Technical Information & Details for MEAN WELL XLG-200-L-AB Power Supply
- Output Power: 200 W
- Output Voltage (Constant Power Region): 142 – 285 V DC
- Output Current (Default): 700 mA
- Current Adjustment Range: 350 – 1050 mA (via Potentiometer & Dimming)
- Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 94 %
- Dimming Methodology: 3-in-1 dimming (0-10Vdc, 10V PWM signal, resistance)
- Inrush Current: max. 65 A @ 230 VAC
- Standby Power Consumption: < 0.5 W (Dimming OFF)
- Operating Temperature: −40 °C to +90 °C (Tcase)
- Cooling: Fanless free air convection
- Protection Functions: Short circuit, Over voltage, Over current, Over temperature
- Surge Immunity: 6KV Line-Earth / 4KV Line-Line protection
- Isolation Voltage: 3750 V AC between Input and Output
- Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
- Weight: approx. 850 g
- Safety Standards: UL8750, EN61347-1, IP67, CE, CB, ENEC
- Special Feature: AB-Type: Internal Potentiometer + External Dimming interface
- Manufacturer Warranty: 5 Years
Information about the MEAN WELL XLG-200-L-AB
The MEAN WELL XLG-200-L-AB is a high-performance 200W LED driver engineered for high-voltage lighting systems that demand precise control and extreme durability. Featuring the advanced Constant Power Mode, it delivers its full rated wattage across a broad output voltage range of 142V to 285V. As an AB-Type model, it offers the ultimate in versatility by combining an internal potentiometer for manual current limiting (350 mA to 1050 mA) with a sophisticated 3-in-1 dimming interface (0-10V, PWM, or resistance). The unit is housed in a rugged metal enclosure with an IP67 rating, making it impervious to water and dust, and perfectly suited for harsh environment deployments such as skyscraper lighting, stadium floodlights, and industrial high-bay lamps. With an industry-leading efficiency of 94% and integrated 6KV surge protection, this driver ensures stable and energy-efficient operation even under unstable grid conditions. Its fanless design and high-quality components provide a service life exceeding 50,000 hours, supported by a comprehensive 5-year manufacturer warranty.
