• Output Power: 81 W
• Output Voltage: 30 V DC
• Output Current: 2.7 A
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: 91 %
• Ripple & Noise: max. 200 mVp-p
• Inrush Current: 70 A at 230 V AC
• Operating Temperature: −40 °C to +80 °C (Case)
• Cooling: fanless free air convection
• Protection Functions: Short circuit, Over current, Over voltage, Over temperature
• Isolation Voltage: 3750 V AC (Input to Output)
• Dimensions (L x W x H): 195.6 mm x 61.5 mm x 38.8 mm
• Weight: approx. 840 g
• Safety & EMC Certificates: UL8750, EN61347-1, IP67, CE, EAC, KC
• Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-80H-30B

The MEAN WELL HLG-80H-30B is a professional 81W AC/DC driver engineered for superior durability in industrial and lighting applications. A primary characteristic of this B-Type model is the versatile 3-in-1 dimming function, supporting output level adjustments via 1–10V DC, 10V PWM signals, or resistance. The unit features a sophisticated dual-mode output design, allowing it to function effectively in both Constant Voltage and Constant Current regions to accommodate various LED configurations. Housed in a fully encapsulated metal casing with an IP67 rating, it is completely protected against dust and water immersion, making it ideal for harsh outdoor environments. Technically, the HLG-80H-30B excels with built-in active Power Factor Correction and a 91% efficiency rating, supporting its fanless thermal architecture for silent operation. With a typical life expectancy exceeding 62,000 hours and an industry-leading 7-year manufacturer warranty, it provides exceptional long-term stability for projects such as high-bay lighting, greenhouse systems, and professional LED signage.
