• Output Power: 99.75 W (at 200–305 V AC) / 70.35 W (at 100–180 V AC)
• Output Voltage (Constant Current Region): 143 – 286 V DC
• Output Current: 350 mA
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 90%
• Current Ripple: 5.0% max.
• Inrush Current: 40 A / 230 V AC (Cold Start)
• No Load / Standby Power Consumption: < 0.5 W
• Operating Temperature (Case): −40 °C to +90 °C (Tcase)
• Cooling: fanless free air convection
• Protections: Short Circuit, Over Voltage, Over Temperature
• Surge Immunity: 6 kV / 4 kV (Line-Earth / Line-Line)
• Isolation Voltage: 3750 V AC (Input/Output)
• Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
• Weight: approx. 850 g
• Safety & EMC Certificates: UL8750 (Type HL), EN61347-1, EN61347-2-13, BIS IS15885, CB, CE, EAC
• Protection Rating: IP65
• Manufacturer Warranty: 5 years

Information about the MEAN WELL ELG-100-C350A-3Y

Tailored for high-voltage string networks requiring direct manual tuning, the MEAN WELL ELG-100-C350A-3Y power supply delivers reliable current regulation under heavy operational loads. Formatted as an A-Type model, it features a built-in potentiometer hidden beneath a secure rubber cap for easy output adjustment, paired with a 3-wire primary input line that includes protective grounding. Its heavy-duty metal enclosure achieves an ingress rating of IP65, effectively keeping out low-pressure water streams and airborne particulate matter. Engineered for structural endurance, the assembly safely handles continuous 5G vibration forces on outdoor poles and industrial frameworks. Supported by hazardous location compliance under UL8750 Type HL directives and backed by a comprehensive 5-year warranty, this unit guarantees exceptional long-term stability.
