life expectancy of more than 62,000 hours, even at case temperatures up to +80 °C.
The unit includes comprehensive protection mechanisms against short circuits, overvoltage, and overtemperature, ensuring the safety of the entire lighting system. Backed by a premier 7-year manufacturer warranty, the HLG-100H-54B is a top-tier solution for applications requiring high-voltage output and intelligent control, such as street lighting, industrial floodlights, and large-scale greenhouse systems.
