Technical Information & Details on MEAN WELL HLG-60H-36B Power Supply
- Output Power: 61.2 W
- Output Voltage: 36 V DC
- Output Current: 1.7 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 90 %
- Ripple & Noise: < 240 mVp-p
- Inrush Current: max. 45 A @230 VAC
- No-Load Power Consumption: < 0.5 W
- Operating Temperature: −40 °C to +80 °C
- Cooling: fanless natural convection
- Protection Functions: Short circuit, Overload, Overvoltage, Over temperature
- Overvoltage Category: OVC III
- Isolation Voltage: 3750 V AC between input and output
- Dimensions (L x W x H): 171 mm x 61.5 mm x 36.8 mm
- Weight: ca. 730 g
- Safety & EMC Certificates: CE, UL, TUV, CB, EAC
- Dimming: 3-in-1 (1-10V, PWM, Resistance)
- Protection Rating: IP67
- Manufacturer Warranty: 7 years
Information on MEAN WELL HLG-60H-36B
The MEAN WELL HLG-60H series provides rugged IP67 waterproof LED power supplies with high reliability for demanding outdoor and industrial applications. The HLG-60H-36B model excels with an extreme temperature range from -40 °C to +80 °C, universal input voltage up to 305 V AC, and up to 90 % efficiency for minimal losses and long-term deployment. Featuring integrated 3-in-1 dimming, active PFC function, automatic recovery after faults, and a 7-year manufacturer warranty, it is ideal for LED lighting, street lamps, industrial systems, and harsh environments with constant performance and maximum flexibility.
