ELG-200-24-3Y

Technical Information & Details for the KVF-24080-TDH Power Supply Output Power: 80 W Output Voltage: 24 V DC Output Current: 3.33 A Input Voltage Range: 200 – 240 V AC, 47 – 63 Hz Efficiency: up to 83% Dimming Function: Phase cut / Triac dimmable, PWM output (0-100%) Inrush Current: typ. 56 A @230 VAC Waterproof Rating: IP66 Working Temperature: −40 °C to +60 °C Cooling: Free air convection (fanless) Protections: Short circuit, over load, over temperature Power Factor (PF): ≥0.97 at full load Withstand Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 226 mm x 69.8 mm x 42 mm Weight: 1.04 kg Certifications: ENEC, SAA, CCC, CE, CB, RoHS, Reach Manufacturer Warranty: 5 Years Information about the KVF-24080-TDH The KVF-24080-TDH is a premium, high-performance dimmable LED driver engineered for professional lighting applications, delivering a reliable 80 watts of output power and a highly stable 24V DC output voltage. Equipped with advanced Triac and phase-cut dimming capabilities, the unit features a high-frequency 20KHz PWM output that ensures completely flicker-free lighting alongside a perfectly smooth dimming range from 0 to 100%. The built-in active PFC function guarantees an exceptional power factor of ≥0.97, effectively maximizing energy efficiency while minimizing harmonic distortion on the power grid. Encased in a rugged, IP66-rated waterproof housing, this power supply is exceptionally suited for demanding indoor and outdoor LED lighting installations where durability is paramount. Beyond its seamless compatibility with leading edge (MLV) and trailing edge (ELV) dimmers, this 80W LED power supply delivers outstanding operational reliability even in extreme environmental conditions, functioning flawlessly between -40 °C and +60 °C. It incorporates comprehensive, auto-recovering safety protections against short circuits, overloads, and over-temperatures to prevent hardware damage and ensure continuous system integrity. The entirely fanless design relies on free air convection cooling to provide a maintenance-free and completely silent performance. Backed by a generous 5-year manufacturer warranty and strictly tested to meet global safety certifications (including ENEC, CE, and RoHS), the KVF-24080-TDH stands out as an exceptionally dependable and long-lasting power solution.

Technical Information & Details on MEAN WELL PWM-120-24 Power Supply Output Power: 120 W Output Voltage: 24 V DC Output Current: 5 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 90 % PWM Frequency: 1.47 kHz Inrush Current: typ. 60 A / 50 µs @ 230 VAC No-Load Power Consumption: < 0.5 W Operating Temperature: −40 °C to +80 °C Cooling: natural convection Protection Functions: Short circuit (Hiccup mode), Overload, Overvoltage, Over temperature Overvoltage Category: II Isolation Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 191 mm x 63 mm x 37.5 mm Weight: approx. 0.97 kg Safety & EMC Certifications: UL8750, ENEC EN61347-1/-2-13, EAC, CB, IP67 Dimming: 3-in-1 (0-10V, PWM, Resistance) MTBF: > 2243.7k hours (Telcordia SR-332) Manufacturer Warranty: 5 years Information on MEAN WELL PWM-120-24 This PWM LED driver excels with its extremely wide operating range (−40 °C to +80 °C), IP67 waterproofing for outdoor use, and high efficiency up to 90 % with low no-load consumption. Unique features include flexible 3-in-1 dimming, automatic fault recovery, and superior vibration resistance for enduring performance. The MEAN WELL PWM-120 series is a high-performance 120 W PWM output LED driver power supply with waterproof IP67 housing, designed for demanding outdoor and industrial applications. The PWM-120-24 model delivers stable 24 V DC / 5 A output power with an extremely wide input voltage range of 90–305 V AC. It is ideal for LED lighting, street lamps, industrial LEDs, and weather-exposed installations, backed by comprehensive certifications and a 5-year manufacturer warranty.

Technical Information & Details for MEAN WELL ELG-150-24B-3Y LED Driver Output Power: 150 W (at 200 – 305 V AC) / 105 W (at 100 – 180 V AC) Output Voltage: 24 V DC (Constant current region: 12 – 24 V) Rated Current: 6.25 A Dimming Function (3-in-1 Dimming): 0 – 10 V DC, 10 V PWM signal (100 Hz – 3 kHz), or resistance (0 – 100 kΩ) Ripple & Noise (max.): ≤ 200 mVp-p Voltage Tolerance: ±2.0% Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC Power Cord Option (3Y Specification): 3-wire AC input cable (Class I with safety earth ground) for European / global standard installations Efficiency (Typ.): 89% Power Factor (PF): PF ≥ 0.97 at 115 V AC / PF ≥ 0.95 at 230 V AC / PF ≥ 0.92 at 277 V AC (at full load) Ingress Protection: IP67 (suitable for indoor and outdoor installations) Operating Temperature: Tcase −40 °C to +90 °C (max. case temperature +90 °C) Cooling: Fanless free air convection Protections: Over current (95 – 108%, constant current limiting), Short circuit (hiccup mode), Over voltage (27 – 34 V), Over temperature Form Factor / Housing: Metal housing design with functional Ground (Class I) Dimensions (L x W x H): 219 mm x 63 mm x 35.5 mm Weight: Approx. 0.95 kg Manufacturer Warranty: 5 Years Information about MEAN WELL ELG-150-24B-3Y The MEAN WELL ELG-150-24B-3Y is a high-performance 150W AC/DC LED power supply featuring dual mode constant voltage and constant current output. Housed in a durable metal casing, it accepts a wide input voltage range of 100 to 305 V AC and provides a 24 V DC output with a rated current of up to 6.25 A (150 W output at 200–305 V AC). As a B-Type model, it features an IP67 rating and built-in 3-in-1 dimming functionality (0–10V, PWM, or resistance) via a dedicated dimming cable. The 3Y suffix designates the model configured with a 3-wire AC input cable with protective earth grounding for compliance with international safety standards. Designed with fanless free air convection cooling, it operates efficiently across case temperatures ranging from −40 °C to +90 °C, making it suitable for indoor and outdoor installations such as LED street lighting, architectural lighting, and floodlighting. Equipped with active PFC, built-in protection circuitry, and a lifetime expectancy exceeding 50,000 hours, it is backed by a 5-year manufacturer warranty.

Technical Information & Details for MEAN WELL ELG-200-24B-3Y Power Supply Output Power: 199.68 W Output Current: 8.33 A Output Voltage: 24 V DC Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz Efficiency: up to 92% Ripple & Noise: ≤ 200 mVp-p Inrush Current: max. 60 A @230 VAC Standby Power Consumption: < 0.5 W Operating Temperature: −40 °C to +90 °C (case temperature Tcase) Cooling: fanless free air convection Protections: short circuit, over current, over voltage, over temperature Overvoltage Category: OVC II Isolation Voltage: 3750 V AC input to output Dimensions (L x W x H): 244 mm x 71 mm x 37.5 mm Weight: approx. 1220 g Safety & EMC Certificates: CE, UL8750 (Type HL), EN61347-1, EN61347-2-13, EAC, BIS Protection Rating & Feature: IP67, 3-in-1 dimming function, 3-wire AC input with PE (3Y) Manufacturer Warranty: 5 years Information on the MEAN WELL ELG-200-24B-3Y Combining heavy-duty outdoor durability with precise output control, the MEAN WELL ELG-200-24B-3Y serves as an ideal LED driver for high-demand 24V industrial lighting systems. It features versatile 3-in-1 dimming technology, allowing seamless light adjustment via 0–10VDC, 10V PWM, or resistance inputs. Encapsulated in a rugged aluminum housing rated to IP67 water and dust ingress protection, the unit includes a 3-wire input cable with a dedicated PE ground wire for maximum safety compliance. Its hazardous-location Type HL approval makes it suitable for Class I, Division 2 installations, while built-in 5G vibration resistance protects against extreme mechanical shock. With high operational efficiency, this power supply is designed for continuous duty and is supported by a 5-year warranty.

Technical Information & Details for MEAN WELL HLG-320H-24B Power Supply Rated Power: 320.16 W Output Voltage: 24 V DC Rated Current: 13.34 A Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: up to 94% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 70 A @ 230 V AC (Cold start) Dimming Function: 3-in-1 dimming (0-10V DC, 10V PWM, Resistance) Power Factor: PF ≥ 0.95 at 230 V AC Operating Temperature: −40 °C to +90 °C (case temperature) Cooling: fanless free air convection Protections: Short circuit, Over current, Over voltage, Over temperature IP Rating: IP67 rated Isolation Voltage: 3750 V AC between Input and Output Dimensions (L x W x H): 252 mm x 90 mm x 43.8 mm Weight: approx. 1880 g Safety Standards: UL8750, EN61347-1, EN61347-2-13, IP67, PSE Manufacturer Warranty: 7 Years Information on the MEAN WELL HLG-320H-24B The MEAN WELL HLG-320H-24B is a high-performance LED driver specifically engineered for applications requiring advanced light intensity management through its versatile 3-in-1 dimming interface. Unlike standard models, the B-Type variant features a dedicated dimming cable that supports 0-10VDC, 10V PWM signals, or resistance-based control, offering seamless integration into automated building systems and professional dimming setups. This driver utilizes a dual-mode design, maintaining stable operation in both Constant Voltage (CV) and Constant Current (CC) regions to accommodate various LED array requirements. Built for the most demanding environments, the HLG-320H-24B is housed in a robust aluminum casing and is fully potted to achieve an IP67 ingress protection rating, making it waterproof and suitable for outdoor or high-humidity industrial sites. Its superior 94% efficiency and active PFC function ensure minimal heat generation, allowing for a reliable fanless operation even at elevated temperatures up to +90 °C. With a 7-year manufacturer warranty and a typical lifetime of over 62,000 hours, this power supply is a premier choice for high-bay lighting, street illumination, and large-scale signage where durability and precision control are paramount.

Technische Eigenschaften des SNAPPY SL100-24VF Nennleistung: 100 W Eingangsbereich von 200 bis 240VAC Ausgangsspannung: 24 VDC Class II Netzteil im Kunststoffgehäuse Lineare Bauform Schutzart IP20 Schutz vor Kurzschluss, Überspannung, Überlastung und Übertemperatur Informationen zum SNAPPY SL100-24VF Der Snappy SL100-24VF LED-Treiber mit einem Eingangsbereich von 200 bis 240 VAC liefert eine konstante Ausgangsspannung von 24 V mit einer 100 W Nennleistung. Dank der besonders niedrigen Höhe von 18,2mm ist das lineare LED-Netzteil äußerst platzsparend konzipiert. Die Konstruktion ist geeignet für die Installation in Möbelbeleuchtung, Lichtschienen sowie in Leuchtkästen. Mit der Schutzart IP20 des Kunststoffgehäuses kann das SL100-24VF Class II Netzteil bei einer Arbeitstemperatur von -20 bis +45°C und bei einer relativen Luftfeuchtigkeit zwischen 45% und 85% betrieben werden. Zudem verfügt der SL100-24VF LED-Treiber von Snappy über einen Schutz gegen Kurzschluss, Überlast, Überspannung sowie Übertemperatur. Eine Lebensdauer von 30.000 Stunden ist dabei garantiert. Weiterhin ist das Snappy SL100-24VF LED-Netzteil konform mit Sicherheitsstandards nach IEC61347-1, IEC61347-2-13, EN61547, EN61000-3-2 sowie weiteren Anforderungen, die für Netzteile im LED-Beleuchtungsbereich notwendig sind.
