Technical Information & Details on MEAN WELL HLG-60H-48B Power Supply
- Output Power: 60 W
- Output Voltage: 48 V DC
- Output Current: 1.3 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 90.5 %
- Ripple & Noise: ≤ 300 mVp-p
- Inrush Current: max. 55 A
- No-Load Power Consumption: < 0.5 W
- Operating Temperature: -40 °C to +80 °C (case temperature)
- Cooling: fanless natural convection
- Protection Functions: Short circuit (Hiccup), Overload, Overvoltage, Over temperature
- IP Rating: IP67
- Isolation Voltage: 3.75 kV AC between input and output
- Dimensions (L x W x H): 171 mm x 61.5 mm x 36.8 mm
- Weight: ca. 730 g
- Safety & EMC Certifications: UL8750, CE, TÜV, CB, EAC, IP67
- Manufacturer Warranty: 7 years
Information on MEAN WELL HLG-60H-48B
The MEAN WELL HLG-60H-48B is a high-performance 60 W LED driver power supply with exceptional efficiency up to 90.5 % and rugged IP67 housing for indoor and outdoor use. It delivers stable 48 V DC / 1.3 A output voltage with adjustable range 40–58 V and outstanding temperature resistance from -40 °C to +80 °C thanks to fanless convection cooling. Featuring universal input voltage range, potentiometer adjustment, and comprehensive protections with auto-recovery, it is ideal for professional LED lighting, street lights, floodlights, and industrial applications demanding maximum reliability and longevity.
