Technical Information & Details for the MEAN WELL HLG-100H-30B Power Supply
- Output Power: 96 W
- Output Voltage: 30 V DC
- Output Current: 3.2 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 93 %
- Ripple & Noise: ≤ 200 mVp-p
- Inrush Current: max. 60 A @ 230 VAC
- Leakage Current: < 0.75 mA / 277 VAC
- Operating Temperature: −40 °C to +80 °C (T-case)
- Cooling: Fanless free air convection
- Protection Functions: Short circuit, Over current, Over voltage, Over temperature
- IP Rating: IP67 (full protection against dust and temporary immersion)
- Dimming Technology: 3-in-1 dimming (1–10V DC, 10V PWM signal, or resistance)
- Isolation Voltage: 3750 V AC (Input to Output)
- Dimensions (L x W x H): 220 mm x 68 mm x 38.8 mm
- Weight: approx. 1.12 kg
- Safety & EMC Certificates: UL8750, TUV EN61347-1, EN61347-2-13, PSE, KC, EAC, CB, CE
- Manufacturer Warranty: 7 Years
Details about the MEAN WELL HLG-100H-30B
The MEAN WELL HLG-100H-30B is a high-performance 96W AC/DC LED driver designed for professional-grade installations where intelligent dimming and environmental resilience are paramount. This "B-Type" variant is distinguished by its integrated 3-in-1 dimming function, which allows for precise light management via a 1–10V DC signal, 10V PWM signal, or external resistance. Engineered with a rugged metal housing, the driver features an IP67 rating, ensuring total protection against dust ingress and making it resistant to water immersion, which is critical for demanding outdoor and industrial applications. Its dual-mode constant voltage and constant current output provides the necessary flexibility to power various LED configurations while maintaining exceptional electrical stability. With an efficiency of up to 93 % and a built-in active PFC function, the HLG-100H-30B maximizes energy savings and ensures high power quality. The fanless design enables completely silent operation and long-term reliability even at high case temperatures of up to +80 °C. Backed by a typical lifetime of over 62,000 hours and a generous 7-year manufacturer warranty, this driver is a top-tier choice for LED high-bay lighting, parking lot illumination, and sophisticated greenhouse lighting systems.
